Hager 8228 ADA-Compliant All-Active Push Plate Actuator Switches for Automatic Doors

Hager 8228 ADA-Compliant All-Active Push Plate Actuator Switches for Automatic Doors

(No reviews yet) Write a Review

Model: 8228-00H/00 32D
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$114.16
$87.58
Adding to cart… The item has been added
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 16 - 23 and get 3% off
  • Buy 24 - 31 and get 6% off
  • Buy 32 - 47 and get 9% off
  • Buy 48 or above and get 12% off
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Hager 8228 ADA-Compliant All-Active Push Plate Actuator Switches for Automatic Doors

Heavy-Duty Automatic Door Activation Solution

The Hager 8228 series delivers professional-grade push plate actuator switches designed for automatic door systems with full ADA compliance. These heavy-duty switches feature an innovative "all-active" design where any part of the plate triggers activation, ensuring reliable operation from any angle. Available in multiple configurations including 4.5" round, 6" round, and 4.5" square designs with durable stainless steel or brass faceplates for indoor and outdoor applications.

Professional Features & Benefits

  • Multiple Size Options: Available in 4.5" round (8228-01), 6" round (8228-00), and 4.5" square (8228-02) configurations for versatile installation requirements.
  • All-Active Design: Innovative activation technology allows triggering from any part of the plate surface, providing easy operation from any angle for enhanced accessibility.
  • ADA Compliance: Meets Americans with Disabilities Act requirements for accessibility, ensuring code compliance in commercial applications.
  • Heavy-Duty Construction: Durable stainless steel or brass faceplates with embossed graphics provide long-lasting performance and weather resistance for indoor and outdoor use.
  • Flexible Mounting Options: Designed to mount to standard single or double gang electrical boxes with surface mount options available for various installation scenarios.
  • Weather-Resistant Design: Engineered for reliable operation in both indoor and outdoor environments with appropriate weather protection.

Technical Specifications

  • Activation: "All-active" design means any part of the plate triggers the switch; easy to use from any angle.
  • Compliance: Meets Americans with Disabilities Act (ADA) requirements for accessibility.
  • Durability: Heavy-duty construction with stainless steel or brass faceplates, often with embossed graphics for longevity, suitable for indoor/outdoor use.
  • Key Features & Types: Models: Includes 8228-01 (4.5" RND), 8228-00 (6" RND), and 8228-02 (4.5" SQR).
  • Mounting: Mounts to standard single or double gang electrical box es, with surface mount options available.
  • Subcategory: Door Trim & Accessories

Installation & Operation

  1. Verify electrical requirements match available power supply and confirm compatibility with automatic door operator system before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit to standard single or double gang electrical box or use surface mount configuration ensuring adequate clearance for wiring access and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams and automatic door operator specifications. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings and test activation response with the automatic door system per application requirements.
  6. Restore power and test all functions including activation from multiple angles across the plate surface and integration with connected door operator systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Automatic Door Systems
  • Healthcare Facility Accessible Entrances
  • Educational Institution ADA-Compliant Access Points
  • Retail Store Automatic Entry Systems
  • Government and Municipal Building Accessibility
  • Industrial Facility Personnel Access
  • Multi-Tenant Residential Automatic Doors

Why Choose Hager Quality?

Hager 8228 series actuator switches deliver professional-grade reliability with heavy-duty stainless steel and brass construction designed for demanding automatic door applications. The all-active plate design and ADA compliance ensure dependable accessibility performance in both indoor and outdoor commercial environments. Engineered for demanding commercial applications where dependable automatic door activation is essential.

Manufacturer Resources

Product Specs

Subcategory:
Door Trim & Accessories
Product Group:
Sensors, Switches, Relays, Timers
Product Subgroup:
Door Trim & Accessories
Product Type:
Door Actuators & Plates
Product Model:
8225
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Hager 8228-00H/00 32D – Frequently Asked Questions

1) Will the Hager 8228 push plate work with my existing automatic door operator?
The 8228 is a hardwired actuator switch, so it needs to be wired into the operator's activation input. Every model in the range (6 inch round 8228-00H, 4.5 inch round 8228-01H, 4.5 inch square 8228-02H, and the narrow 8228-04W) is the hardwired configuration, not wireless. Before you order, confirm your operator accepts a dry hardwired activation input and that you can run cable from the plate location back to the operator. There is no transmitter or receiver in the box.
2) What size push plates does the Hager 8228 come in, and which one should I use on a narrow mullion?
Four shapes: 6 inch round (8228-00), 4.5 inch round (8228-01), 4.5 inch square (8228-02), and a narrow plate (8228-04W). Use the narrow plate where you are mounting on a jamb, mullion, or storefront stile that will not take a 4.5 inch face. The 6 inch round is the one to pick for high-traffic public entrances where you want the largest target for someone approaching with a cart or a wheelchair.
3) What electrical box do I need to rough in for a Hager 8228 actuator plate?
The 8228 mounts to a standard single or double gang electrical box, and surface mount options are available where you cannot cut into the wall. On a glass storefront or a masonry entry where recessing is not practical, plan on the surface mount configuration. Leave enough depth behind the plate for the wiring and for future service access.
4) Does the Hager 8228 push plate meet ADA requirements for an accessible entrance?
Yes. The 8228 meets Americans with Disabilities Act requirements for accessibility. It also uses an all-active plate, meaning any part of the face triggers the switch rather than a small button in the center, so it operates with an elbow, a forearm, a closed fist, or a wheelchair footrest. That is the practical part of accessible operation that a center-button plate does not give you.
5) Can a Hager 8228 push plate be mounted outside?
Yes, the 8228 is built for indoor and outdoor use, with a stainless steel or brass faceplate and weather-resistant construction. For an exterior bollard or wall post, that faceplate is what keeps the plate serviceable through weather; still pick a box and back-box detail that keeps water out of the wiring behind it.
6) Do I need two Hager 8228 push plates for one automatic door?
Most accessible entrances take two: one on the approach side outside and one inside. Each plate is a separate hardwired switch wired back to the operator's activation input, so budget one 8228 per side, plus the cable run for each. On a vestibule with an inner and outer door, that count doubles again. You can mix shapes across locations, for example a 6 inch round outside and a narrow plate on an interior mullion, since all four models are the same hardwired switch behind different faceplates.
7) Hager 8228 vs a wave-to-open touchless sensor: which should I specify for a healthcare entrance?
The 8228 is a contact plate, the user presses it. That is the right choice where you want a positive, deliberate activation that will not false-trigger from someone walking past, and it is the lower-cost, simpler wiring path since it is a straightforward hardwired switch to the operator. A touchless sensor is what you want where infection control drives the spec and nobody should touch the surface. Many healthcare projects run both: touchless at patient-facing doors, 8228 plates at staff and service entries.
8) Is the Hager 8228 a replacement for an existing round push plate actuator on a gang box?
In most cases yes, because the 8228 mounts to a standard single or double gang electrical box, which is the same rough-in nearly every actuator plate uses. Match the shape and size you are pulling off the wall: 6 inch round to 8228-00, 4.5 inch round to 8228-01, 4.5 inch square to 8228-02. Going from a 6 inch round down to a 4.5 inch plate can leave an unpainted or unfinished ring on the wall where the old plate sat.
