Product Specs
- Country Of Origin:
- United States
- Ip Rating:
- IP66
- Panel:
- Available (sold separately)
- Product Height:
- 16.27
- Product Material:
- Polyester Plastic
- Product Weight:
- 14 lbs
- Product Width:
- 14.4
- Reach Compliant:
- Yes
- Rohs Compliant:
- Yes
- Standards:
- ce, culus
- Type Rating:
- type-3r, type-13, type-4x
- Usmca Compliant:
- Yes
- Product Depth:
- 8.13
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Subgroup:
- Enclosures
- Product Type:
- Screw-Cover Enclosure
Hammond Manufacturing PJ16148 – Frequently Asked Questions
1) Can the Hammond PJ16148 enclosure be used outdoors or in a washdown area?
Yes. The PJ16148 polyester enclosure carries Type 3R, Type 4X and Type 13 ratings plus IP66, so it handles outdoor rain exposure, hose-directed water and oil or coolant spray. Type 4X in a non-metallic polyester body also means it holds up where a painted steel box would corrode, such as coastal sites, wastewater plants and food processing areas.
2) Does the PJ16148 junction box come with a mounting panel inside?
No. The PJ16148 ships as the enclosure with its screw cover; the back panel is a separate order. If you are mounting terminal blocks, breakers, relays or a small drive inside, add the panel line item, otherwise you will be drilling the enclosure's inner wall on site.
3) Is a screw cover enclosure or a hinged door enclosure better for my application?
A screw cover box like the PJ16148 is the right pick when the enclosure gets opened rarely, during commissioning or occasional service, and you want the gasket pulled down evenly all the way around for the Type 4X and IP66 seal. If an operator has to get inside daily, or you need to mount a panel and swing it clear, go with a hinged-door version instead, because unscrewing a cover every shift is how gaskets get pinched and screws get lost.
4) Will a non-metallic enclosure like this work where I need to drill my own conduit entries?
Yes, and that is one practical reason people choose polyester plastic over steel. The PJ16148 body cuts with a hole saw or step bit without leaving bare metal to rust, so field-added conduit hubs and cord grips are straightforward. Use sealing hubs or gaskets rated to match if you want to keep the IP66 and Type 4X performance after you open the wall.
5) Does the Hammond PJ16148 meet RoHS and REACH for our procurement checklist?
Yes on both. The PJ16148 is RoHS compliant and REACH compliant, and it is USMCA compliant with United States country of origin, which covers the usual domestic-preference and trade-documentation questions on institutional and government orders.
6) What exact part number do I order for this 16 x 14 x 8 Hammond non-metallic screw cover box?
Order Hammond Manufacturing PJ16148. That single part number covers the enclosure with screw cover in polyester; there are no finish or size options to specify. The interior mounting panel is the one extra line you may need.
