Pemko 412 Series Surface Mounted Automatic Door Bottom with EPDM Insert and Fire Rating

Pemko 412 Series Surface Mounted Automatic Door Bottom with EPDM Insert and Fire Rating

(No reviews yet) Write a Review

Model: 412CRL-30
$89.46
$79.51
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$89.46
$79.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 412 Series Surface Mounted Automatic Door Bottom with EPDM Insert and Fire Rating

Professional Automatic Door Sealing Solution

The Pemko 412 Series Surface Mounted Automatic Door Bottom provides comprehensive sealing against light, sound, smoke, and fire when doors are closed. This handed door bottom features aluminum construction with H: 2", W: 9/16"; dimensions and includes EPDM insert for reliable sealing performance. Custom cut to length with installation hardware included, this door bottom meets multiple ASTM and UL testing standards including UL10C fire rating and GREENGUARD Gold certification for commercial applications.

Professional Features & Benefits

  • Precise Dimensions: H: 2", W: 9/16"; aluminum casing designed for surface mounting on architectural doors with optimal clearance requirements.
  • Comprehensive Testing Certifications: Air infiltration tested to ASTM E-283-04, sound tested to ASTM E90-2009, smoke tested to UL1784, and fire rated to UL10C positive pressure standards for code compliance.
  • EPDM Insert Technology: High-quality EPDM rubber insert delivers reliable sealing with excellent weather resistance and durability for long-term performance.
  • Durable Aluminum Construction: Professional-grade aluminum substrate provides long-lasting performance in demanding commercial applications.
  • Custom Length Configuration: Door bottom is custom cut to required length for precise fit and optimal sealing performance on various door widths.
  • GREENGUARD Gold Certification: Meets strict chemical emissions standards for healthy indoor air quality in commercial environments.
  • Complete Installation Package: Includes installation instructions and mounting screws for professional installation.
  • Manufacturer Warranty: 5 Year warranty coverage provides confidence and protection for commercial installations.

Technical Specifications

  • ANSI/BHMA: Air Infiltration Tested �� Tested to ASTM E-283-04 (2012); Sound Tested �� Tested to ASTM E90 �� 2009; Smoke Tested - UL1784; Fire Rated - UL10C - Positive Pressure; Underwriters Laboratory 4L10; GREENGUARD Gold Certified
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • For Use With: Architectural Doors
  • Insert Type: EPDM insert
  • Product Category: Door Trim and Accessories
  • Product Dimension: H: 2", W: 9/16";
  • Product Function: Automatic Door Bottom
  • Product Group: Door Trim and Accessories
  • Product Model: 412
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Substrate: Aluminum
  • Product Type: Door Bottoms
  • Subcategory: Door Bottoms & Door Shoes
  • Warranty: 5 Year

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Pemko Quality?

Pemko 412 Series automatic door bottoms deliver professional-grade sealing performance with aluminum construction and comprehensive testing certifications including ASTM E-283-04, ASTM E90-2009, UL1784, and UL10C standards. 5 Year warranty coverage and GREENGUARD Gold certification demonstrate commitment to quality and indoor air quality. Engineered for demanding commercial applications where reliable sealing against light, sound, smoke, and fire is essential.

Product Specs

Insert Type:
EPDM insert
Warranty:
5 Year
Subcategory:
Door Bottoms & Door Shoes
Product Group:
Door Trim and Accessories
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Bottoms
ANSI/BHMA:
Air Infiltration Tested – Tested to ASTM E-283-04 (2012); Sound Tested – Tested to ASTM E90 – 2009; Smoke Tested - UL1784; Fire Rated - UL10C - Positive Pressure; Underwriters Laboratory 4L10; GREENGUARD Gold Certified
Commercial/Residential:
Commercial
Product Model:
412
Product Function:
Automatic Door Bottom
For Use With:
Architectural Doors
Product Dimension:
H: 2", W: 9/16"
Product Substrate:
Aluminum
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko 412CRL-30 – Frequently Asked Questions

