NGP NGP 202NDKB Neoprene Door Sweep, 36" Dark Bronze NGP-202NDKB

NGP 202NDKB Neoprene Door Sweep 36" Dark Bronze Aluminum with Stainless Steel Hardware

(No reviews yet) Write a Review

Model: 202NDKB
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$82.41
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

NGP Neoprene Door Sweep 36" Dark Bronze Aluminum with Stainless Steel Hardware

Professional Weather Sealing Solution for Commercial Applications

The NGP Neoprene Door Sweep delivers superior weather protection with a 36" dark bronze aluminum housing and high-performance neoprene seal. Constructed from aluminum alloy 6063 T5 temper with a synthetic rubber polymer blend of Chloroprene and EPDM, this door sweep provides exceptional durability and sealing performance. BHMA certified to ANSI/BHMA A156.22 performance standards for heat and cold resistance, operating effectively in temperatures from -20 F to 200 F.

Professional Features & Benefits

  • 36" Length: Standard door width coverage with dark bronze aluminum finish for professional appearance and corrosion resistance.
  • Temperature Performance: Operates reliably from -20 F to 200 F with BHMA certification to ANSI/BHMA A156.22 heat and cold performance tests.
  • Premium Construction: Aluminum alloy 6063 T5 temper housing provides structural integrity and long-term dimensional stability.
  • Advanced Seal Material: Synthetic rubber polymer blend of Chloroprene and EPDM delivers excellent abrasion resistance, tensile strength, and memory retention.
  • Weather Resistance: Flame resistant and moisture resistant design with good resistance to ozone, sunlight, and aging for extended service life.
  • Adjustable Installation: Slotted screw holes allow for precise positioning and alignment during installation.
  • Complete Hardware: Includes #6 x 3/4" stainless steel sheet metal screws for secure mounting and corrosion resistance.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Type: Door Sweeps and Bottoms
  • Series: Neoprene Door Sweep Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose NGP Quality?

NGP door sweep products deliver professional-grade weather sealing with aluminum alloy 6063 T5 temper construction and BHMA certified performance to ANSI/BHMA A156.22 standards. The advanced Chloroprene and EPDM polymer blend provides exceptional durability with excellent abrasion resistance and temperature performance from -20 F to 200 F. Engineered for demanding commercial applications where reliable weather protection and long-term performance are essential.

Product Specs

Product Group:
Door Trim and Accessories
Series:
Neoprene Door Sweep Series
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Sweeps and Bottoms
Subcategory:
Gaskets & Weatherstripping
Commercial/Residential:
Commercial
Product Category:
Door Trim and Accessories
Department:
Door Hardware

