International Door Closers 9000 Series - 9001-P Surface Door Closer, 1-6 Adjustable Spring Power, Adjustable Back Check, Delayed Action

International Door Closers 9000 Series - 9001-P Surface Door Closer, 1-6 Adjustable Spring Power, Adjustable Back Check, Delayed Action

(No reviews yet) Write a Review

Model: 9001-P-AL
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$154.00
$141.74
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

International Door Closers 9000 Series - 9001-P Surface Door Closer, 1-6 Adjustable Spring Power, Adjustable Back Check, Delayed Action

FEATURES

  • Model 9001-TP: Adjustable spring power (1-6) Opening Force with adjustable back check and delayed action controlled by a separate regulating valve.
  • ADA (Handicap) multi-sized closer with adjustable Spring Power for a range of sizes adjustable after installation.
  • Two Speed Control Valves: Closing and Latching speeds controlled by separate regulating valves, adjustable after installation.
  • Universal Application: Non handed for standard, top jamb or parallel arm installation (parallel arm bracket included).
  • Rack and pinion mechanism contained in a high tensile precision cast aluminum housing.
  • Stable hydraulic door check fluid for any climatic operation and constant lubrication.
  • Furnished with a high impact molded PVC Dress Cover (door closer body casting is finished for use without the dress cover).
  • Optional hold-open arms available. • Hold-open arms are adjustable for holding from 90° to 180°

Manufacturer Resources

Product Specs

Product Group:
Door Closers
Product Subgroup:
Door Closers - Surface Mounted
Product Type:
Surface Mounted Door Closers
ADA Compliant:
Yes
Series:
9000 Series
Subcategory:
Door Closers - Surface Mounted
Closer Arm Type:
Regular Arm
Product Model:
9001-P
Door Hand Direction:
Non-Handed
Delay Function:
Yes
Product Category:
Doors Closers
Department:
Door Hardware

International Door Closers 9001-P-AL – Frequently Asked Questions

1) Do I need to order a left-hand or right-hand version of the IDC 9001-P door closer?
Neither. The 9001-P is non-handed, so one closer covers both left and right hand openings. It mounts three ways: regular (pull side), top jamb, or parallel arm, and the parallel arm bracket comes in the box.
2) Can one 9001-P closer cover different door sizes, or do I have to order by size?
One unit covers the range. Spring power is adjustable from 1 through 6, set with a screw after the closer is hung, so the same closer can be dialed down for a light interior door or up for a heavier exterior one. For a property manager standardizing across a building, that means stocking a single model instead of a size-specific closer per opening.
3) Is this door closer ADA compliant for an accessible entrance?
The 9001-P is listed as ADA compliant and is built as a multi-sized closer with adjustable spring power specifically so opening force can be brought down to an accessible level after the door is hung. That adjustability is what lets you tune the opening force on site rather than swapping hardware.
4) What is delayed action on a door closer and do I need it?
Delayed action holds the door open briefly at the start of the closing cycle before it begins to swing shut, which gives someone with a cart, a wheelchair, or an armload of supplies time to get through. On the 9001-P it runs off its own separate regulating valve, so you set the delay independently of closing and latching speed. It's worth having on healthcare, school, and multi-family corridor doors; on a light office door it is usually unnecessary.
5) What adjustments can be made after the closer is installed?
Four, all by valve or screw with the closer in place: spring power 1 to 6, closing speed, latching speed, and back check. Closing and latching run on separate regulating valves, and delayed action has its own valve as well. Nothing here requires taking the closer off the door to retune it.
6) Will this closer stop the door slamming into the wall when someone throws it open?
Back check is what handles that, and the 9001-P has it, adjustable. Back check cushions the door near the end of the opening swing so wind or a hard push doesn't drive the door or arm into the adjacent wall. It is not a substitute for a stop, though; on exposed exterior openings still use a floor or wall stop as the mechanical limit.
7) Does the 9001-P hold the door open, and can I add a hold-open arm later?
The standard 9001-P ships with a regular arm, which does not hold open. Hold-open arms are offered as an option for the 9000 Series and are adjustable to hold anywhere from 90 to 180 degrees. If you want hold-open on a stairwell or fire-rated opening, check your local code first, since hold-open on those doors normally has to be an electrified or fusible arrangement.
8) When should I use parallel arm mounting instead of regular arm on this closer?
Parallel arm puts the closer on the push side of the door with the arm folded back against the face, which keeps it out of the opening and protects it from abuse, common on corridor and exterior out-swinging doors. Regular arm mounts on the pull side and generally gives the most efficient power. Top jamb goes on the frame face when the door itself has no room for the body. The 9001-P supports all three and includes the parallel arm bracket, so the mounting decision is made in the field, not at the order.
9) Does the cover come with it, and what finish is the closer body?
A high impact molded PVC dress cover is furnished with the closer. The body casting is finished on its own, so you can run the closer without the cover if you prefer the exposed industrial look or if covers keep walking off in a high-traffic corridor. The finish offered is aluminum.
10) Will this closer work on an exterior door in cold weather?
It is filled with a stable hydraulic door check fluid intended for operation across climates, which keeps closing speed from drifting badly between a hot afternoon and a cold morning, and keeps the internals lubricated. The mechanism is rack and pinion inside a high tensile precision cast aluminum housing. For an exterior opening, also set the back check so wind gusts don't overrun the arm.
