Panduit SA6-T Pan-Lug Aluminum Compression Splice

Panduit SA6-T Pan-Lug Aluminum Compression Splice

(No reviews yet) Write a Review

Model: SA6-T

In Stock (leaves warehouse same day if ordered before 3pm ET)

$8.62
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit SA6-T Pan-Lug Aluminum Compression Splice

The Panduit Pan-Lug™ SA6-T is an aluminum compression splice built from high conductivity, thick wall aluminum for reliable conductor-to-conductor connections. Tin-plated to inhibit corrosion and sized for 6 AWG aluminum conductors, this splice is UL Listed and CSA Certified to 35 kV and temperature rated to 90°C when crimped with Panduit or specified competitor crimping tools and dies.

Key Features

  • Trade Size: Sized for 6 AWG aluminum conductor with a wire strip length of 3/4" (19.1mm).
  • Durable Construction: High conductivity, thick wall aluminum body resists deformation under compression.
  • Corrosion Inhibition: Tin-Plated finish helps inhibit corrosion at the connection point.
  • Factory Pre-Filled Joint Compound: Sealed with an easy pull-out end plug to keep the joint compound protected until installation.
  • Die Index Marking: Panduit and specified competitor die index numbers are marked on the barrel for proper crimp die selection (T&B Die Index Number 29, Burndy Die Index Number 346).
  • Over-Insertion Protection: Internal solid stop prevents over-insertion of the conductor for a consistent, repeatable crimp.
  • Electrical Rating: UL Listed and CSA Certified to 35 kV, temperature rated to 90°C when crimped with approved tools and dies.
  • Finish: Tin-Plated with a Gray color code, Non-Insulated barrel.

Certifications & Compliance

  • UL Listed to 35 kV, 90°C Temperature Rating
  • CSA Certified to 35 kV, 90°C Temperature Rating
  • RoHS Compliant

Technical Specifications

  • REACH Status: N
  • CSA Temperature Rating (°C): 90
  • California Pro65 Cancer: N
  • Maximum Voltage (kV): 35
  • UL Temperature Rating (°C): 90
  • Mercury Content Indicator: N
  • Std Ctn Qty: 800
  • Wire Strip Length (In.): 3/4
  • Pallet Quantity: 0
  • Std. Pkg. Qty.: 200
  • T & B Die Index Number: 29
  • Std Carton Width MM: 292.1
  • UOM EA PK: PK
  • Burndy Die Index Number: 346
  • Pallet Volume: 0.000000
  • Std Package Width In: 5.38
  • Hazardous Material Flag: N
  • Insulation Material: Non-Insulated
  • Wire Strip Length (mm): 19.1

Typical Applications

  • Electrical Power Distribution Splicing
  • Utility and Industrial Wiring Repairs
  • Underground and Overhead Conductor Connections
  • Commercial and Industrial Electrical Installations
  • Aluminum Conductor Terminations Requiring Corrosion Protection

Why Panduit?

Panduit engineers the Pan-Lug™ SA6-T with a factory pre-filled, sealed joint compound and an internal solid stop that together help installers achieve a consistent, code-compliant crimp every time. With UL Listing and CSA Certification to 35 kV and a 90°C temperature rating, this aluminum compression splice is built for dependable performance in demanding electrical connection applications.

Manufacturer Resources

Product Specs

Standard Package Volume Ft3:
0.0191
Standard Package Weight Pounds:
3.8000
Aluminum Conductor Size:
6 AWG
REACH Status:
N
Std. Pkg. UOM:
Piece
Base Material:
Aluminum
Std Carton Length In:
15.25
CSA Temperature Rating (°C):
90
California Pro65 Cancer:
N
Std Carton Height In:
4.25
Std Package Length In:
7.25
Maximum Voltage (kV):
35
Finish/Coating:
Tin-Plated
Overall Length (mm):
41.1
UL Temperature Rating (°C):
90
Standard Carton Volume Ft3:
0.0763
Color Code:
Gray
Mercury Content Indicator:
N
Std Package Length MM:
184.15
Std Carton Width In:
11.5
Sub Brand:
Pan-Lug™
Std Ctn Qty:
800
Wire Strip Length (In.):
3/4
Product Type:
Compression Splice
GTIN Carton:
50613056858218
Std Carton Height MM:
107.95
Std Package Width MM:
136.652
Pallet Quantity:
0
Std Package Height In:
3.38
Standard Carton Weight Pounds:
15.2000
Std Package Height MM:
85.852
Min Order Qty:
1.0000
RoHS Compliant:
Compliant
GTIN Package:
00613056858213
Min. Order UOM:
Piece
Std. Pkg. Qty.:
200
T & B Die Index Number:
29
Overall Length (In.):
1.62
Std Carton Length MM:
387.35
Std Carton Width MM:
292.1
UOM EA PK:
PK
Burndy Die Index Number:
346
Pallet Volume:
0.000000
Std Package Width In:
5.38
Hazardous Material Flag:
N
Any Reason Not to Sell:
N
Insulation Material:
Non-Insulated
Wire Strip Length Mm:
19.1
Department:
Electrical
Product Group:
Wire Connectors & Terminals
Product Subgroup:
Splice Kits

