MS Sedco MS Sedco 614 Series Extreme Door Switches MSS-614

MS Sedco 614 Series Extreme Door Switch with Waterproof Piezo Technology

(No reviews yet) Write a Review

Model: 614-SS

In Stock (leaves warehouse same day if ordered before 3pm ET)

$114.00
$98.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco 614 Series Extreme Door Switch with Waterproof Piezo Technology

The MS Sedco 614 Series Extreme Door Switch is engineered to deliver reliable activation of automatic doors in the most demanding environments. Featuring a patented solid-state piezo design with no moving parts, the 1" diameter red anodized pressure-sensitive SPST button is virtually indestructible and completely waterproof. The 614 Series is rated weatherproof from -40°F to 257°F and has been tested to an exceptional 50 million cycles, making it ideal for industrial clean rooms, wet environments, and other extreme-duty commercial applications. Stainless steel face plates are available in two sizes: 4 1/2" x 4 1/2" or 1 11/16" x 4 1/2".

Key Features

  • 50 Million Cycle Durability: Tested to 50 million cycles, delivering exceptional long-term reliability in high-traffic and extreme-duty applications.
  • Patented Solid-State Piezo Technology: No moving parts design using patented piezo material eliminates mechanical wear for virtually indestructible performance.
  • Completely Waterproof: Fully sealed construction makes the 614 Series ideal for industrial clean rooms, wet environments, and wash-down applications.
  • Extreme Temperature Range: Weatherproof rated from -40°F to 257°F for reliable operation in harsh outdoor and industrial environments.
  • 1" Diameter Pressure-Sensitive Button: Red anodized SPST button provides clear visual identification and responsive activation for automatic door systems.
  • Stainless Steel Face Plate Options: Available in 4 1/2" x 4 1/2" or 1 11/16" x 4 1/2" stainless steel face plate sizes to suit varied mounting requirements.
  • Radio Control Versions Available: Optional radio control configurations provide added installation flexibility for wireless automatic door activation.

Certifications & Compliance

  • Commercial Grade Electronic Access Control
  • Patented Piezo Solid-State Technology
  • Weatherproof Rated: -40°F to 257°F
  • Tested to 50 Million Cycles

Technical Specifications

  • Faceplate: 1-11/16" x 4.5" stainless steel
  • Switch: 1" diameter red piezo button; waterproof with no moving parts (patented piezo technology)
  • Included: Self-adhesive wheelchair and PUSH TO OPEN Mylar decals

Typical Applications

  • Industrial Clean Rooms
  • Commercial Wet and Wash-Down Environments
  • Healthcare Facility Automatic Door Systems
  • Educational Institution Entrances
  • Retail and Commercial Building Automatic Doors
  • Outdoor and Extreme-Temperature Installations
  • Government and Municipal Building Access Points

Why MS Sedco 614 Series?

MS Sedco 614 Series door switches are built for environments where standard switches simply cannot perform. The patented solid-state piezo technology with no moving parts, combined with a completely sealed waterproof construction and a tested rating of 50 million cycles, ensures dependable automatic door activation even in the most extreme industrial and commercial conditions. Engineered for professionals who demand hardware that performs reliably where temperature extremes, moisture, and heavy use are everyday realities.

Manufacturer Resources

614 Data Sheet

Product Specs

Product Group:
Electronic Access Controls
Series:
614 Series
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Door Switches
Subcategory:
Switches
Commercial/Residential:
Commercial
Electronic:
Yes
Product Model:
614 Series
Product Finish:
Stainless Steel
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco 614-SS – Frequently Asked Questions

1) Will the MS Sedco 614 door switch hold up in a wash-down area or an outdoor entrance?
That's exactly what the 614 Series is built for. The button is a solid-state piezo element with no moving parts, fully sealed, so there's no mechanism for water to get into. It's weatherproof rated from -40F to 257F, which covers freezer vestibules, exterior entrances, and hot industrial spaces alike. Wash-down and clean room use are listed applications. If your current actuator is a mechanical plunger or membrane switch that keeps failing after washdown, the piezo design is the fix, since there is nothing inside to wear or corrode.
2) What's the difference between the narrow and single-gang MS Sedco 614 switch?
It's the face plate size. The 614 comes as a Narrow Extreme Switch and a Single-Gang Extreme Switch, with stainless steel plates of 1-11/16 x 4-1/2 inches or 4-1/2 x 4-1/2 inches. Pick the narrow plate when you're mounting on a door jamb, mullion, or a tight bollard face where a full square plate won't sit flat. The single-gang size is the one for a standard wall box location. Both use the same 1 inch red anodized piezo button.
3) Will an MS Sedco 614 piezo switch wire into my existing automatic door operator?
The 614 button is an SPST switch, so it presents a simple dry contact closure, which is what an automatic door operator's activation input expects. Wire it to the operator's activation terminals the same way you'd wire any push plate. Note it's an activation switch only, not an operator or a controller, so it replaces the push plate on the wall, not anything inside the header.
4) How long will a piezo door switch last on a high traffic entrance?
The 614 Series has been tested to 50 million cycles. For scale, a busy hospital or grocery entrance actuated a couple thousand times a day is nowhere near that in the life of the building. The reason it gets there is the patented piezo material: there's no spring, no plunger, no contact to pit, so the usual failure mode of a mechanical push plate doesn't apply.
5) Does the MS Sedco 614 switch come with the wheelchair and PUSH TO OPEN graphics?
Yes, self-adhesive wheelchair symbol and PUSH TO OPEN Mylar decals ship with the switch. The plate itself is plain stainless, so you apply the decal you need for the opening. Nothing else to order for the graphics.
6) Is there a wireless version of the 614 switch so I don't have to run conduit?
Radio control versions of the 614 are offered, which lets you put the actuator where pulling wire isn't practical, like a free-standing bollard in the middle of a walkway or an existing masonry wall. The base configuration is a hardwired SPST switch, so specify the radio control version at order time if that's what you need.
7) Should I use a piezo switch or a touchless wave sensor for an automatic door actuator?
Different problems. A piezo button like the 614 needs contact, but it can't be false-triggered by carts, foot traffic passing by, or a mop, and it works with wet or gloved hands. That's why it lands in clean rooms, wash-down areas, and outdoor entrances. A touchless switch is the one to specify where hygiene rules forbid contact entirely or where the user may have no free hands. If your complaint is that mechanical plates keep breaking, the piezo answers it without giving up the deliberate press.
8) Is the MS Sedco 614 rated for commercial use or is it a residential product?
Strictly a commercial-grade electronic access control device. It's listed for industrial clean rooms, healthcare and school entrances, retail and government buildings. There's no residential version of the 614, and its temperature and cycle ratings are aimed at facilities where the door runs all day.
9) Will a stainless 614 switch match the other actuators in my building?
The face plates are stainless steel on both sizes, which is the common finish for actuators and push plates, so it will read consistently next to brushed stainless hardware elsewhere in the building. The button itself is red anodized and 1 inch across, so it stands out against the plate, which is what you want for visibility on an accessible entrance. If you're standardizing a fleet of openings, the single-gang plate is the one to spec across the board and the narrow plate for jamb-mounted locations.
