Panduit StructuredGround Universal Grounding Bar, 6-Port, Copper, Tin-Plated

Panduit StructuredGround Universal Grounding Bar, 6-Port, Copper, Tin-Plated

(No reviews yet) Write a Review

Model: UGB2/0-414-6

In Stock (leaves warehouse same day if ordered before 3pm ET)

$47.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit StructuredGround Universal Grounding Bar, 6-Port, Copper, Tin-Plated

The Panduit StructuredGround Universal Grounding Bar securely terminates the main equipment grounding conductor with a compression or mechanical connector in any control panel or enclosure. Built from copper with a tin-plated finish, this 6" grounding bar accepts #14 – #4 AWG wire in 6 wire ports and up to a 2/0 AWG main equipment grounding conductor. It is UL 467 listed and CSA certified to 22.2 no. 41, making it a reliable choice for professional electrical grounding installations.

Key Features

  • Size: 6" length grounding bar for control panel and enclosure applications.
  • Durable Construction: Copper body with a tin-plated finish for reliable, corrosion-resistant conductivity.
  • Wire Ports: 6 ports accept #14 – #4 AWG wire for multiple grounding conductor terminations.
  • Main Conductor Capacity: Accommodates up to a 2/0 AWG main equipment grounding conductor with a compression or mechanical connector.
  • Mounting Flexibility: Compatible with bonding stand-offs, isolation stand-offs, or direct mounting to a panel.
  • Finish: Tin-Plated for enhanced connectivity and corrosion resistance.

Certifications & Compliance

  • UL 467 Listed
  • CSA Certified to 22.2 no. 41
  • RoHS Compliant

Technical Specifications

  • Number of Ports: 6
  • Std. Pkg. UOM: Kit
  • Std Carton Length In: 8.2
  • Mounting Hole Width (mm): 2.4
  • Overall Length (mm): 125
  • Std Ctn Qty: 10
  • Std Package Height In: .7
  • Min. Order UOM: Kit
  • Std. Pkg. Qty.: 1
  • Std Carton Length MM: 208.28
  • Std Carton Width MM: 110.49
  • UOM EA PK: EA
  • Std Package Width In: 4
  • Product Material: Copper
  • Product Size: 6"

Typical Applications

  • Control Panel Grounding
  • Equipment Enclosure Bonding
  • Main Equipment Grounding Conductor Termination
  • Commercial and Industrial Electrical Installations
  • Panelboard and Enclosure Wiring

Why Panduit?

Panduit's StructuredGround Universal Grounding Bar delivers dependable, code-compliant grounding performance backed by UL 467 listing and CSA certification. Its durable copper, tin-plated construction and flexible mounting options make it a trusted choice for control panel and enclosure grounding in professional electrical installations.

Manufacturer Resources

Spec Sheet

Product Specs

Standard Package Volume Ft3:
0.0074
Number of Ports:
6
Standard Package Weight Pounds:
0.2783
REACH Status:
N
Std. Pkg. UOM:
Kit
Overall Width (mm):
15.7
Std Carton Length In:
8.2
Std Carton Height In:
3.45
Std Package Length In:
5.65
Mounting Hole Width (mm):
2.4
Finish/Coating:
Tin-Plated
Overall Length (mm):
125
Country of Origin:
Mexico, United States
Compatible Conductor Size:
14-4 AWG
Standard Carton Volume Ft3:
0.0741
Mercury Content Indicator:
N
Std Package Length MM:
143.51
Std Carton Width In:
4.35
Sub Brand:
StructuredGround™
Std Ctn Qty:
10
Product Segment:
IEI
Product Type:
Ground Bar
Mounting Hole Width (In.):
2.37
GTIN Carton:
50074983402224
Std Carton Height MM:
87.63
Std Package Width MM:
101.6
Pallet Quantity:
3,000
Std Package Height In:
.7
Standard Carton Weight Pounds:
2.7830
Overall Height (In.):
0.48
Std Package Height MM:
17.78
Min Order Qty:
5.0000
RoHS Compliant:
Compliant
GTIN Package:
00074983402229
Min. Order UOM:
Kit
ARRA Compliant:
Y
Std. Pkg. Qty.:
1
Overall Length (In.):
4.92
Std Carton Length MM:
208.28
Std Carton Width MM:
110.49
UOM EA PK:
EA
Pallet Volume:
22.222222
Std Package Width In:
4
Hazardous Material Flag:
N
Any Reason Not to Sell:
N
Compatible Wire Gauge:
4 AWG
Product Material:
Copper
Product Color:
Silver
Product Size:
6"
Department:
Electrical
Product Group:
Grounding & Bonding
Product Subgroup:
Grounding & Bonding
Application:
Control Panel

Panduit UGB2/0-414-6 – Frequently Asked Questions

1) What wire sizes can I land on the Panduit StructuredGround 6-port grounding bar?
The six wire ports on the Panduit UGB2/0-414-6 take #14 through #4 AWG, so equipment grounding conductors, panel bonding jumpers and device grounds all land in the same bar. The separate main lug accepts up to 2/0 AWG for the main equipment grounding conductor, using either a compression or a mechanical connector. If you need to terminate anything larger than 2/0 on the main, this is not the bar for it.
2) Is this grounding bar UL listed for use in an equipment enclosure?
Yes. The Panduit StructuredGround universal grounding bar is UL 467 listed and CSA certified to 22.2 no. 41, which is the grounding and bonding equipment listing an inspector will look for in a control panel or equipment enclosure. It is also RoHS compliant.
3) Can I mount this bar isolated from the enclosure, or does it have to bond to the panel?
Either way works. The bar can be mounted directly to the panel so it bonds to the enclosure, or set on bonding stand-offs, or set on isolation stand-offs when the grounding system has to stay isolated from the enclosure steel. Stand-offs are a separate order, so decide which scheme you need before you buy.
4) Is tin-plated copper the right choice for a grounding bar in a humid or industrial environment?
The body is solid copper with a tin plating. The tin coating resists corrosion at the terminations and keeps contact resistance stable, which is why tin-plated bars are the usual pick for industrial enclosures and anywhere humidity or airborne contaminants would dull bare copper. Color reads silver rather than copper because of the plating.
5) How is the Panduit UGB2/0-414-6 grounding bar sold, and is there a minimum order?
It ships as a kit, one bar per standard package, with a minimum order of 5 kits. Standard carton is 10 kits. If you are standardizing grounding across a run of control panels, order in multiples of the kit count rather than as loose pieces.
6) Does this Panduit grounding bar meet ARRA / Buy American sourcing requirements for a government job?
The bar is flagged ARRA compliant, and country of origin is listed as Mexico and the United States. Institutional and public-works buyers who have to document sourcing should pull the origin statement for the specific production lot they receive.
7) Do I need lugs or connectors to use this grounding bar, or are they included?
The six wire ports are screw ports that take #14 to #4 AWG conductors directly, no separate lug needed. The main equipment grounding conductor up to 2/0 AWG lands with a compression or mechanical connector, which you supply to match the conductor and your termination method. Stand-offs for isolated or bonded mounting are also ordered separately.
