Advance Electronic Fluorescent Ballast 32W T8 Single Lamp 120-277V Instant Start

Advance Electronic Fluorescent Ballast 32W T8 Single Lamp 120-277V Instant Start

(No reviews yet) Write a Review

Model: ICN1P32N35I
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$79.57
$22.81
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance Electronic Fluorescent Ballast 32W T8 Single Lamp 120-277V Instant Start

Professional instant start electronic ballast for single T8 fluorescent applications

The Advance electronic fluorescent ballast delivers reliable instant start operation for single 32W T8 fluorescent lamps with universal 120-277V input voltage. This compact electronic ballast features high 0.98 power factor for efficient operation and CSA/UL certification for professional installations across commercial and industrial applications.

Professional Features & Benefits

  • 32W Power Rating: Optimized for standard T8 fluorescent lamps providing consistent light output and energy efficiency
  • 120-277V Universal Input: Compatible with standard commercial voltage systems for versatile installation flexibility
  • 0.98 High Power Factor: Maximizes electrical efficiency and reduces power consumption for cost-effective operation
  • Electronic Instant Start: Provides immediate lamp ignition without flickering for professional lighting performance
  • Compact Design: 9.5" x 1.3" x 1.0" dimensions enable installation in tight fixture spaces
  • CSA/UL Certification: Meets rigorous safety standards for reliable commercial and industrial use
  • USA Manufacturing: Domestic production ensures consistent quality and reliable supply chain support

Technical Specifications

  • Ballast Type: Electronic Fluorescent
  • Country Of Origin: USA
  • Frequency Rating: 50to60 Hz
  • Lamp Type: T8
  • Number Of Lamps: 1
  • Power Factor: 0.98
  • Product Height: 1.0000 IN
  • Product Length: 9.5000 IN
  • Product Wattage: 32 W
  • Product Weight: 0.640 Lbs
  • Product Width: 1.3000 IN
  • Standard: CSA certificate;UL certificate;CEC Listing;RoHS Compliant
  • Voltage Rating: 120-277 V

Professional Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Facilities
  • Industrial Workspaces
  • Warehouse Lighting
  • Professional Service Areas

Why Choose Advance Quality?

Advance electronic ballasts combine proven reliability with professional-grade performance, backed by comprehensive CSA and UL certifications. The high power factor design and RoHS compliance demonstrate commitment to energy efficiency and environmental responsibility, while USA manufacturing ensures consistent quality and dependable supply chain support for critical lighting applications.

Manufacturer Resources

Product Specs

Ballast Type:
Electronic Fluorescent
Country Of Origin:
USA
Frequency Rating:
50to60 Hz
Lamp Type:
T8
Number Of Lamps:
1
Power Factor:
0.98
Product Height:
1.0000 IN
Product Length:
9.5000 IN
Product Wattage:
32 W
Product Weight:
0.640 Lbs
Product Width:
1.3000 IN
Standard:
CSA certificate;UL certificate;CEC Listing;RoHS Compliant
Voltage Rating:
120-277 V
Department:
Electrical

Advance ICN1P32N35I – Frequently Asked Questions

1) Will the Advance ICN1P32N35I ballast run on 277V, or do I need a separate part number for 120V?
One part covers both. The ICN1P32N35I accepts any input from 120 to 277 volts, so the same ballast goes into a 120V office circuit or a 277V commercial lighting branch without changing models. Frequency range is 50 to 60 Hz. For a facility standardizing a stockroom across mixed-voltage buildings, that means a single SKU on the shelf.
2) How many lamps will this Advance T8 ballast drive?
One. The ICN1P32N35I is a single-lamp ballast rated for one 32W T8. If your fixture is a 2-lamp or 4-lamp troffer, this is the wrong part unless you're intentionally running one ballast per lamp. Match the lamp count on the ballast label you're pulling out before ordering.
3) Is this Advance ballast UL listed and RoHS compliant for a healthcare or school job?
It carries a UL certificate and a CSA certificate, plus CEC Listing and RoHS compliance. That covers the safety listings inspectors ask for on commercial and institutional work in both the US and Canada, and the CEC listing matters if you're buying into California.
4) Will this Advance ballast fit inside a shallow strip fixture wireway?
It measures 9.5 x 1.3 x 1.0 inches and weighs 0.64 lbs, which is the standard small-can electronic form factor that drops into most T8 strip and troffer wireways. Measure the channel depth on your fixture against the 1.0 inch dimension if you're working with a low-profile or wraparound housing.
5) Instant start vs programmed start for a T8 ballast, which do I want?
The ICN1P32N35I is instant start. That suits spaces where lamps stay on for long runs, like offices, retail floors, warehouses and corridors. Instant start strikes the lamp immediately with no warm-up, but it's harder on cathodes in rooms switched on and off constantly. If the fixture is on an occupancy sensor or a frequently cycled space, a programmed start ballast is the better match for lamp life.
6) Does the Advance ICN1P32N35I meet the power factor requirement on our lighting spec?
Rated 0.98 power factor, which clears the 0.90 high power factor threshold commercial lighting specs and utility rebate programs typically call for. Useful number to have on hand when submitting a retrofit for approval.
7) What exact part number do I order for a single F32T8 Advance instant start ballast?
Advance ICN1P32N35I. The label shorthand reads ELE BLST (1) F32T8 120-277V IC, meaning electronic ballast, one F32T8 lamp, universal voltage. That's the number to cross-reference against the sticker on the ballast you're replacing.
8) Is this Advance ballast made in the USA?
Yes, country of origin is the USA. That's worth noting on federally funded or Buy American flagged projects where domestic sourcing has to be documented on the submittal.
