BEA 10PBR6X Stainless Steel 6"...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$90.90
$81.09
BEA BEA 10PBR6X - Stainless Steel 6" Round Push Plates BEA-10PBR6X

BEA 10PBR6X Stainless Steel 6" Round Push Plate for Automatic Door Activation

(No reviews yet) Write a Review

Model: 10PBR
From the 10PBR6X Collection

In Stock (leaves warehouse same day if ordered before 3pm ET)

$90.90
$81.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEA 10PBR6X Stainless Steel 6" Round Push Plate for Automatic Door Activation

ADA-Compliant Accessibility Solution for Automatic Door Systems

The BEA 10PBR6X is a professional-grade 6" round stainless steel push plate designed to enhance accessibility and integrate seamlessly with automatic door activation systems. This ADA-compliant push plate improves overall access for those with limited mobility or disabilities while offering flexible installation options including hardwired connections to door operators or wireless compatibility with BEA transmitters. Available in various design options with alternative accessibility artwork for customized applications.

Professional Features & Benefits

  • 6" Round Design: Optimal size for clear visibility and easy activation while meeting accessibility requirements for commercial applications.
  • Stainless Steel Construction: Durable stainless steel actuator provides long-lasting performance and resistance to wear in high-traffic environments.
  • ADA Compliance: Meets accessibility standards with available variety of popular faceplate graphic options including alternative accessibility artwork.
  • Wireless Compatibility: Reduces installation time by eliminating the need to run wires from the push plate or use additional mounting hardware when used with BEA wireless transmitters.
  • Flexible Installation Options: Compatible with both surface and flush mount boxes for versatile mounting configurations.
  • Complete Kit Availability: Available in complete kits including plates, mounting boxes and optional wireless devices for simplified ordering and installation.
  • Enhanced Accessibility Design: Specifically engineered to improve overall access and enhance accessibility for users with limited mobility or disabilities.

Technical Specifications

  • Faceplate Material: 16 gauge, 304 2B Stainless Steel
  • Backplate Material: 1/8 inch thick, Aluminum
  • Mounting Screws: Stainless Steel, 6-32 x 1 in & 8-32 x 1 in Allen Head Size: 5/64
  • Cherry Switch: Single-pole, 15 A, COM / NO / NC, UL Recognized
  • Compatible Wireless Frequencies: 900, 433 or 300 MHz

Installation & Operation

  1. Verify electrical requirements match available power supply and confirm compatibility with existing automatic door operator system.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location using compatible surface or flush mount box ensuring adequate clearance for wiring access and user operation.
  4. Route and connect wiring according to manufacturer wiring diagrams for hardwired installation, or configure wireless transmitter connection per BEA specifications.
  5. Configure operational settings and test wireless connectivity if using wireless transmitter option per application requirements.
  6. Restore power and test all functions including push plate activation, door operator response, and integration with connected automatic door systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Automatic Door Systems
  • Healthcare Facility Accessibility Solutions
  • Educational Institution ADA Compliance
  • Retail Establishment Entry Systems
  • Government and Municipal Building Access
  • Multi-Tenant Residential Accessibility
  • Industrial Facility Automated Entry Points

Why Choose BEA Quality?

BEA electronic access control products deliver professional-grade reliability with stainless steel construction engineered for demanding commercial applications. The 10PBR6X series combines ADA compliance with flexible installation options including wireless compatibility to reduce installation complexity. Designed specifically to enhance accessibility while providing dependable automatic door activation performance in high-traffic environments.

