Leviton 1-Pole Duplex AC Combination Switch with Neon Pilot Light, White

The Leviton 1-Pole Duplex AC Combination Switch with Neon Pilot Light combines a 15-Amp, 120/277-Volt AC single-pole switch with a NEMA 5-15R duplex receptacle on a single device yoke, finished in White. A built-in 120-Volt AC neon pilot light provides an at-a-glance indication of switch status, making this combination device a practical solution wherever load control and a standard plug-in outlet are needed at the same location. This space-saving wiring device is well suited to both retrofit and new construction electrical work.

Key Features

  • Combination Design: Integrates a 1-Pole AC switch and a duplex NEMA 5-15R receptacle in a single device, saving box space and installation time.
  • Neon Pilot Light: A 120-Volt AC neon pilot light indicates when the switch is energized, useful for remotely located loads such as exhaust fans or exterior lighting.
  • Switch Rating: AC switch rated 15-Amp at 120/277-Volt AC for reliable control of lighting and general-purpose circuits.
  • Receptacle Configuration: Duplex outlet rated NEMA 5-15R for standard 120-Volt straight-blade plugs.
  • Single-Pole Operation: 1-Pole switching allows straightforward on/off control from a single location.
  • Space-Saving Wiring Device: Combines two functions in one device, reducing the number of openings needed in a wallbox.
  • Finish: Clean White finish suited to standard residential and commercial decor.

Technical Specifications

  • Product Type: Combination Switch/Receptacle
  • Amperage: 15A
  • Voltage: 120/277V
  • Poles: 1
  • Product Color: White

Typical Applications

  • Residential and Commercial Lighting Control
  • Combination Switch and Receptacle Installations
  • Rooms Requiring Both Switching and a Plug-In Outlet at One Location
  • Retrofit and New Construction Wiring Projects
  • Exhaust Fan, Utility, and Equipment Circuit Control with Local Outlet Access

Why Leviton?

Leviton wiring devices are engineered to deliver dependable, code-compliant performance for both switching and receptacle needs in a single footprint. This 1-Pole Duplex AC Combination Switch with Neon Pilot Light reflects Leviton's focus on practical, space-saving device design for professional electrical installations, backed by clearly defined 15-Amp, 120/277-Volt AC switch and NEMA 5-15R receptacle ratings that electricians and specifiers can rely on.

[{"name": "Product Type", "value": "Combination Switch/Receptacle"}]

Manufacturer Resources

Technical Information

Product Specs

Product Type:
Switch/Pilot Light Combination
Amperage Rating:
15A
Voltage Rating:
120/277V
Poles:
1
Nema Rating:
5-15R
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Combination Devices

Leviton 5226-W – Frequently Asked Questions

1) Can the Leviton 5226 combination switch and receptacle be used on a 277V lighting circuit?
The switch half is rated 15A at 120/277V AC, so the switch can control a 277V lighting load. The receptacle half is a NEMA 5-15R, which is a 125V straight-blade outlet and cannot be fed at 277V. If you run the switch at 277V you need to feed the receptacle from a separate 120V source, and the internal tab between the two halves has to be broken so they are on independent feeds.
2) What does the neon pilot light on the Leviton 5226 indicate, and does it need a neutral?
The 120V AC neon pilot glows when the switch is on, so you can tell from the wall that a remote load, an attic exhaust fan or an exterior fixture for example, is energized. A lit pilot lamp draws current on its own, so the device needs a neutral in the box. Plan on pulling a neutral to the box if the existing switch leg is a two-wire run with no white conductor.
3) Is the switch on this Leviton combination device single pole or three way?
Single pole, one pole only. The 5226 gives on/off control from one location. If you need to control the same light from two places, this device won't do it and you need a three-way switch at each end instead.
4) Do I need a single-gang or two-gang box for the Leviton 5226 switch/receptacle combo?
One single-gang opening. The switch and the duplex 5-15R outlet share a single device yoke, which is the point of the part: two functions where a two-gang box would otherwise be required. It takes a standard single-gang cover plate cut for a combination device, not a plain toggle or duplex plate.
5) Can the switch on the 5226 control the receptacle below it?
It can be wired either way. As shipped the two halves are commoned by a tab, so the switch and the outlet are fed from the same hot and the outlet is always live. Break the tab and you can feed the outlet from the switched side instead, making it a switch-controlled outlet, or feed the two halves from entirely separate circuits. The pilot light follows the switch either way.
6) Will a 15A combination switch/receptacle work on a 20A branch circuit?
A 15-amp device like the 5226 is permitted on a 20-amp branch circuit where more than one receptacle is on that circuit, which is the ordinary case in a residential or commercial lighting and general-purpose run. What it will not do is serve as the single receptacle on a dedicated 20A circuit, or accept a 20A T-slot plug. For a 20A appliance receptacle you need a 5-20R device instead.
7) Is this Leviton combo device a good fit for a bathroom exhaust fan with an outlet at the same spot?
That's one of the jobs it's built for. You get single-pole control of the fan, a pilot light so nobody leaves an attic or inline fan running unnoticed, and a 5-15R outlet at the same box. Note the outlet half is a standard duplex, not GFCI, so in any location where code requires GFCI protection you'll need to protect it from an upstream GFCI breaker or receptacle.
8) What colors does the Leviton 5226 combination switch come in?
Two: White, ordered as 5226-W, and Ivory, ordered as 5226-I. If you are matching a run of existing devices in a building, the suffix is the only difference between the two part numbers.
