Milbank 200 Amp 6-Position Ringless Meter Socket with 4 Terminal Large Closing Plate

Milbank 200 Amp 6-Position Ringless Meter Socket with 4 Terminal Large Closing Plate

Professional Multi-Position Metering Solution for Commercial Applications

The Milbank 200 Amp 6-Position Ringless Meter Socket delivers reliable multi-position metering with 4 terminal configuration and large closing plate design. Constructed with G90 galvanized steel and powder coat finish for durability, this UL Listed Type 3R surface mount unit accommodates 6 AWG to 350 kcmil load side wire range for versatile commercial and multi-unit installations.

Professional Features & Benefits

• 200 Continuous Ampere Rating: Provides robust capacity for demanding commercial and multi-unit metering applications with reliable continuous service.
• 6-Position Configuration: Accommodates multiple meter installations in a single enclosure, maximizing efficiency and reducing installation footprint.
• 4 Terminal Ringless Design: Eliminates the need for meter rings while providing secure connections and simplified maintenance access.
• G90 Galvanized Steel Construction: Delivers superior corrosion resistance and long-term durability with professional powder coat finish.
• Type 3R Rating: Ensures reliable outdoor performance with protection against rain, sleet, and ice formation.
• Flexible Wire Range: Accepts 6 AWG to 350 kcmil conductors, providing installation flexibility for various load requirements.
• UL Listed Certification: Meets rigorous safety and performance standards for professional electrical installations.

Technical Specifications

• Amperage Rating: 200 Continuous Ampere
• Application: Meter Socket
• Brand Name: Milbank
• Departent: Electrical
• Frequency Rating: 60 Hertz
• Hub Closing Plate: Large Closing Plate
• Load Side Wire Range: 6 AWG - 350 kcmil
• Main Breaker Size: No Main Breaker
• Number Of Jaws: 4 Terminal
• Number Of Main Breakers: 0
• Number Of Meter Positions: 6 Positions
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: G200
• Product Height: 18 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Type: Ringless Meter Socket
• Standard: UL Listed;Type 3R
• Unspsc Number: 39121102
• Voltage Rating: 300 Volts Alternating Current

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Multi-Unit Residential Properties
• Commercial Buildings
• Retail Centers
• Office Complexes
• Industrial Facilities
• Municipal Buildings
• Educational Institutions

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather protection. The G90 galvanized steel construction with powder coat finish ensures long-term durability and corrosion resistance for professional electrical installations requiring dependable multi-position metering solutions.
