Leviton Decora USB Type A/Type-C Duplex Receptacle & Charger, 20-Amp 125V, Black

The Leviton T5833-E is a Decora-style combination duplex receptacle and USB Type A/Type-C charger, rated 125-Volt AC and 20-Amp with a NEMA 5-20R configuration, finished in Black. This device merges standard AC outlet power with integrated USB Type A and Type-C charging ports on a single wiring device, letting homeowners and electrical professionals plug in traditional equipment while charging phones, tablets, and other USB-powered electronics without a separate wall adapter. Built on Leviton's Decora platform, it delivers the clean, modern face style that coordinates with the broader Decora device and wallplate family, making it a practical retrofit or new-construction upgrade for any room where convenient charging is needed alongside standard power.

Key Features

  • Combination Design: Integrates a duplex receptacle with a USB Type A/Type-C charger on one device, combining standard AC power and USB charging in a single gang space.
  • Electrical Rating: Rated 125-Volt AC, 20-Amp, NEMA 5-20R, suitable for standard residential and commercial branch-circuit wiring.
  • Decora Styling: Features Leviton's Decora design language for a clean, modern appearance that matches Decora wallplates, switches, and dimmers.
  • Dual USB Charging Ports: USB Type A and Type-C ports on the same device support simultaneous charging of multiple device types without bulky plug-in adapters cluttering the outlet.
  • Duplex Outlet Configuration: Retains two standard NEMA 5-20R AC outlet positions in addition to the USB charging ports, so existing plugs and cords still have a home.
  • Space-Saving Convenience: Eliminates the need for separate USB charging blocks or power strips by building charging capability directly into the wall device.
  • Finish: Black finish coordinates with a wide range of Decora wallplate and device color schemes.

Technical Specifications

  • Amperage: 20A
  • Voltage: 125V
  • Product Color: Black

Typical Applications

  • Residential Kitchens, Bedrooms, and Home Offices
  • Commercial Workstations and Conference Rooms
  • Hospitality and Multi-Family Housing Upgrades
  • Renovation and New Construction Wiring Projects
  • Charging Stations for Mobile Devices and Tablets
  • Shared Workspaces and Co-Working Environments

Why Leviton?

Leviton is a well-established name in electrical wiring devices, and this combination receptacle/USB charger reflects the brand's focus on practical, code-compliant devices built for modern power and charging needs. With its 125-Volt, 20-Amp, NEMA 5-20R electrical rating and signature Decora design, this device is built to deliver dependable everyday performance for electrical contractors, designers, and homeowners who want integrated charging without sacrificing standard outlet capacity. Choosing Leviton for this upgrade means pairing a trusted wiring device brand with the added convenience of built-in USB Type A and Type-C charging.

Manufacturer Resources

Technical Information

Product Specs

Product Type:
Receptacle
Connection Type:
USB Type A/Type-C Charger
Amperage Rating:
20A
Voltage Rating:
125V
NEMA Rating:
5-20R
Product Color:
Black
Product Finish:
Black
Department:
Electrical
Product Group:
Outlets
Product Subgroup:
Switches & Receptacles

Leviton T5833-W – Frequently Asked Questions

1) Can the Leviton T5833 USB receptacle go on a 20-amp kitchen circuit?
Yes. The T5833 Decora combination receptacle is rated 20A at 125V with a NEMA 5-20R face, so it is the right device for a 20-amp branch circuit such as a kitchen small-appliance or workstation circuit. The 5-20R slot pattern also accepts standard 5-15P plugs, so everyday cords still plug in normally.
2) Does the Leviton T5833 have USB-C, or just the older USB-A ports?
Both. The T5833 carries one USB Type A port and one USB Type-C port on the same device, alongside the two AC outlet positions. That covers older Type-A cables and newer USB-C phones and tablets without a plug-in brick sitting in the outlet.
3) Can I replace an existing 15-amp outlet with the Leviton T5833?
Only if the circuit and wiring actually support 20 amps. The T5833 is a 5-20R device, and a 5-20R receptacle belongs on a 20A circuit with 12 AWG conductors. If the box is fed by a 15A breaker on 14 AWG, you need a 15A (5-15R) USB combination device instead, not this one.
4) What colors does the Leviton T5833 USB receptacle come in?
Three: Black (T5833-E), Gray (T5833-GY), and White (T5833-W). All three are the same 20A, 125V device, so on a multi-unit or hospitality job you can match whatever Decora scheme is already on the walls without changing the electrical spec.
5) Will a standard Decora wallplate fit the Leviton T5833 USB charging outlet?
Yes. It is built on Leviton's Decora platform with the standard Decora rectangular opening, so any Decora/GFCI-style wallplate covers it. That is the same plate used on Decora switches and dimmers, which is what lets a run of devices in a room stay uniform.
6) Do I need a separate USB circuit or low-voltage wiring for this outlet?
No. The T5833 wires like an ordinary receptacle off the 125V branch circuit; the USB charging electronics are built into the device. There is no transformer, no low-voltage home run, and no extra gang required, which is why it works as a straight swap in a renovation.
7) Where does the Leviton T5833 make sense on a commercial or multi-family job?
It suits spots where people charge phones at the wall but still need the outlet: conference rooms and workstations, hotel and apartment bedrooms, kitchens, and shared co-working desks. Putting the charger in the device removes the plug-in bricks that otherwise block the second outlet position, and the 20A rating keeps it usable on general branch circuits.
8) Where can I find the full technical data on the Leviton T5833?
Leviton publishes a technical information sheet for the device, hosted at https://zensupply.com/content/pdf/leviton/technical-information-dc7646.pdf. That is the reference for wiring detail beyond the headline 20A, 125V, NEMA 5-20R rating.