Panduit SA6-T – Frequently Asked Questions

1) How much insulation do I strip back for the SA6-T splice?
Strip 3/4 inch (19.1 mm) off each conductor end. The splice has an internal solid stop at the center, so the conductor bottoms out at the correct depth and you get the same crimp every time; the overall barrel is 1.62 inches (41.1 mm) long, which is roughly two 3/4 inch strip lengths plus the stop.
2) Is the Panduit SA6-T rated for medium voltage underground work?
Yes. It is UL Listed and CSA Certified to 35 kV with a 90 degree C temperature rating on both listings, which covers medium voltage distribution splicing. It also comes factory pre-filled with joint compound behind a pull-out end plug, so the aluminum conductor is protected against oxidation in wet or buried applications.
3) What is the closest alternative to the Panduit SA6-T for splicing aluminum conductors?
The Panduit SA6-T is an aluminum-bodied, tin-plated compression splice for 6 AWG aluminum conductor. The closest alternative in the same construction is the NSi Industries ASC-T series dual-rated aluminum compression splice, which is rated AL9CU so it can be used on either aluminum or copper conductors. The SA6-T itself is sized specifically for 6 AWG aluminum, so if the job mixes aluminum and copper runs, the dual-rated ASC-T series is the one to check sizing against.
4) Does the SA6-T come insulated, or do I have to tape or heat shrink over it?
The barrel is non-insulated, gray color coded, so the splice needs to be re-insulated in the field with tape, heat shrink or a splice kit appropriate to the circuit voltage. Nothing for insulating the joint ships with the connector.
5) Why choose a tin-plated aluminum splice over a plain one for outdoor aluminum feeders?
Two things fight corrosion on this Pan-Lug splice: the tin plating on the aluminum body, and the factory joint compound sealed inside behind a pull-out end plug so it stays clean until the conductor goes in. That matters on overhead and direct-buried aluminum, where a bare aluminum interface oxidizes and the connection heats up. It is also RoHS compliant.
6) What is the difference between the NSi C series and SC series copper splices when replacing a Panduit SA6-T job?
Both are tinned copper compression splices. The NSi C series is a long barrel design, and the NSi SC series is a short barrel design; long barrel splices take more crimps over a greater contact length, while short barrel splices fit tighter spaces such as crowded enclosures or handholes. Neither is an aluminum splice, so they are not a direct swap for the SA6-T, which is an aluminum body sized for 6 AWG aluminum conductor with a 3/4 inch strip length.
7) Which splice should I stock if I want one part number for both aluminum and copper feeders?
For mixed-metal work the NSi Industries ASC-T series is dual-rated AL9CU, meaning it is listed for both aluminum and copper conductor. The Panduit SA6-T is the aluminum-specific choice: an aluminum body, tin-plated, factory pre-filled with joint compound and marked with T&B die index 29 and Burndy die index 346 so crews can crimp it with tooling they already own. If your dies are already set up for those index numbers, standardizing on the SA6-T for aluminum runs keeps the crimp procedure consistent.
8) How are Panduit SA6-T splices packaged for a large job, and can I buy just one?
Minimum order is one piece. Standard package is 200 pieces and a standard carton holds 800, so crews pulling a lot of 6 AWG aluminum can order by the carton rather than counting singles.
9) What is the shipping weight of a package and a carton of SA6-T splices?
A standard 200 piece package weighs 3.8 pounds and measures 7.25 x 5.38 x 3.38 inches. The 800 piece carton weighs 15.2 pounds at 15.25 x 11.5 x 4.25 inches. Country of origin is India.
