BEA BEA 10PBR45 - Stainless Steel 4.5" Round Push Plates BEA-10PBR45X

BEA 10PBR45 Stainless Steel Round Push Plate 4.5" ADA-Compliant Automatic Door Actuator

(No reviews yet) Write a Review

Model: 10PBR45

In Stock (leaves warehouse same day if ordered before 3pm ET)

$77.66
$53.62
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEA 10PBR45 Stainless Steel Round Push Plate 4.5" ADA-Compliant Automatic Door Actuator

Professional ADA-Compliant Access Control Solution

The BEA 10PBR45 stainless steel round push plate delivers professional-grade automatic door activation with 4.5" round design for enhanced accessibility compliance. This ADA-compliant actuator improves overall access and enhances accessibility for those with limited mobility or disabilities while seamlessly integrating with automatic door operators. Available with wireless compatibility options and multiple faceplate graphic configurations for versatile installation requirements.

Professional Features & Benefits

  • 4.5" Round Design: Optimal size for clear visibility and easy activation while meeting ADA compliance requirements for accessible door operation.
  • ADA-Compliant Construction: Meets accessibility standards with variety of popular faceplate graphic options including alternative accessibility artwork for clear user guidance.
  • Wireless Compatibility: Reduces installation time by eliminating the need to run wires from the push plate or use additional mounting hardware for flexible system integration.
  • Stainless Steel Construction: Durable stainless steel material provides long-lasting performance and resistance to wear in high-traffic commercial applications.
  • Dual Installation Options: Compatible with both surface and flush mount boxes for versatile mounting configurations to suit various architectural requirements.
  • Complete Kit Availability: Available in complete kits including plates, mounting boxes and optional wireless devices for simplified ordering and installation.
  • Enhanced Accessibility Design: Specifically engineered to improve overall access and enhance accessibility for users with limited mobility or disabilities.

Technical Specifications

  • Faceplate Material: 16 gauge, 304 2B Stainless Steel
  • Backplate Material: 1/8 inch thick, Aluminum
  • Mounting Screws: Stainless Steel, 6-32 x 1 in & 8-32 x 1 in Allen Head Size: 5/64
  • Cherry Switch: Single-pole, 15 A, COM / NO / NC, UL Recognized
  • Compatible Wireless Frequencies: 900, 433 or 300 MHz

Installation & Operation

  1. Verify electrical requirements match available power supply and confirm compatibility with existing automatic door operator system before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the push plate in the specified location using either surface or flush mount box configuration ensuring adequate clearance for wiring access and user operation.
  4. Route and connect wiring according to manufacturer wiring diagrams, or configure wireless transmitter connection per system requirements. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings and test wireless connectivity if applicable per application requirements and door operator specifications.
  6. Restore power and test all functions including normal activation response, wireless signal transmission if equipped, and integration with automatic door operator system.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Automatic Door Systems
  • Healthcare Facility Accessibility Compliance
  • Educational Institution ADA-Compliant Entrances
  • Retail Store Automatic Entry Systems
  • Government and Municipal Building Access
  • Multi-Tenant Residential Automatic Doors
  • Industrial Facility Accessible Entrances

Why Choose BEA Quality?

BEA push plate products deliver professional-grade reliability with stainless steel construction and ADA-compliant design engineered for demanding commercial applications. The 4.5" round configuration provides optimal visibility and accessibility while offering both hardwired and wireless compatibility options for flexible system integration. Engineered for demanding commercial applications where dependable automatic door activation and accessibility compliance are essential.

Product Specs

Product Type:
Round Push Plates
Series:
10PBR45X
Subcategory:
Parts and Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Size:
4-1/2"
Product Category:
Electronic Access Control
Department:
Door Hardware

BEA 10PBR45 – Frequently Asked Questions

1) What size is the BEA 10PBR45 push plate, and is it big enough to meet ADA actuator requirements?
The 10PBR45 is a 4-1/2 inch round actuator plate, which is the standard round size used on ADA automatic door openings. The description calls out the ADA-compliant round design with faceplate graphics that guide the user to the button. If your specification calls for a 6 inch square or a 4-3/4 by 4-3/4 plate, this is not that part.
2) Can the BEA 10PBR45 be surface mounted, or does it need a box in the wall?
Both. The plate works with a surface mount box or a flush mount box, so you can cut it into a finished wall or hang it on a mullion or masonry where you cannot get behind the surface. The mount box is a separate item, and BEA sells complete kits with the plate, the box, and an optional wireless device together.
3) Do I have to run wire to the BEA 10PBR45 push plate?
Not if you go wireless. The 10PBR45 is offered with wireless compatibility that removes the wire run from the plate back to the operator, which is how most retrofits into existing masonry or glass-front entrances get done. The wireless side works at 900, 433, or 300 MHz, so the transmitter frequency has to match the receiver at the door operator. Hardwired is still an option, and the plate's switch gives you COM, NO, and NC terminals for that.
4) Will the BEA 10PBR45 work with a door operator that needs a normally closed input?
Yes. The switch behind the plate is a single-pole Cherry switch wired out to COM, NO, and NC, so it drops into either a normally open or a normally closed activation input on the operator. It is rated 15 A and UL Recognized. Most low-voltage automatic operator inputs are a dry contact closure, and the NO leg is what you land on for those.
5) What else do I need to order with the BEA 10PBR45 to finish the job?
At minimum a mount box, surface or flush depending on the wall, since the plate itself does not include one. Going wireless adds a transmitter at the plate and a matching receiver at the operator on the same frequency (900, 433, or 300 MHz). Hardwired instead means low-voltage cable from the plate to the operator's activation input. BEA packages plate, box, and optional wireless device as a kit if you would rather order it as one line.
6) Which graphic options does the BEA 10PBR45 round push plate come in?
Three faceplate graphics: blue text only, blue handicap logo only, and blue handicap logo with text. Facilities that standardize on the wheelchair symbol alone usually take the logo-only plate; buildings that want wording at the entrance take the logo-and-text version. All three are the same 4-1/2 inch round stainless plate underneath, so mixing graphics across a building does not change the mounting.
7) Is the BEA 10PBR45 push plate stainless steel all the way through?
The faceplate is 16 gauge 304 2B stainless. The backplate behind it is 1/8 inch aluminum. That is the normal build for an actuator: the stainless is what takes the hand traffic and the aluminum carries the switch. For a healthcare corridor or a school entrance getting hit hundreds of times a day, the 304 face is the part that matters.
8) Round push plate or square push plate for an automatic door actuator, which should I use?
It comes down to what the wall and the spec already have. The round 4-1/2 inch plate like the BEA 10PBR45 mounts in a smaller footprint and is the common choice on narrow jamb faces and mullions where a square plate overhangs. Square plates give more surface for a bigger graphic and are often what a drawing calls out for main lobby entrances. Electrically they behave the same, and BEA covers both sizes in the same 4-1/2 inch round and square family, so switching shape does not change how it wires to the operator.
9) What screws come with the BEA 10PBR45 and what driver do I need on site?
Mounting screws are stainless, supplied in 6-32 x 1 inch and 8-32 x 1 inch, with Allen heads taking a 5/64 hex key. Bring that 5/64 wrench; it is not a Phillips plate. The two thread sizes cover the different BEA box configurations.
10) Is the BEA 10PBR45 rated for a commercial entrance or is it a light-duty residential actuator?
Commercial. BEA lists the 10PBR45 as a commercial product, built for hospital and clinic entrances, school and campus doors, retail entries, government buildings, multi-tenant residential lobbies, and industrial openings. The 304 stainless face is the reason it holds up in those traffic counts.
