Nuts 7/16-14 Hx Nut SS (Jar 50)
Additional Notes
- Other sizes and quantities available by request
Features
- Designed for use with stainless steel bolts and screws with a specified minimum tensile strength equal to or less than the specified proof stress of the mating nut. Both type of stainless are corrosion resistant with 316 stainless having greater such resistance as well as superior strength at raised temperatures.
- Six-sided internally threaded fastener whose thickness is 0.875 D is the nominal nut size and 1.5 D is their width across the flats, made from austenitic alloys.
Manufacturer Resources
Product Specs
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Division:
- Electrical H1
- Fastener Head Height:
- 4-Jan in.
- Fastener Head Width:
- 0.675 - 0.688 in.
- Fastener Height:
- 0.365 - 0.385
- Fastener Width:
- 0.768 - 0.794
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Hardness:
- Rockwell B95-C32
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Nut_Domestic_Gr_2_Gr_5_Gr_8_Gal_18-8_SS_316_SS.pdf
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- EA
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 2.7 in
- Product Length:
- 3 in
- Product Weight:
- 1.477 lbs
- Product Width:
- 3 in
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 14
- Thread Standard:
- ANSI/ASME B18.2.2
- Department:
- Electrical
- Product Subgroup:
- Nuts
- Product Type:
- Hexagonal Nut
- Type2:
- Hexagonal Nut
- Series:
- JSN
- Product Details:
- Hexagonal Nut
- Product Material:
- 316 Stainless Steel
Metallics JSN20316SS – Frequently Asked Questions
1) Will the Metallics JSN20316SS hex nut thread onto a 7/16-14 bolt?
Yes. The JSN20316SS is a 7/16-14 hex nut, 14 threads per inch, cut to ANSI/ASME B18.2.2, so it mates with any standard 7/16 inch UNC coarse-thread bolt or threaded rod.
2) Is 316 stainless worth it over 18-8 for outdoor or coastal electrical work?
The JSN20316SS is 316 stainless. Both 316 and 18-8 austenitic grades resist corrosion, but 316 has greater corrosion resistance and better strength at raised temperatures, which is why it gets specified for marine, coastal, wash-down and chemical exposure. For dry indoor work 18-8 is usually enough.
3) Do these Metallics stainless nuts qualify for a Buy American or ARRA project?
No. The JSN20316SS is listed as not Buy American compliant and not ARRA compliant, with multiple countries of origin. If your spec carries a domestic-content clause, these will not pass.
4) Can I use these stainless nuts on galvanized or Grade 5 steel bolts?
Pair them with stainless steel bolts and screws whose specified minimum tensile strength is equal to or less than the proof stress of the nut. Mixing a stainless nut onto a higher-strength plated steel bolt can leave the nut as the weak link, and dissimilar metals in a wet location invite galvanic corrosion. Match the nut to the bolt material.
5) How many nuts come in a jar of Metallics JSN20316SS?
They ship 50 to a jar, and 50 each is the order minimum. Jar weight is 1.477 lbs. The jar packaging keeps them together on a service truck instead of loose in a bin.
