INS NYL RING TERM, 4/0AN, 3/8, BLUE
Manufacturer Resources
Product Specs
- Country Of Origin:
- Mexico (MX)
- Product Subgroup:
- General Terminals
- Product Type:
- Nylon Insulated Ring Terminal
- Standards:
- UL E9809
- Voltage Rating:
- 600 V
- Wire Size:
- 4/0AN
- Department:
- Electrical
- Product Group:
- Wire Termination
- Product Color:
- Blue
- Product Material:
- Copper
Sta-Kon RM9731 – Frequently Asked Questions
1) What wire size does the Sta-Kon RM9731 ring terminal take?
The RM9731 is sized for 4/0 AWG conductor. It is a one-size barrel, so smaller cable will not crimp up properly in it and larger will not enter. If you are terminating 4/0 battery cable, feeder, or a grounding conductor, this is the right barrel.
2) Is the Sta-Kon RM9731 UL listed, and what voltage is it rated for?
It carries UL file E9809 and is rated 600 V, which covers standard commercial and industrial branch and feeder work up to 600 volts.
3) Is this ring terminal copper or aluminum, and can I use it on aluminum conductor?
The barrel is copper, so it is intended for copper conductor. Aluminum cable needs a terminal rated AL or AL/CU; putting aluminum into a copper-only barrel is a dissimilar-metal connection you do not want on a feeder.
4) What does the blue color on this Sta-Kon terminal mean?
Blue is the insulation color on the RM9731. On small insulated terminals blue is the industry color code for 16-14 AWG, but that code does not run to heavy lugs like this one: the barrel here is 4/0, so go by the stamped wire size, not the color.
5) Do I need a special crimper for a 4/0 Sta-Kon ring terminal?
Yes. A 4/0 copper barrel is well beyond hand-plier range; it takes a hydraulic or large mechanical lug crimper with the correct die for the barrel. A standard insulated-terminal hand tool will not make a code-quality crimp on this size, and the crimper and dies are a separate purchase from the terminal.
6) Is the insulation on this terminal nylon or vinyl?
Nylon. The RM9731 is a nylon insulated ring terminal, which holds up better to heat and abrasion than vinyl sleeving and is what most panel and switchgear specs call out.
7) Where is the Sta-Kon RM9731 made?
Mexico. That matters on public work where country of origin has to be documented for the submittal package.
