Panduit StructuredGround Insulated Copper Panel Bonding Jumper
The Panduit StructuredGround™ Panel Bonding Jumper attaches a CP**BL panel to the grounding bus, providing a reliable bonding path for control panel installations. Built with insulated #12 AWG stranded copper cable measuring 8" overall, this jumper is designed for dependable electrical continuity in Control Panel applications. Finished in Green/Yellow for immediate grounding-conductor identification on the job.
Key Features
- Conductor Gauge: #12 AWG stranded copper cable for reliable bonding conductivity.
- Overall Length: 8" (203.2mm) jumper length for connecting CP**BL panel to grounding bus.
- Insulated Design: Insulated copper construction supports safe, code-conscious grounding connections.
- Application: Purpose-built for Control Panel bonding and grounding.
- Color Coding: Green/Yellow jacket for standard grounding-conductor identification.
- Sub-Brand: Part of the Panduit StructuredGround™ grounding and bonding system.
Certifications & Compliance
- RoHS Compliant
- ARRA Compliant
Technical Specifications
- REACH Status: N
- Std Carton Height In: 4.5
- Std Package Length In: 12
- Mercury Content Indicator: N
- Std Carton Width In: 6.7
- Std Ctn Qty: 10
- Product Segment: IEI
- Std Package Height In: .8
- ARRA Compliant: Y
- Std. Pkg. Qty.: 1
- Overall Length (In.): 8
- UOM EA PK: EA
- Std Package Width In: 5.8
- Hazardous Material Flag: N
Typical Applications
- Control Panel Grounding and Bonding
- Panel-to-Grounding-Bus Connections
- Commercial and Industrial Electrical Installations
- Structured Grounding Systems
Why Panduit?
Panduit's StructuredGround™ Panel Bonding Jumper delivers insulated #12 AWG stranded copper construction for a dependable panel-to-ground-bus connection. With RoHS and ARRA compliance, it's built to support code-conscious, reliable grounding performance in professional control panel installations.
Manufacturer Resources
Product Specs
- Standard Package Volume Ft3:
- 0.0190
- Standard Package Weight Pounds:
- 0.0350
- REACH Status:
- N
- Std. Pkg. UOM:
- Piece
- Std Carton Length In:
- 10.9
- Std Carton Height In:
- 4.5
- Application:
- Control Panel
- Std Package Length In:
- 12
- Overall Length (mm):
- 203.2
- Country of Origin:
- United States
- Standard Carton Volume Ft3:
- 0.1902
- Std Package Length MM:
- 304.8
- Mercury Content Indicator:
- N
- Std Carton Width In:
- 6.7
- Sub Brand:
- StructuredGround™
- Std Ctn Qty:
- 10
- Product Segment:
- IEI
- Product Type:
- Panel Bonding Jumper
- GTIN Carton:
- 50074983597951
- Std Carton Height MM:
- 114.3
- Std Package Width MM:
- 147.32
- Pallet Quantity:
- 2,400
- Std Package Height In:
- .8
- Standard Carton Weight Pounds:
- 0.3500
- Std Package Height MM:
- 20.32
- Min Order Qty:
- 1.0000
- RoHS Compliant:
- Compliant
- GTIN Package:
- 00074983597956
- Min. Order UOM:
- Piece
- ARRA Compliant:
- Y
- Std. Pkg. Qty.:
- 1
- Overall Length (In.):
- 8
- Std Carton Length MM:
- 276.86
- Conductor Gauge:
- 12 AWG
- Std Carton Width MM:
- 170.18
- UOM EA PK:
- EA
- Pallet Volume:
- 45.643750
- Std Package Width In:
- 5.8
- Hazardous Material Flag:
- N
- Any Reason Not to Sell:
- N
- Pallet Weight:
- 84.0000
- Product Color:
- Green/Yellow
- Department:
- Electrical
- Product Group:
- Grounding & Bonding
- Product Subgroup:
- Grounding & Bonding
Panduit PGK – Frequently Asked Questions
1) What is the Panduit PGK bonding jumper actually used for?
The Panduit StructuredGround PGK is a short bonding jumper that ties a CP**BL control panel to the grounding bus. It is an 8 inch insulated #12 AWG stranded copper lead, built for control panel bonding rather than for building steel or rack-to-rack runs.
2) Will an 8 inch jumper reach from my panel door to the ground bus?
Overall length is 8 inches (203.2 mm), measured end to end, so it suits a short hop from a panel door or subpanel to a nearby grounding bus. If your bus is further than that from the bond point, this jumper won't reach and you need a longer made-up lead or field-terminated #12 green/yellow.
3) Is the Panduit PGK RoHS and ARRA compliant for a federally funded job?
Yes on both. The PGK is listed RoHS compliant and ARRA compliant, and country of origin is the United States, which is what a government or institutional buyer usually needs documented on a Buy American style project.
4) Is the PGK jumper green/yellow so it reads as a grounding conductor on inspection?
The jacket is green/yellow, the standard identification for an equipment grounding conductor, so it reads correctly to an inspector without extra tagging. Solid green is the common North American convention, and green with a yellow stripe is accepted for the same purpose.
5) Can I buy one PGK jumper, or do I have to take a carton?
Single pieces are fine. Minimum order is 1 piece and the standard package is 1 piece. A standard carton holds 10, and a pallet quantity is 2,400 if you are stocking a panel shop.
6) Is #12 AWG heavy enough for bonding a control panel door?
The PGK is #12 AWG stranded copper, which is the size Panduit specifies for bonding a CP**BL panel to the grounding bus. It is an equipment bonding jumper for panel-level connections, not a grounding electrode conductor or a service bonding jumper, where larger conductors are required.
7) Does the Panduit PGK jumper have any hazardous material or mercury content to declare?
No. The PGK carries no hazardous material flag and no mercury content, so it ships as ordinary freight and needs no special handling paperwork in an MRO stockroom.