NGP 202NDKB – Frequently Asked Questions

1) Will the NGP 202NDKB door sweep cover a standard 36 inch commercial door?
Yes. The 202ND sweep comes in a 36 inch dark bronze aluminum housing, which matches a standard 3-0 door leaf. It surface mounts to the face of the door at the bottom rail, so if your opening is narrower, the aluminum housing can be cut down to width on site.
2) Does the NGP 202NDKB sweep come with mounting screws, or do I need to supply my own?
Screws are in the box. NGP supplies #6 x 3/4 inch stainless steel sheet metal screws, so you get corrosion resistant fasteners for exterior openings without a separate line item. The housing is punched with slotted holes, so you can slide the sweep up or down to set seal contact on the threshold before you drive them home.
3) Will a neoprene door sweep hold up on an exterior door in freezing winters and hot summers?
The 202ND seal is a Chloroprene and EPDM polymer blend rated for service from -20 F to 200 F, and it is BHMA certified to the ANSI/BHMA A156.22 heat and cold performance tests. That covers northern winter exposure and a dark, south-facing metal door in full summer sun. The blend also resists ozone, sunlight and aging, which is what kills a cheap rubber seal first.
4) Our project requires low-emitting materials for a green building credit - is there an alternative to the NGP 202NDKB?
The 202NDKB seal is a synthetic rubber polymer blend of Chloroprene and EPDM and is BHMA certified to ANSI/BHMA A156.22 for heat and cold performance, but the certification is a performance standard, not an emissions one. If the submittal calls for a low-emitting material, the Pemko 345V door bottom sweep uses a GREENGUARD Gold certified Eco-V insert. The Pemko 56 series also carries an Eco-V insert and is offered in a 36 inch length that matches the 202NDKB.
5) What is the closest equivalent to the NGP 202NDKB neoprene door sweep in another brand?
The NGP 202NDKB pairs a 36 inch aluminum housing with a neoprene seal and mounts with slotted screw holes. The nearest like-for-like is the Cal-Royal BTN-112, which also uses an extruded aluminum retainer with a neoprene insert, so the seal material and the retainer construction match. The difference to check before you order is length: the 202NDKB is a 36 inch piece sized for a standard commercial door width, so confirm the retainer length you need on the Cal-Royal before swapping.
6) I need a door sweep for an uneven or worn threshold - is a neoprene blade sweep the right choice?
A neoprene blade like the one on the NGP 202NDKB seals best against a flat, even sill because the blade contacts in a continuous line. Where the floor is uneven, worn, or the gap varies along the opening, a brush sweep conforms better: the Pemko 29326NB is a 36 inch brush door bottom sweep in clear anodized aluminum with a concealed fastener design, matching the 202NDKB length. The Cal-Royal BTN-112 is also from a brush weatherstrip series if you want a brush option with an extruded aluminum retainer.
7) Should I use a neoprene sweep or a brush sweep on my door?
A neoprene blade like the NGP 202ND wipes the threshold and gives you a tighter seal against air, water and light, which is what you want on an exterior opening. A brush sweep, like the Cal-Royal BTN-112 or the Pemko 29326NB, drags less and rides over uneven or carpeted floors more forgivingly, so it is the usual pick for interior doors, smoke and dust control, or where the floor is not flat. If the door swings out over a stoop in weather, go neoprene.
8) Is the dark bronze finish on this NGP sweep going to match my bronze storefront and exterior doors?
The 202NDKB is finished dark bronze on a 6063 T5 aluminum extrusion, which is the standard companion to dark bronze anodized storefront and hollow metal. For a fleet of openings, note this sweep is offered in dark bronze only, so if some of your doors are aluminum-clear you would be mixing finishes. Pemko's 29326NB is the clear anodized equivalent in a brush style.
9) My door has a rain problem at the bottom, will a sweep alone fix it?
A surface sweep like the NGP 202ND seals the gap between the door bottom and the threshold, but it does nothing about water running down the face of the door and under it. For driving rain on an out-swing exterior opening, pair it with a drip, or use a bottom that integrates one such as the Pemko 3452 surface plate rain drip door bottom.
10) Can I install this sweep without pulling the door off the hinges?
Yes. The 202ND surface mounts to the face of the door bottom with the supplied #6 x 3/4 inch stainless screws, so it goes on with the door hung. The slotted holes let you snug the screws lightly, swing the door to check the seal drags evenly on the threshold, then adjust the height and tighten. No mortising and no door prep.
11) Will the NGP 202NDKB keep rain from running down the face of an exterior door?
The 202NDKB is a surface-applied sweep: the aluminum housing holds a neoprene blade that closes the gap between the door bottom and the sill, and it is flame and moisture resistant with good resistance to ozone, sunlight and aging. It does not project a drip lip over the threshold. For a driving-rain exterior opening where water needs to be thrown clear of the sill, the Pemko 3452 is a surface plate rain drip door bottom. Many exterior openings use both - the sweep for the air and water seal at the sill, the drip for the runoff.
12) If exposed screw heads are a problem on the door face, what should I use instead of the NGP 202NDKB?
The NGP 202NDKB mounts through slotted screw holes in the aluminum housing using the supplied #6 x 3/4 inch stainless steel sheet metal screws, so the fasteners are visible on the door face - the slots are what let you fine-tune the blade height at the sill. Where the finished appearance matters and you want the fasteners hidden, the Pemko 29326NB is a 36 inch sweep with a concealed fastener design in clear anodized aluminum.
13) Does the Pemko 3452 work as a direct replacement for an NGP 202NDKB neoprene sweep?
No - it is a different part doing a different job. The 202NDKB is a 36 inch neoprene sweep whose blade seals the gap at the sill against air and moisture. The Pemko 3452 is a surface plate rain drip door bottom, which sheds water off the door face rather than sealing the bottom gap. If your goal is to close the gap under the door, stay with a sweep such as the 202NDKB or the Pemko 56 series with Eco-V insert in 36 inch.
14) I am standardizing door sweeps across a portfolio of commercial buildings - how do the 36 inch options differ?
Three of the common 36 inch choices differ mainly in seal type and fastening. The NGP 202NDKB uses a Chloroprene and EPDM neoprene blade in a dark bronze 6063 T5 aluminum housing with slotted holes and stainless steel screws included, and is BHMA certified to ANSI/BHMA A156.22 for heat and cold, rated -20 F to 200 F. The Pemko 29326NB is a brush sweep in clear anodized aluminum with concealed fasteners. The Pemko 56 series uses an Eco-V insert. Pick the seal type by floor condition and the housing finish to match the door hardware already in the building.
15) Is this NGP sweep rated for commercial traffic or is it a residential part?
It is a commercial-grade part. NGP lists the 202ND as commercial, and the aluminum 6063 T5 housing with a BHMA certified A156.22 seal is built for office buildings, schools, hospitals, retail, warehouses and municipal facilities rather than a back door on a house.
