IDEAL Industries Thermo-Shrink Heavy-Wall Heat Shrink, 4-3/0 AWG, 100 Pack

IDEAL Industries Thermo-Shrink Heavy-Wall Heat Shrink, 4-3/0 AWG, 100 Pack

(No reviews yet) Write a Review

Model: 46-351

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,403.37
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Thermo-Shrink® Heavy-Wall Heat Shrink, 6" Length, 4-3/0 AWG

  • Features

    • Adhesive liner provides complete insulation and protection to electrical splices in above-grade, underground or underwater applications
    • Maximum flame retardancy
    • Meets UL 486D, CSA C22.2 No. 198.2, ANSI C119.1, Western Underground Guides Nos. 2.4, 2.5, MIL-DTL-23053/15, IEEE 383 Vertical Flame Test, ANSI C37.20.2, ICEA S-19-8 and NEMA insulation thickness requirements
    • Rated for 600V, 90°C continuous use
    • TS-46 irradiated cross-linked polyolefin with 3:1 standard shrink ratio

Manufacturer Resources

Product Specs

Department:
Electrical
Pack size (unit):
100
Product Subgroup:
Electrical Sleeves
Product Type:
Heat Shrink Tubing
Product Group:
Cable Management & Identification

Ideal Industries 46-351 – Frequently Asked Questions

1) What wire sizes does the IDEAL Thermo-Shrink heavy-wall tubing cover?
The TS-46 heavy-wall Thermo-Shrink is sized for 4 AWG through 3/0 AWG conductors, so it covers typical secondary and service-size copper or aluminum splices. The 3:1 shrink ratio lets one size recover down over the smaller end of that range and still grip tight.
2) What voltage and temperature is the IDEAL TS-46 tubing rated for?
600V, with 90 C continuous operating temperature. That matches the insulation rating of most building wire and URD cable it would be spliced onto.
3) Which length should I order, the 6 inch or the 9 inch?
Two lengths are offered: 6 inch (46-351) and 9 inch (46-352). Pick the length by how long your splice body is plus the overlap you want onto the cable jacket on each end. Inline compression or crimp sleeves on 4 AWG usually sit fine in 6 inches; longer splice connectors, taped repairs, or splices where you want extra jacket coverage call for the 9 inch.
4) Is this the same as 3M FP-301 thin-wall shrink tubing?
No, they're different jobs. The IDEAL TS-46 is heavy-wall, adhesive-lined, cross-linked polyolefin for sealed power splices rated 600V and 90 C. The 3M FP-301 family we carry, including the FP301-2 black polyolefin thin wall and the FP301-332-TO-12 assorted size kit, is single-wall thin-wall tubing without an adhesive liner. Thin wall is for wire marking, strain relief, and dry-location insulation; it won't seal a buried or submerged splice.
5) Can 3M FP-301 heat shrink tubing be used in place of IDEAL Thermo-Shrink 46-351 for a direct-buried cable splice?
No. The IDEAL Thermo-Shrink TS-46 heavy-wall tubing is an irradiated cross-linked polyolefin with an adhesive liner that insulates and protects electrical splices in above-grade, underground or underwater applications, and it is rated 600V, 90 C continuous. The 3M FP-301 is a single wall, thin wall flexible polyolefin tubing with no adhesive liner, so it is not the equivalent for a sealed buried or submerged splice. Use the heavy-wall adhesive-lined IDEAL part for that opening.
6) Does the 3M FP301-2 black tubing carry the same flame and utility approvals as IDEAL Thermo-Shrink TS-46?
The IDEAL Thermo-Shrink TS-46 heavy-wall tubing is built to maximum flame retardancy and meets UL 486D, CSA C22.2 No. 198.2, ANSI C119.1, Western Underground Guides 2.4 and 2.5, MIL-DTL-23053/15, the IEEE 383 vertical flame test, ANSI C37.20.2, ICEA S-19-8 and NEMA insulation thickness requirements. The 3M FP301-2 is a black polyolefin thin wall tubing; where a drawing calls out those utility and NEMA insulation thickness requirements, specify the TS-46 heavy-wall part.
7) How many pieces come in a pack?
Sold 100 pieces per pack, in whichever length you pick. That is bulk-crew quantity rather than a single repair, so it suits a utility contractor or an MRO storeroom standardizing one splice cover across jobs.
8) Is this heat shrink flame retardant for use in cable trays or switchgear?
Yes. The TS-46 material is rated for maximum flame retardancy and passes the IEEE 383 Vertical Flame Test, and it meets ANSI C37.20.2, which is the switchgear standard. That combination is what gets it accepted in tray and gear applications where a non-rated tubing would not be.
9) I need heat shrink in long continuous rolls rather than cut pieces - what should I order?
The IDEAL Thermo-Shrink heavy-wall product is supplied as pre-cut 6-inch and 9-inch sleeves, 100 to a pack, for splice work. For continuous length tubing, the 3M FP-301 single wall line includes a 48-inch flexible polyolefin format in the assorted size kit, and the FP301 is also offered with a header label for shelf stock. Those are thin wall single wall products, so they do not replace the adhesive-lined heavy-wall sleeve on a sealed splice.
