Spec Sheet
Product Specs
- Light Unit Type:
- Incandescent, full voltage
- Series:
- 10250T
- Voltage Rating:
- 12 Vac/dc
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty
- Product Length:
- 2.4 IN
- Product Details:
- 30.5 mm, Heavy-Duty
- Product Height:
- 3.2 IN
- Product Weight:
- .1 LB
- Product Width:
- 2.1 IN
B-LINE 10250T70 – Frequently Asked Questions
1) What voltage is the B-Line 10250T70 light unit for illuminated push-pull devices?
The 10250T70 is a 12 Vac/dc full voltage incandescent light unit. Full voltage means the lamp runs directly at the circuit voltage with no internal transformer, so your control circuit has to be 12 volts AC or DC. Feeding it 120 V will destroy the lamp.
2) Will a 10250T70 light unit fit a 30.5 mm panel cutout?
Yes. The 10250T70 is part of the 10250T heavy-duty 30.5 mm line, so it is built for the standard 30.5 mm (1-3/16 inch) pushbutton hole used on industrial control panels and enclosures.
3) Can I use the 10250T70 as a replacement lamp unit on an existing 10250T illuminated push-pull station?
That is exactly what it is for. Because it is a 10250T series 30.5 mm heavy-duty light unit, it goes back into the same family of illuminated push-pull operators. The one thing to confirm on the old unit is voltage: this one is 12 Vac/dc full voltage, so if the existing station was wired for a different control voltage it is not a straight swap.
4) Is this an LED light unit?
No, it is incandescent. If your maintenance standard calls for LED lamp units to cut relamping on a machine line, this is not that part. Incandescent full voltage units like this one do give you a simple 12 V lamp with no driver electronics to fail.
