Leviton Decora Plus Commercial Grade Duplex Receptacle, 20-Amp 125-Volt NEMA 5-20R, White

Leviton Decora Plus Commercial Grade Duplex Receptacle, 20-Amp 125-Volt NEMA 5-20R, White

(No reviews yet) Write a Review

Model: 16342-W
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.15
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton Decora Plus Commercial Grade Duplex Receptacle, 20-Amp 125-Volt NEMA 5-20R, White

The Leviton Decora Plus™ Duplex Receptacle is a commercial grade, heavy-duty, impact-resistant straight blade device built for demanding electrical environments. Rated 20-Amp, 125-Volt with a NEMA 5-20R configuration, this White finish receptacle delivers the durability and consistent performance electrical contractors expect from Leviton's Decora Plus line. Its rugged construction is engineered to withstand repeated impact and heavy daily use in commercial and light-industrial settings, making it a dependable choice wherever code-compliant, high-traffic devices are required for long-term, day-to-day reliability.

Key Features

  • Electrical Rating: 20-Amp, 125-Volt for reliable operation on standard commercial circuits.
  • NEMA Configuration: NEMA 5-20R straight blade design accepts both 15-amp and 20-amp plugs for versatile compatibility with common cord-and-plug equipment.
  • Commercial Grade: Built to commercial grade specifications for demanding, high-traffic electrical applications where device longevity matters.
  • Heavy-Duty, Impact-Resistant Housing: Reinforced construction resists cracking and impact damage in rugged work environments and busy commercial spaces.
  • Decora Plus™ Design: Part of Leviton's Decora Plus series, offering a clean, modern device profile that pairs with Decora Plus wallplates and system components for a coordinated installation.
  • Duplex Configuration: Dual outlet design provides two independent points of connection from a single device, maximizing usable outlets per wallbox.
  • Finish: White housing for a clean, versatile appearance that coordinates with standard commercial interior finishes.

Technical Specifications

  • Amperage: 20A
  • Voltage: 125V
  • Product Color: White

Typical Applications

  • Commercial and Light-Industrial Electrical Installations
  • Office Buildings and Retail Spaces
  • Equipment Rooms and Break Areas Requiring 20-Amp Circuits
  • Renovation and New Construction Wiring Projects
  • High-Traffic Areas Requiring Impact-Resistant Devices

Why Leviton?

Leviton's Decora Plus commercial grade devices are engineered for contractors and facility managers who need dependable, code-compliant performance day after day. The heavy-duty, impact-resistant construction of this 20-Amp, 125-Volt NEMA 5-20R duplex receptacle reflects Leviton's focus on rugged reliability, making it a trusted choice for commercial electrical installations that demand consistent, long-term performance across offices, retail spaces, and light-industrial facilities.

Manufacturer Resources

Technical Information

Product Specs

Product Type:
Receptacle
Connection Type:
Straight Blade
Amperage Rating:
20A
Voltage Rating:
125V
NEMA Rating:
5-20R
Grade:
Commercial
Product Color:
White
Department:
Electrical
Product Group:
Outlets
Product Subgroup:
Switches & Receptacles

Leviton 16342-W – Frequently Asked Questions

1) Will a Leviton 16342 20-amp receptacle accept a regular 15-amp plug, or only 20-amp T-blade cords?
Both. The 16342 is a NEMA 5-20R straight blade duplex, and that face takes standard 15-amp parallel-blade plugs as well as 20-amp T-blade cords. So a break room fed by a 20-amp circuit can run a microwave with a T-blade cord and everyday office equipment from the same device.
2) Can I put a 20-amp 5-20R receptacle like the Leviton 16342 on a 15-amp branch circuit?
No. A 5-20R face belongs on a 20-amp circuit with 12 AWG conductors and a 20-amp breaker, because it tells a user the outlet will carry a 20-amp load. On a 15-amp circuit you want a 15-amp 5-15R device instead. The 16342 is rated 20A at 125V, which is the standard commercial circuit it is built for.
3) Do I need a special wallplate for a Decora Plus receptacle, or will a standard duplex cover fit?
You need a decorator or rectangular opening plate, not the old figure-eight duplex cover. The 16342 is a Decora Plus device, so it takes any standard Decora-style wallplate, in one, two or more gangs depending on the box. A round-hole duplex plate will not fit over it.
4) I am replacing a cracked outlet in an office. Will the Leviton 16342 fit the same box and wires?
If the existing device is a decorator-style outlet on a 20-amp circuit, yes, the 16342 drops into the same single-gang box on the same strap. Two things to check before you swap: the circuit must be 20-amp for the 5-20R face to be correct, and the existing wallplate has to be a decorator opening. If the old outlet is the traditional two-round-hole style, plan on a new plate as well.
5) What colors does the Leviton Decora Plus 16342 receptacle come in, and what is the part number for each?
Four colors, each its own part number: White is 16342-W, Ivory is 16342-I, Gray is 16342-GY, and Black is 16342-E. The suffix is the only thing that changes, so you can standardize a building on one device and still match the trim color room to room.
6) Is the Leviton 16342 commercial grade or spec grade, and is it tough enough for a high-traffic lobby or retail floor?
Commercial grade. The Decora Plus 16342 uses a heavy-duty impact-resistant body meant for repeated abuse in commercial and light-industrial space, which is the level a property manager should be putting in corridors, retail floors and break areas rather than a residential-grade device. For equipment rooms and shop areas where cords get yanked daily, this is the right tier.
7) Is the Leviton 16342 a GFCI or tamper-resistant receptacle?
Neither. The 16342 is a straight blade commercial duplex, so it has no built-in ground fault protection and no shutter mechanism. In a location that requires GFCI protection, either feed it from a GFCI device upstream or a GFCI breaker, and where a facility type calls for tamper resistance, specify a TR-marked device instead.
8) Does the Leviton 16342 duplex give me two separately usable outlets, and can I split it between two circuits?
The 16342 is a duplex, so you get two independent connection points from one box, which is what you want where a single opening has to feed a desk and a printer. Nothing in the device data describes a break-off tab for split-wiring, so treat it as a standard duplex fed from one 20-amp, 125V circuit and plan a second device where you truly need two circuits.
9) Where can I get the spec sheet for the Leviton 16342 for a submittal?
Leviton publishes technical information for this Decora Plus device, and ZenSupply hosts it at https://zensupply.com/content/pdf/leviton/technical-information-e24200.pdf. For the submittal itself, the numbers a reviewer usually wants are on the face of the order: 20A, 125V, NEMA 5-20R, commercial grade, with the color called out by suffix such as 16342-GY for gray.
