IDEAL Industries 46-357 Thermo-Shrink® Heavy-Wall Heat Shrink, 12" Length, 4/0-400 MCM, 100 Pack

IDEAL Industries 46-357 Thermo-Shrink® Heavy-Wall Heat Shrink, 12" Length, 4/0-400 MCM, 100 Pack

(No reviews yet) Write a Review

Model: 46-357
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,513.59
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Thermo-Shrink® Heavy-Wall Heat Shrink, 12" Length, 4/0-400 MCM

  • Features

    • Adhesive liner provides complete insulation and protection to electrical splices in above-grade, underground or underwater applications
    • Meets UL 486D, CSA C22.2 No. 198.2, ANSI C119.1, Western Underground Guides Nos. 2.4, 2.5, MIL-DTL-23053/15, IEEE 383 Vertical Flame Test, ANSI C37.20.2, ICEA S-19-8 and NEMA insulation thickness requirements
    • Maximum flame retardancy
    • Rated for 600V, 90°C continuous use
    • TS-46 irradiated cross-linked polyolefin with 3:1 standard shrink ratio

Manufacturer Resources

Product Specs

Product Group:
Cable Management & Identification
Department:
Electrical
Product Subgroup:
Electrical Sleeves
Pack size (unit):
100
Product Type:
Heat Shrink Tubing

Ideal Industries 46-357 – Frequently Asked Questions

1) Can IDEAL 46-357 heat shrink be used on a direct-buried or submerged splice?
Yes. The adhesive liner inside the 46-357 tubing seals the splice for above-grade, underground, and underwater use, which is why it is specified for heavy-wall power cable work rather than plain non-lined tubing.
2) What voltage and temperature is the 46-357 Thermo-Shrink tubing rated for?
Rated 600V and 90 degrees C continuous. That covers secondary power and service splices; for medium-voltage cable you need an MV-rated splice kit, not this tubing.
3) How many pieces come in IDEAL part number 46-357?
46-357 is a 100 piece pack of 12 inch heavy-wall tubes. It is a stocking quantity for utility crews and MRO cribs, not a single-splice item, so order it where you are standardizing on one tube size across a lot of splices.
4) What material is IDEAL Thermo-Shrink 46-357 made from, and is it flame retardant?
It is TS-46 irradiated cross-linked polyolefin with maximum flame retardancy, and it passes the IEEE 383 Vertical Flame Test. Cross-linking is what lets the wall hold its shape and dielectric strength at the 90 degree C continuous rating.
5) Is heavy-wall adhesive-lined tubing like the 46-357 the right choice, or will thin-wall tubing do?
For a 4/0 to 400 MCM power splice that will sit underground or in water, heavy-wall with an adhesive liner is the correct type: the thick wall rebuilds insulation to NEMA thickness requirements and the liner seals out moisture. Thin-wall tubing has no sealant and no insulation-thickness rating, so it is for bundling, strain relief, and low-voltage identification only.
6) Will a 12 inch tube cover my splice, or do I need a longer piece?
Each 46-357 tube is 12 inches before recovery, which has to span the connector plus overlap onto sound jacket at both ends. Measure your connector length and planned overlap first; if the splice body plus overlap exceeds 12 inches, step up to a longer cut length in the same Thermo-Shrink heavy-wall family rather than butting two tubes together.
