Sta-Kon RBC797 INS VINYL RING TERM 16-14 HVD 3/8IN

The RBC797 is sized for 16-14 AWG stranded copper conductors. Its green vinyl insulation sleeve is the color code for that gauge range on Sta-Kon terminals, so you can spot the right one in a mixed bin on the truck. Anything heavier than 14 AWG or lighter than 16 AWG needs a different terminal, since an out-of-range crimp will not hold mechanically.

Yes. The Sta-Kon RBC797 carries a 600 V rating, which covers typical commercial control panels, motor connections, and lighting circuits. It is also UL recognized under file E9809, which is what an institutional or MRO inspector will want to see on a terminated conductor.

A ring terminal like the RBC797 is the choice where the connection cannot be allowed to vibrate loose or pull off, because the conductor is captured all the way around the 3/8 inch stud. A fork or spade slides out from under a loosened screw, which is why it is used only where fast disconnection matters more than retention. For motor leads, grounding points, and anything subject to vibration, use the ring.

The RBC797 is a heavy-duty vinyl insulated ring terminal, meaning a thicker barrel and a heavier insulation sleeve than a standard-duty terminal of the same 16-14 AWG range. That matters where the lead gets flexed, pulled, or handled repeatedly, such as equipment leads and MRO repairs, rather than a one-time terminal strip hookup.

The barrel is copper, so the RBC797 is for copper conductors only. Crimping it onto aluminum wire creates a dissimilar metal joint that corrodes and loses contact pressure. Aluminum feeders need a terminal marked AL or AL9CU for that service.

Yes, use a crimp tool matched to insulated terminals in the 16-14 AWG range, with the die nest that corresponds to the green color code. A generic plier-style crimp can cut the vinyl sleeve or under-compress the copper barrel, and an under-crimped terminal is the usual cause of a joint that heats up later. The tool is a separate purchase, not supplied with the terminal.

Vinyl insulation is the general purpose sleeve material and is fine for normal panel and equipment temperatures, but it is not the choice for high heat. In an engine bay, a boiler room cabinet, or anywhere you would expect sustained elevated temperature, specify a nylon insulated or heat shrink insulated ring terminal in the same 16-14 AWG, 3/8 inch stud configuration instead.

Country of origin on the RBC797 ring terminal is the United States, which is what government, healthcare, and education procurement teams working to domestic preference requirements will need on the submittal.
