IDEAL Industries 830 Intermediate Heavy Duty Terminal Block

Ideal Industries 830 Intermediate Heavy Duty Terminal Block 155A/600V with Tubular Screw Contact

(No reviews yet) Write a Review

Model: 830
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$181.19
$131.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Ideal Industries 830 Intermediate Heavy Duty Terminal Block 155A/600V with Tubular Screw Contact

Professional electrical connection solution for demanding applications

The Ideal Industries 830 Intermediate Heavy Duty Terminal Block delivers reliable electrical connections with 155A/600V rating capacity. This professional-grade terminal block features nylon construction with painted finish, accommodating wire sizes from #12 to #1/0 AWG through its tubular screw contact design. The two-way mounting base provides versatile installation options for both channel and direct mounting configurations.

Professional Features & Benefits

  • 155A/600V Rating: Handles high-current applications with copper conductors for demanding electrical systems
  • Wide Wire Range (#12 to #1/0 AWG): Accommodates various conductor sizes for flexible installation requirements
  • Tubular Screw Contact Style: Provides secure mechanical connection with reliable electrical contact
  • Two-Way Mounting Base: Offers installation flexibility with channel or direct mount options
  • 105�C Temperature Rating: Withstands elevated operating temperatures for reliable performance
  • Nylon Construction with Painted Finish: Delivers durability and corrosion resistance in electrical environments
  • Full Accessory Line Available: Supports comprehensive system integration with compatible components

Technical Specifications

  • Cat Id: 830
  • Deparetment: Electrical
  • Description: Nylon, Tubular Screw,Painted, #12 to #1/0 AWG
  • Product Group: Outlets
  • Product Subgroup: GFCI Receptacles
  • Quantity: Box of 10
  • parent sku: IDL-830

Professional Applications

  • Industrial Control Panels and Electrical Enclosures
  • Commercial Building Electrical Systems
  • Manufacturing Equipment Connections
  • Power Distribution Applications
  • Motor Control Centers
  • Electrical Maintenance and Retrofit Projects

Why Choose Ideal Industries Quality?

Ideal Industries terminal blocks deliver proven reliability with professional-grade construction designed for demanding electrical applications. The 105�C temperature rating and robust nylon construction ensure long-term performance in challenging environments, while the comprehensive accessory line supports complete system integration needs.

Manufacturer Resources

Product Specs

Product Group:
Wire Connectors & Terminals
Department:
Electrical
Product Subgroup:
Terminal Blocks & Strips
Cat Id:
830
Description:
Nylon, Tubular Screw,Painted, #12 to #1/0 AWG
parent sku:
IDL-830
Item Quantity:
Box of 10
Product Type:
Terminal Block

Ideal Industries 830 – Frequently Asked Questions

1) What wire sizes does the Ideal 830 terminal block accept?
The Ideal 830 intermediate heavy duty terminal block takes copper conductors from #12 AWG up to #1/0 AWG in its tubular screw contacts. That range covers everything from control wiring on the small end to feeder-size conductors in a panel, so one block type can handle a mixed pull. Anything smaller than #12 or larger than #1/0 needs a different block.
2) Is the Ideal 830 terminal block rated for 600V circuits?
Yes, the 830 is rated 155A at 600V with copper conductors, which puts it in range for industrial control panels, motor control centers, and power distribution work at standard commercial voltages. The 155A figure is the limiting number for most installs, so size the block to the actual conductor ampacity you are landing.
3) Is the Ideal 830 a GFCI receptacle or a terminal block?
It is a terminal block, not a receptacle. The 830 is an intermediate heavy duty block with tubular screw contacts that lands and joins conductors inside a panel or enclosure. It provides no ground-fault protection and no plug outlet of any kind.
4) Can the Ideal 830 block be mounted on channel, or does it have to be screwed directly to a panel?
Either. The 830 has a two-way mounting base, so it can sit on channel or be direct mounted to a subpanel or enclosure back plate. That matters when you are retrofitting into an existing enclosure where the mounting method is already set by what is in there.
5) How many Ideal 830 terminal blocks come in a box?
The 830 ships as a box of 10. If you are standardizing a panel build or stocking for MRO, order in multiples of ten rather than by the piece.
6) What part number do I order for the Ideal intermediate heavy duty 155A terminal block?
Order Ideal Industries 830. That is the catalog number and the manufacturer part number for the nylon, tubular screw, painted intermediate block taking #12 to #1/0 AWG.
7) What is the Ideal 830 terminal block made of, and will it hold up in a damp or corrosive panel?
Body is nylon with a painted finish. Nylon gives you a non-conductive, impact-tolerant housing and the painted metal parts resist corrosion in typical electrical environments. For genuinely wet or washdown locations, the enclosure rating is what protects the block, not the block itself.
