Advance Electronic Fluorescent Ballast 4-Lamp T8 32W 120-277V Instant Start

Advance Electronic Fluorescent Ballast 4-Lamp T8 32W 120-277V Instant Start

(No reviews yet) Write a Review

Model: ICN4P32N35I
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$83.30
$26.93
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance Electronic Fluorescent Ballast 4-Lamp T8 32W 120-277V Instant Start

Professional Electronic Ballast for Commercial & Industrial Lighting

The Advance Electronic Fluorescent Ballast delivers reliable instant start operation for 4-lamp T8 fluorescent systems. Engineered with 120-277V universal voltage compatibility and 0.98 power factor efficiency, this compact electronic ballast provides professional performance for commercial and industrial lighting applications. Built to UL and CSA standards with RoHS compliance and NEMA Premium rating.

Professional Features & Benefits

  • 4-Lamp T8 Capacity: Operates four 32W T8 fluorescent lamps simultaneously for comprehensive area lighting coverage
  • Universal Voltage 120-277V: Compatible with standard commercial voltage systems for versatile installation flexibility
  • High Power Factor 0.98: Maximizes electrical efficiency and reduces power consumption for cost-effective operation
  • Electronic Instant Start: Provides immediate lamp ignition without flicker or delay for professional lighting performance
  • Compact Design 9.5" x 1.3" x 1.0": Space-efficient profile fits standard fixture housings and tight installation spaces
  • Multi-Standard Certified: UL, CSA, CEC, and NEMA Premium certifications ensure code compliance and professional reliability
  • RoHS Compliant: Meets environmental standards for responsible commercial and industrial applications

Technical Specifications

  • Ballast Type: Electronic Fluorescent
  • Country Of Origin: USA
  • Frequency Rating: 50to60 Hz
  • Lamp Type: T8
  • Number Of Lamps: 4
  • Power Factor: 0.98
  • Product Height: 1.0000 IN
  • Product Length: 9.5000 IN
  • Product Wattage: 32 W
  • Product Weight: 1.000 Lbs
  • Product Width: 1.3000 IN
  • Standard: CSA certificate;UL certificate;CEC Listing;CEE Rated;NEMA Premium;NOM certificate;RoHS Compliant
  • Voltage Rating: 120-277 V

Professional Applications

  • Commercial Office Buildings
  • Retail and Shopping Centers
  • Educational Facilities
  • Healthcare and Medical Facilities
  • Industrial and Manufacturing Plants
  • Warehouse and Distribution Centers
  • Government and Municipal Buildings

Why Choose Advance Quality?

Advance electronic ballasts deliver proven reliability with comprehensive certifications including UL, CSA, CEC, and NEMA Premium ratings. Made in USA with RoHS compliance, this ballast provides the professional performance and code compliance required for demanding commercial and industrial lighting installations.

Manufacturer Resources

Product Specs

Ballast Type:
Electronic Fluorescent
Country Of Origin:
USA
Frequency Rating:
50to60 Hz
Lamp Type:
T8
Number Of Lamps:
4
Power Factor:
0.98
Product Height:
1.0000 IN
Product Length:
9.5000 IN
Product Wattage:
32 W
Product Weight:
1.000 Lbs
Product Width:
1.3000 IN
Standard:
CSA certificate;UL certificate;CEC Listing;CEE Rated;NEMA Premium;NOM certificate;RoHS Compliant
Voltage Rating:
120-277 V
Department:
Electrical

Advance ICN4P32N35I – Frequently Asked Questions

1) Will the Advance ICN4P32N35I ballast run on 277V, or do I need a separate ballast for 120V fixtures?
One ballast covers both. The Advance ICN4P32N35I is a universal-voltage electronic ballast rated 120-277 V, so the same part number goes into 120V office troffers and 277V high-bay or corridor fixtures. For a facility running mixed voltages that means one stocking number instead of two. Frequency rating is 50 to 60 Hz.
2) How many T8 lamps will the Advance ICN4P32N35I ballast drive, and can I run it with fewer lamps than that?
It is a 4-lamp ballast built for 32W T8 lamps, which is the standard 4-foot F32T8. It is an instant start ballast, so the lamp circuits are wired in parallel and a burned-out lamp does not take the others down with it. If your fixture is a 2-lamp or 3-lamp troffer, order the ballast that matches that lamp count rather than under-loading this one.
3) Will a 4-lamp T8 ballast fit inside a standard fluorescent troffer wireway?
The case measures 9.5 x 1.3 x 1.0 inches and weighs 1 pound, which is the common low-profile electronic ballast footprint that drops into the wireway channel of a 2x4 troffer or a strip fixture. Measure the channel before you pull the old one if you are retrofitting an older magnetic ballast, since magnetic cases are taller and the fixture may have been built around them.
4) Should I use an instant start or a programmed start ballast for my T8 fixtures?
Instant start, which is what the ICN4P32N35I is, strikes the lamp immediately with a high voltage kick and draws the least input power, so it suits spaces where lights come on in the morning and stay on: offices, warehouses, retail floors, corridors. Programmed start is the better choice where fixtures are switched frequently, particularly on occupancy sensors in restrooms, stairwells, and private offices, because it preheats the cathodes and gets far more switching cycles out of a lamp. If your controls cycle the lights all day, do not put an instant start ballast behind them.
5) Is the Advance ICN4P32N35I ballast UL listed and RoHS compliant for a healthcare or school project?
It carries UL certificate, CSA certificate, NOM certificate, CEC Listing, CEE Rated, NEMA Premium, and is RoHS Compliant. That set covers the US, Canada, and Mexico for an institutional submittal, and the CEC Listing is the one a California project will be asked for. Country of origin is USA, which is what a government or municipal buyer with domestic sourcing language on the PO needs to see.
6) What is the power factor on the Advance ICN4P32N35I, and does it matter for a commercial building?
Power factor is 0.98, which is high power factor by any utility definition, so a bank of these draws close to the same apparent power as real power. That matters on a large lamp count: it keeps branch circuit current down so you fit more fixtures per 20A circuit, and it keeps you clear of power factor penalties on a commercial demand meter. It also carries a NEMA Premium rating and a CEC Listing.
7) Is there one Advance ICN4P32N35I ballast, or do I have to pick a voltage version when I order?
There is a single orderable part, MPN ICN4P32N35I. No voltage, wattage, or lamp-count option to select, because the universal 120-277 V input covers the whole commercial range in one unit. For a property manager standardizing a building on 4-lamp T8 troffers, that is one line item on the PO regardless of which panel the fixtures land on.
8) Should I re-ballast my T8 fixtures or convert them to LED tubes?
Re-ballasting with an electronic instant start unit like this one is the low-cost move when the fixtures, lampholders, and lenses are sound and you just have ballasts failing: it is a wire-nut job per fixture and the F32T8 lamps you already stock keep working. Converting to LED means either buying ballast-compatible tubes that still run on this ballast, or rewiring the fixture to line voltage for direct-wire tubes, which is more labor per fixture. For a landlord replacing two failed ballasts in a suite, re-ballast. For a full warehouse relamp where you are touching every fixture anyway, price the LED conversion against it.
