Mersen ATM3 Midget Fast-Acting Fuse 600VAC/600VDC 3A Ferrule Terminal

Mersen ATM3 Midget Fast-Acting Fuse 600VAC/600VDC 3A Ferrule Terminal

Professional Fast-Acting Circuit Protection for AC/DC Applications

The Mersen ATM3 delivers reliable fast-acting circuit protection with dual voltage capability for both 600VAC and 600VDC applications. This midget fuse features ferrule terminals with tin-plated copper construction and GMG body insulating material for dependable performance in professional electrical installations. With 100 kA breaking capacity and clip mounting design, this 3A fuse provides comprehensive protection in a compact 1.5-inch form factor.

Professional Features & Benefits

• Dual Voltage Rating: 600VAC/600VDC capability provides versatile protection for both AC and DC circuits in diverse applications.
• High Breaking Capacity: 100 kA interrupting rating ensures reliable fault current protection in demanding electrical systems.
• Fast-Acting Response: Quick response characteristic provides immediate protection against overcurrent conditions and short circuits.
• Ferrule Terminal Design: Tin-plated copper ferrule terminals ensure secure connections and excellent conductivity for reliable operation.
• Midget Class Construction: Compact 1.5-inch length with GMG insulating material delivers space-efficient protection without compromising performance.
• Clip Mounting System: Simple clip mounting method enables quick installation and replacement in fuse holders and panels.
• RoHS Compliant: Environmentally responsible construction meets regulatory requirements for professional installations.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 100 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 3:00 AM
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Midget
• Mounting Method: Clip
• Product Length: 1.5 in
• Product Weight: 0.017 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 600 V
• Rohs Compliant: Yes
• Speed Characteristic: Fast-Acting

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Control Panels and Motor Control Centers
• Commercial Electrical Distribution Systems
• DC Power Supply and Battery Backup Systems
• Electronic Equipment and Instrumentation Protection
• Renewable Energy and Solar Power Systems
• Telecommunications and Data Center Infrastructure
• Process Control and Automation Equipment

Why Choose Mersen Quality?

Mersen delivers proven reliability through professional-grade construction featuring GMG insulating materials, tin-plated copper terminals, and RoHS compliant manufacturing. The compact midget design with high breaking capacity ensures dependable circuit protection while meeting stringent regulatory standards for professional electrical installations.