Product Specs

Product Type:
Round Push Plates
Series:
10PBR6X
Subcategory:
Parts and Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Collection:
10PBR6X
Product Size:
6"
Product Category:
Electronic Access Control
Department:
Door Hardware

BEA 10PBR – Frequently Asked Questions

1) Will the BEA 10PBR6X round push plate work with my existing automatic door operator, or does it only work wireless?
Both ways. The 10PBR6X can be hardwired straight to the door operator, or paired with a BEA wireless transmitter so you don't have to pull wire to the plate location. The switch behind it is a single-pole Cherry switch, 15 A, with COM, NO and NC terminals, so it drops into a standard dry-contact activation input on an operator. Wireless versions work on 900, 433 or 300 MHz.
2) What mounting box do I need for a 6 inch BEA round push plate?
The 10PBR6X mounts to either a surface mount box or a flush mount box, so you can pick based on whether you're cutting into the wall or going on top of it. Mounting screws come with the plate: stainless steel 6-32 x 1 inch and 8-32 x 1 inch, Allen head, 5/64 size. If you go wireless with a BEA transmitter, you skip the extra mounting hardware entirely. Complete kits are also sold with plate, mounting box and the optional wireless device together.
3) Which faceplate graphic should I order on the BEA 10PBR6X push plate?
Five faces are offered: Blue Handicap Logo and Text, Blue Handicap Logo Only, Blue Text Only, Blue "PUSH TO OPEN" Text and Active Handicap Logo, and Plain Face. Pick the logo-and-text or PUSH TO OPEN version for a public accessible entrance where the actuator has to be identified. Plain Face is for interior or staff-side openings where you want the actuator to disappear into the wall, and the Active Handicap Logo version is the dynamic accessibility symbol some jurisdictions and institutions now standardize on.
4) Does a BEA push plate open the door by itself, or do I need more equipment?
The 10PBR6X is the actuator only, the thing a user presses. It sends a switch signal to a low energy or full power automatic door operator, which is what actually swings the door. Ordering the plate alone gets you a replacement or an added activation point on an existing automatic door; if there's no operator on the opening yet, you need the operator and its power supply too, plus a mounting box unless you're going wireless.
5) Is a 6 inch round push plate big enough, or should I use a 4-1/2 inch or a square plate?
6 inch round is the common size for a main accessible entrance, where the actuator has to be seen and hit easily from a wheelchair or with an elbow. The BEA 10PBR6X is that size. Smaller round plates suit tight jambs and narrow wall returns where a 6 inch disc won't sit flat; square plates are usually chosen to match existing square actuators already on a building so the openings look consistent. For a property manager standardizing a building, the deciding factor is usually matching what's already installed rather than the shape itself.
6) How durable is the BEA 10PBR6X in a high traffic hospital or school entrance?
The faceplate is 16 gauge, 304 2B stainless steel over a 1/8 inch thick aluminum backplate, which is why it holds up in entrances that get hit hundreds of times a day. The 304 stainless resists corrosion, so it also works on a vestibule or exterior-facing actuator. It's a commercial-rated product, not a residential one.
7) Can I wire the BEA 10PBR6X so it signals when released instead of when pressed?
Yes. The Cherry switch inside is single-pole with COM, NO and NC terminals, so you can land it normally open for a standard press-to-activate, or normally closed if your operator or interface board expects a break-to-signal input. It's rated 15 A and UL Recognized. Confirm which contact configuration your operator's activation input wants before you land the wires.
8) Do I need to run conduit to the push plate location for a BEA automatic door actuator?
Not if you use the wireless option. Paired with a BEA transmitter on 900, 433 or 300 MHz, the 10PBR6X needs no wire run back to the operator, which is what makes it workable on a retrofit where the actuator sits across an open vestibule or on a masonry wall you don't want to chase. Hardwired is still an option where you have a path for the cable.
9) What tool do I need to install a BEA 10PBR6X push plate?
A 5/64 Allen key. The plate ships with stainless steel 6-32 x 1 inch and 8-32 x 1 inch Allen head screws, and the two thread sizes cover both the surface and flush box patterns. The Allen head is deliberate: it makes the actuator tamper resistant in a public corridor compared to a Phillips head.
How fast can I get the BEA 10PBR delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the BEA 10PBR come with a warranty?
Absolutely. The BEA 10PBR is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the BEA 10PBR?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the BEA 10PBR from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
