Leviton Pin & Sleeve Receptacle, 100A 125/250V IP67
The Leviton Pin & Sleeve Receptacle is a heavy-duty, Industrial Grade device engineered for demanding power distribution applications. Rated 100 Amp, 125/250 Volt, this 3P, 4W (three-pole, four-wire) receptacle is built to the IEC 309-1 & 309-2 standard with a North American pin & sleeve mechanical interlock configuration. Finished in a distinctive orange housing and rated IP67 watertight, it is a non-fused design suited for temporary power, construction, and industrial equipment hookups. A mating hub is sold separately (see Leviton HUB-xxx catalog numbers).
Key Features
- Electrical Rating: 100 Amp, 125/250 Volt rating supports high-capacity industrial power distribution circuits.
- Pole/Wire Configuration: 3P, 4W configuration delivers three-phase power with a dedicated neutral/ground conductor.
- Standard Compliance: Built to IEC 309-1 & IEC 309-2 pin & sleeve standards for interoperable connections with compatible plugs.
- Mechanical Interlock: North American pin & sleeve mechanical interlock design helps prevent disconnection under load for improved operator safety.
- Watertight Protection: IP67 rating provides reliable sealing against dust and water for outdoor and wash-down environments.
- Industrial Grade Construction: Industrial Grade build quality is designed for durability in heavy-duty commercial and industrial settings.
- Non-Fused Design: Non-fused receptacle simplifies installation where overcurrent protection is provided upstream in the distribution system.
- Finish: Orange housing offers high visibility and easy identification of pin & sleeve devices in industrial environments.
Certifications & Compliance
- IEC 309-1 Compliant
- IEC 309-2 Compliant
- IP67 Watertight Rated
- Industrial Grade
Technical Specifications
- list_batch: 377-VARMACHINE-20260803
- Amperage: 100A
- Voltage: 125/250V
- Poles/Wires: 3P, 4W
- Standard: IEC 309-1 & 309-2
- Ingress Protection: IP67, Watertight
- Fuse Type: Non-Fused
- Mating Hub: Sold Separately (See Leviton HUB-xxx)
- Color: Orange
Typical Applications
- Industrial Power Distribution
- Temporary Power Hookups on Construction Sites
- Outdoor and Wet-Location Equipment Connections
- Wash-Down and Marine Environments
- Heavy Equipment and Machinery Power Supply
- Industrial and Commercial Renovation Projects
Why Leviton?
Leviton engineers its pin & sleeve receptacles to Industrial Grade standards, delivering the IP67 watertight protection and IEC 309-1 & 309-2 compliance that professionals rely on for safe, code-compliant power distribution in demanding environments. The mechanical interlock design, non-fused construction, and rugged orange housing reflect a focus on durable, dependable electrical connectivity for industrial and construction power applications.
Manufacturer Resources
Product Specs
- Product Type:
- Pin and Sleeve Receptacle
- Connection Type:
- Mechanical Interlock
- Listing:
- IEC 309-1 & 309-2
- Product Finish:
- Orange
- Department:
- Electrical
- Product Group:
- Wiring Devices
- Product Subgroup:
- Pin & Sleeve Devices
Leviton GFA15-100 – Frequently Asked Questions
1) Do I need to buy anything else to mount a Leviton 100A pin and sleeve receptacle?
Plan on a hub. The Leviton 100A pin and sleeve receptacle ships without one, and the mating hub is ordered separately under the Leviton HUB series catalog numbers. The device itself is non-fused, so overcurrent protection has to come from upstream in the distribution gear. Between the hub and the branch protection, that is the part of the job people forget when they order the receptacle by itself.
2) Will an IEC 309 plug from another manufacturer mate with a Leviton pin and sleeve receptacle?
It will, provided the plug is the same IEC 309 configuration. The Leviton pin and sleeve receptacle is built to IEC 309-1 and 309-2, which is a dimensional standard for pin and sleeve devices, so plugs of matching amperage, voltage and pole/wire arrangement from other IEC 309 makers engage it. Match the configuration, not just the brand: this one is 100A, 125/250V, 3-pole 4-wire, and a plug of a different rating physically will not go in.
3) Can a pin and sleeve receptacle be used outdoors or in a wash-down area?
Yes, this one carries an IP67 watertight rating, which covers dust ingress and temporary immersion, so it holds up in outdoor, wet-location and wash-down service. That is the reason it shows up on construction temporary power and on food-processing and marine equipment hookups rather than a standard dry-location receptacle.
4) Should I use a pin and sleeve device or a standard twist-lock for a 100A equipment hookup?
At 100A a twist-lock is not in the running; locking receptacles top out well below that, and pin and sleeve is the connector class used for high-capacity industrial power distribution. The Leviton 100A pin and sleeve is rated 125/250V, 3-pole 4-wire, with a mechanical interlock so the connection cannot be pulled apart under load. For lighter portable loads a locking device is the simpler choice, but for feeder-size temporary power or heavy machinery this is the right family.
5) What does the mechanical interlock on a Leviton pin and sleeve receptacle actually do?
The interlock ties the plug to the receptacle mechanically so the plug cannot be withdrawn while the connection is live and under load. On a 100A circuit that matters, because breaking that current at the pins is what arcs. It is a mechanical, non-fused design, so the switching and overcurrent duty stays in the upstream distribution equipment.
6) Is a non-fused pin and sleeve receptacle acceptable for temporary construction power?
It is the normal arrangement. The Leviton 100A pin and sleeve receptacle is a non-fused device, meaning it makes and holds the connection while the branch or feeder protection sits upstream in the panel or temporary power distribution unit. If your setup has no upstream protection at that point, you need a fused or breakered distribution assembly ahead of this receptacle, not a different receptacle.
7) Why is the pin and sleeve receptacle orange, and does the color mean anything?
Orange is the housing color on this Leviton pin and sleeve receptacle, chosen for visibility so the device is easy to pick out in an industrial space. Treat it as identification, not as a rating: confirm the fit from the printed configuration, 100A 125/250V 3-pole 4-wire built to IEC 309-1 and 309-2, rather than from the color of the shell.
