NON-INS FERRULE 2, 35 MM2, LG .709
Manufacturer Resources
Product Specs
- Country Of Origin:
- Germany (DE)
- Product Subgroup:
- Ferrules
- Product Type:
- Non-Insulated Ferrule
- Standards:
- UL E489056
- Wire Size:
- 2 AWG
- Department:
- Electrical
- Product Group:
- Wire Termination
- Product Material:
- Copper
Sta-Kon F9034 – Frequently Asked Questions
1) What wire size does the Sta-Kon F9034 ferrule take?
The F9034 wire ferrule is sized for 2 AWG conductor, which is the 35 mm2 metric equivalent called out in the part description. Use it on stranded 2 AWG only; a smaller conductor will not fill the barrel and the crimp won't hold.
2) Is the F9034 ferrule insulated or bare?
Bare. The F9034 is a non-insulated ferrule, so there is no plastic collar and nothing to color-code the size by. If the terminal block or enclosure needs strain relief or touch protection at the wire entry, you want an insulated ferrule instead.
3) What is the Sta-Kon F9034 ferrule made of?
Copper. Copper barrels match the conductor metal on standard copper building and control wire, so there's no dissimilar-metal joint at the termination. For aluminum conductor you need a connector rated for aluminum, not this one.
4) Is the Sta-Kon F9034 ferrule UL recognized for panel work?
It carries UL file E489056. Inspectors and institutional specs that call for a UL file reference on wire terminations will take that number for the F9034.
5) Why use a ferrule on 2 AWG stranded wire going into a terminal block?
A ferrule gathers the strands into a solid pin so the set screw clamps the whole conductor instead of splaying strands out of the block, which is the usual cause of loose connections and hot terminations on large stranded wire. The F9034 does that for 2 AWG / 35 mm2. It must be crimped, not just slipped on.
6) Where is the Sta-Kon F9034 ferrule manufactured?
Germany. That matters on public and institutional jobs with country-of-origin reporting requirements on electrical components.