1) Will a Pemko 412 automatic door bottom work on a fire rated door?
Yes. The Pemko 412 automatic door bottom is fire rated to UL10C positive pressure and smoke tested to UL1784, so it can go on a rated opening where the smoke and fire seal has to hold up under test. It is also air infiltration tested to ASTM E-283-04 (2012) and sound tested to ASTM E90-2009, which is what gets it onto acoustic and air-leakage specs for offices and healthcare corridors.
2) How much clearance under the door does the Pemko 412 need, and does it mount on the door face?
The 412 is a surface mounted unit that screws to the face of the door at the bottom rail, so it hangs below the door rather than sitting in a routed pocket. The aluminum casing measures H: 2 inches, W: 9/16 inches, so plan on the housing occupying roughly two inches of door face height and projecting 9/16 of an inch off the face. Because it is surface applied, no mortise pocket has to be cut, which is why it is the usual pick for retrofitting an existing door.
3) Do I need to specify handing when ordering a Pemko 412 door bottom?
Yes, the 412 is a handed automatic door bottom. The plunger that trips the seal sits at the hinge or strike end depending on hand, so a left hand unit will not operate correctly on a right hand door. Confirm the door swing before you order, and if you are doing a floor of openings, count lefts and rights separately.
4) Should I use an automatic door bottom or just a door sweep?
A sweep drags on the floor the whole time the door moves. An automatic door bottom like the Pemko 412 stays retracted while the door swings and drops the seal only when the door closes against the stop, which is what you want over carpet, over a finished floor you do not want scuffed, or where drag would fight a closer set for accessible opening force. The 412 seals against light, sound, smoke and fire when closed. If the opening has a big undercut and nobody cares about drag, a plain sweep is simpler and cheaper to install.
5) Does the Pemko 412 come with mounting screws or do I have to buy them separately?
Mounting screws and installation instructions ship with the 412. Nothing else is required to attach it to the door face. What is not included is the mating threshold or saddle it seals down onto, so if the opening does not already have a flat surface at the sill, that gets ordered separately.
6) Is the Pemko 412 suitable for a school or hospital where indoor air quality is specified?
It is GREENGUARD Gold certified, which is the chemical emissions standard schools and healthcare facilities most often write into their specs. Combined with the UL1784 smoke test and UL10C fire rating, the 412 covers both the life safety and the IAQ line items on a typical institutional door hardware schedule. It is a commercial rated product intended for architectural doors.
7) Can I cut a Pemko 412 automatic door bottom down to fit a narrower door?
Yes, the 412 is meant to be cut to length for the opening. Order the next size up from your door width out of the 30, 36, 42 and 48 inch options and trim the aluminum housing and insert to suit. That is how one part number covers a building full of slightly different leaf widths.
8) What finishes does the Pemko 412 automatic door bottom come in, and will it match my other door hardware?
Two anodized aluminum finishes: clear anodized and dark bronze anodized. Clear anodized reads as a natural silver aluminum and blends with aluminum storefront and most brushed hardware. Dark bronze anodized matches dark bronze storefront and dark finish exit devices. Both are available in all four lengths and with either insert, so finish does not restrict your other choices.
9) Will an automatic door bottom help with sound transfer between a corridor and an office?
The gap under the door is usually the biggest acoustic leak in an opening, and the Pemko 412 closes it: it is sound tested to ASTM E90-2009 and air infiltration tested to ASTM E-283-04 (2012). The EPDM insert compresses against the floor or threshold when the door latches. For it to do anything for you the rest of the opening has to be sealed too, since head and jamb gaps will leak just as readily.
10) Will the Pemko 412 hold up on an exterior door?
The housing is extruded aluminum in an anodized finish and the seal is EPDM, a rubber that stands up to weather and UV better than most, so the 412 is built for that exposure. It is air infiltration tested to ASTM E-283-04 (2012), which is the test that matters for stopping drafts at a perimeter door. Note it seals only when the door is closed, so it does nothing for a door propped open.
