Pass & Seymour 40FRBG Series 16 Double Set Screw Panel Mount Connector, 400A 600V

Pass & Seymour 40FRBG Series 16 Double Set Screw Panel Mount Connector, 400A 600V

(No reviews yet) Write a Review

Model: PS40-FRBG
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$124.80
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour 40FRBG Series 16 Double Set Screw Panel Mount Connector, 400A 600V

The Pass & Seymour Series 16 Panel Mount Connector is a heavy-duty double set screw device rated 400A at 600V, built for high-current panel mounting applications where reliable, torque-secure termination is required. This connector is offered across a color family — Orange, Standard, and Yellow — so installers can match job-site color coding while relying on the same 400A, 600V electrical performance and construction across every option. Its nylon housing and heavy-duty brass contact construction deliver consistent conductivity and long-term durability in demanding industrial environments, and every unit in the family shares identical amperage, voltage, and mounting specifications regardless of which color is selected.

Key Features

  • Electrical Rating: 400A, 600V for high-current panel mount connections, consistent across all color options.
  • Heavy-Duty Set Screws: Double set screw termination allows greater termination torque for a secure, reliable connection.
  • Durable Housing: Nylon housing provides outstanding impact and chemical resistance for demanding environments.
  • Contact Construction: Heavy-duty brass male and female contacts provide a superior, consistent means of conductivity.
  • Panel Mount Design: Configured for panel mounting in industrial power distribution setups.
  • Color Options: Available in Orange, Standard, and Yellow to support color-coded circuit identification without any change to the underlying 400A, 600V rating.

Technical Specifications

  • Product Line: Pass & Seymour
  • Country of Origin: Mexico
  • Amperage Rating: 400A
  • Voltage Rating: 600V
  • Packaging: 25 EA
  • Color Options: Orange, Standard, Yellow

Typical Applications

  • Industrial Power Distribution Panels
  • High-Current Panel Mount Connections
  • Commercial and Industrial Electrical Installations
  • Heavy-Duty Termination Requiring High Torque
  • Color-Coded Circuit Identification in Multi-Connector Panels

Why Pass & Seymour?

Pass & Seymour builds the Series 16 Panel Mount Connector with a durable nylon housing and heavy-duty brass contacts to deliver dependable conductivity and long service life. The double set screw design allows for greater termination torque, supporting secure, code-compliant connections in demanding 400A, 600V industrial power applications, and the Orange, Standard, and Yellow color options let electricians standardize color coding without sacrificing performance.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
PASS-20260820
Product Type:
Panel Mount Connector
Voltage Rating:
600V
Amperage Rating:
400A
Connection Type:
Double Set Screw
Product Material:
Nylon
Department:
Electrical
Product Group:
Wiring Devices
Series:
Series 16
Product Subgroup:
Plugs & Connectors

Pass & Seymour PS40-FRBG – Frequently Asked Questions

1) What is the Pass & Seymour 40FRBG Series 16 panel mount connector rated for?
The Series 16 40FRBG panel mount connector is rated 400A at 600V. That rating is the same on all three color versions (Standard, Orange, Yellow), so color coding a panel does not change the electrical capacity you are installing.
2) How do the conductors terminate on the Pass & Seymour 40FRBG connector, and why would I pick set screw over a crimp?
Termination is double set screw. Two screws per contact let you pull more termination torque than a single-screw barrel, which is what you want on a 400A feeder where a loose joint means heat. It is also field-serviceable with hand tools, so no crimp dies or hydraulic press on site, and a conductor can be re-terminated later without cutting back the cable.
3) What are the part numbers for the orange and yellow Pass & Seymour 400A Series 16 panel mount connectors?
Order by color: PS40-FRBG is the standard color, PS40FRB-O is orange, and PS40FRB-Y is yellow. All three are the same 400A, 600V double set screw panel mount device, so the suffix is the only thing that changes.
4) Will the nylon housing on this 400A connector hold up in a wash-down or chemical plant panel?
The housing is nylon, which Pass & Seymour specifies for impact and chemical resistance in industrial environments. The current-carrying parts are heavy-duty brass male and female contacts. That combination is what the Series 16 is built around for industrial power distribution duty, rather than a thermoset or metal shell device.
5) Why would I use different colors of the same Pass & Seymour Series 16 400A connector in one panel?
Color is purely for circuit identification. In a multi-connector panel, orange, yellow and standard let a crew tell phases, sources or feeders apart at a glance without reading labels, and prevents mating the wrong line on a reconnect. Electrically they are identical at 400A, 600V, so you can standardize a site color scheme without juggling two different devices.
6) Is the Pass & Seymour 40FRBG a single-pole device or a multi-pole connector body?
Series 16 is a single-pole connector family. The 40FRBG is one panel mount half with brass male and female contact construction, so a three-phase run means one device per conductor, plus a ground, and the color options are how installers keep those runs straight in the panel.
7) How many of the Pass & Seymour 40FRBG connectors come in a box?
Standard packaging is 25 each. Worth knowing before you spec a panel build: if you need one device per phase plus ground, a box covers roughly six three-phase sets with spares, and any mix of the orange, yellow or standard numbers is ordered separately by part number.
8) Is there a spec sheet for the Pass & Seymour 40FRBG I can attach to a submittal?
Yes, Pass & Seymour publishes a spec sheet for the Series 16 panel mount connector covering the 400A, 600V device. It is the document to pull dimensional and mounting detail from when you are preparing a panel cutout or an electrical submittal package.
