Pemko SA Series 36"; Surface Mount Automatic Door Bottom with GREENGUARD Gold Certified Eco-V Insert

Pemko SA Series 36" Surface Mount Automatic Door Bottom with GREENGUARD Gold Certified Eco-V Insert

(No reviews yet) Write a Review

Model: SA3D-36
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$88.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko SA Series 36"; Surface Mount Automatic Door Bottom with GREENGUARD Gold Certified Eco-V Insert

GREENGUARD Gold Certified Automatic Door Sealing Solution

The Pemko SA Series 36"; Surface Mount Automatic Door Bottom delivers professional-grade sealing performance with eco-friendly GREENGUARD Gold certified materials. This automatic door bottom features precise 36"; length with 1/2"; width and 1-3/8"; height dimensions, designed for surface mounting on architectural and wood doors. The bio-based Eco-V insert construction contains no phthalates or heavy metals while providing exceptional energy-saving performance through superior air infiltration control with 1/2"; maximum drop and 2"; maximum trim capabilities.

Professional Features & Benefits

  • Precise Dimensions: 36"; length with 1/2"; width and 1-3/8"; height for accurate door bottom sealing applications on architectural and wood doors.
  • Maximum Sealing Performance: 1/2"; maximum drop with 2"; maximum trim provides effective sealing against drafts, dust, moisture, insects, fumes, light, and sound.
  • GREENGUARD Gold Certification: Eco-friendly bio-based material construction assists building teams with emissions criteria in green building rating programs.
  • Heavy-Duty Construction: Aluminum substrate with Eco-V insert meets BHMA certification standards for compression and tensile strength.
  • Environmental Safety: Heavy metal free construction with plasticizers from renewable carbon sources and organic-based, zinc-free stabilizers.
  • Superior Durability: Surpasses traditional vinyl quality and durability, resulting in longer service life and reduced replacement needs.
  • Chemical Resistance: Good resistance to adhesives and most mild cleaning solutions with limited UV and weather resistance.
  • Replacement Insert Available: Compatible with EV5 replacement insert for extended service life and maintenance flexibility.

Technical Specifications

  • ANSI/BHMA: Air Infiltration Tested; BHMA Certified; Smoke Tested UL1784; Fire Rated UL10C Positive Pressure; cUL Listed 4L10
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Features: Seals to Keep Out Draft, Dust, Moisture, Insects, Fumes, Light, Sound
  • For Use With: Architectural Doors; Wood Doors
  • Insert Replacement Part Number: EV5
  • Insert Type: Eco-V Insert
  • Product Category: Door Trim and Accessories
  • Product Dimension: W: 1/2", H: 1-3/8 ";
  • Product Function: Automatic Door Bottom
  • Product Group: Door Trim and Accessories
  • Product Length: 36";
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Substrate: Aluminum
  • Product Type: Automatic Door Bottoms
  • Series: SA Series
  • Subcategory: Door Bottoms & Door Shoes

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Pemko Quality?

Pemko SA Series automatic door bottoms deliver professional-grade reliability with aluminum substrate construction and GREENGUARD Gold certified eco-friendly materials that meet BHMA certification standards for compression and tensile strength. ANSI/BHMA air infiltration tested and UL fire rated construction ensures dependable performance in demanding commercial applications where energy efficiency and environmental sealing are essential.

Product Specs

Features:
Seals to Keep Out Draft, Dust, Moisture, Insects, Fumes, Light, Sound
Product Function:
Automatic Door Bottom
Insert Type:
Eco-V Insert
Product Group:
Door Trim and Accessories
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Automatic Door Bottoms
Subcategory:
Door Bottoms & Door Shoes
ANSI/BHMA:
Air Infiltration Tested; BHMA Certified; Smoke Tested UL1784; Fire Rated UL10C Positive Pressure; cUL Listed 4L10
Commercial/Residential:
Commercial
Series:
SA Series
Product Length:
36"
For Use With:
Architectural Doors; Wood Doors
Insert Replacement Part Number:
EV5
Product Dimension:
W: 1/2", H: 1-3/8 "
Product Substrate:
Aluminum
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko SA3D-36 – Frequently Asked Questions

1) Will a Pemko SA Series automatic door bottom seal a fire rated wood door opening?
Yes. The SA Series automatic door bottom is Fire Rated to UL10C Positive Pressure and cUL Listed 4L10, and it is smoke tested to UL1784. It is also air infiltration tested and BHMA certified. It is made for architectural doors and wood doors, so a fire rated wood door leaf is the intended application.
2) How much clearance does a surface mount automatic door bottom need on the face of the door?
The housing is 1/2 inch wide and 1-3/8 inches high. Surface mount means it fastens to the face of the door bottom rail rather than being let into a mortise, so you need 1-3/8 inches of clear rail height and 1/2 inch of projection off the face. Nothing on the stop side, closer arm, or bottom rail hardware can sit in that footprint. If you need the seal buried in the door edge, a surface mount unit is the wrong choice and a mortised automatic door bottom is what you want.
3) When the seal on my Pemko SA door bottom wears out, do I have to replace the whole unit?
No. The Eco-V insert is a separate replacement part, ordered as EV5. The aluminum housing stays on the door and you swap just the seal, which is the practical answer for a facility running these on a lot of openings.
4) Can I use a Pemko SA automatic door bottom on an exterior door?
Keep it on interior openings. The Eco-V insert has good resistance to adhesives and most mild cleaning solutions but only limited UV and weather resistance, so direct sun and weather exposure will shorten its life. It is a commercial-rated product, and it is at its best on interior corridor, stair, smoke, and tenant separation doors where it seals draft, dust, moisture, insects, fumes, light, and sound.
5) What is the difference between a surface mount automatic door bottom and a plain door sweep?
A sweep drags on the floor all the time. The SA Series is an automatic door bottom: the seal retracts up into the aluminum housing while the door swings and drops as the door closes, so it clears carpet and finished flooring on the swing and still seals when shut. That drop is limited to 1/2 inch. Use the automatic bottom where the floor covering or threshold would chew up a fixed sweep, or where you need the smoke and air seal only when the door is closed.
6) Does the Pemko SA Series automatic door bottom help with a GREENGUARD or green building submittal?
The Eco-V insert is GREENGUARD Gold certified, which is what a project team cites against emissions criteria in green building rating programs. The insert is bio-based, contains no phthalates or heavy metals, and uses plasticizers from renewable carbon sources with organic-based, zinc-free stabilizers. That is the part of the assembly the emissions criteria care about; the housing is aluminum.
