Philips Lighting IL336-AL WELLYTE Inground Well Light, Black, 12V, 20W PAR36 Landscape Fixture

Philips Lighting IL336-AL WELLYTE Inground Well Light, Black, 12V, 20W PAR36 Landscape Fixture

(No reviews yet) Write a Review

Model: IL336-AL
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$253.06
$203.06
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting IL336-AL WELLYTE Inground Well Light, Black, 12V, 20W PAR36 Landscape Fixture

The Philips Lighting IL336-AL is a WELLYTE inground well light built for low-voltage landscape and architectural accent lighting. This 12V fixture ships complete with a 20W PAR36 incandescent lamp and is rated for lamps up to 50W, giving installers flexibility to dial in brightness for the application. Finished in black for a discreet, low-profile appearance once installed, the fixture is designed to uplight trees, walls, and landscape features directly from ground level, concealing the housing while projecting light upward for dramatic outdoor accent effects.

Key Features

  • Voltage: Engineered for 12V low-voltage landscape lighting systems.
  • Lamp Included: Ships complete with a 20W PAR36 incandescent lamp (Lamp Source Code: INC).
  • Fixture Rating: WELLYTE inground well light rated for lamps up to 50W, allowing flexible brightness options.
  • Finish: Black housing delivers a low-profile, discreet outdoor appearance.
  • Configuration: Inground well-light design ideal for uplighting trees, facades, and landscape features.
  • Compact Footprint: Lightweight fixture (0.010 kg net weight) designed for straightforward inground installation.

Technical Specifications

  • Lamp Source Code: INC
  • Lamp Watts: 20
  • Numerator Packs Per Outer Box: 1
  • Numerator Quantity Per Pack: 1
  • Order Product Name: WELLYTE,12V,50W,W/20W PAR36

Typical Applications

  • Landscape and Garden Uplighting
  • Inground Accent Lighting for Trees and Architecture
  • Low-Voltage Outdoor Lighting Systems
  • Commercial and Residential Landscape Design
  • Path, Facade, and Feature Illumination

Why Philips Lighting?

Philips Lighting brings proven lighting engineering to the WELLYTE series, delivering an inground well light built for reliable outdoor performance. The 12V low-voltage platform and included 20W PAR36 lamp make this fixture a ready-to-install solution for landscape and outdoor lighting professionals, while the black finish and inground housing keep installations clean and unobtrusive. Choose this WELLYTE well light for professional-grade, low-voltage accent lighting backed by the Philips Lighting name.

Manufacturer Resources

Spec Sheet

Product Specs

Catalog Number:
IL336-AL
Catalog Number Description:
Inground, Well-light w/ Lamp, Black, 20W PAR 36 12V
Ean Upc Product:
7.83352E+11
Lamp Source Code:
INC
Lamp Watts:
20
Material Nr 12nc:
9.124E+11
Net Weight Piece:
0.010 kg
Numerator Packs Per Outer Box:
1
Numerator Quantity Per Pack:
1
Order Code:
9.124E+11
Order Product Name:
WELLYTE,12V,50W,W/20W PAR36
Voltages:
12 V
Product Type:
Landscape Light
Department:
Electrical
Product Group:
Lighting
Product Subgroup:
Light Fixtures

Philips Lighting IL336-AL – Frequently Asked Questions

1) Does the Philips IL336-AL well light come with a lamp, or do I need to order one separately?
The IL336-AL ships as an inground well light with the lamp included: a 20W PAR 36 running at 12 volts. You don't need to source the lamp separately to get the fixture working, though you will need a 12V supply on the circuit.
2) Can I wire the IL336-AL well light directly to 120V line voltage?
No. The IL336-AL is a 12 volt fixture, so it has to run off the secondary side of a low voltage landscape transformer. Feeding it 120V line voltage will destroy the lamp. If your run is on line voltage, you need a 120V-to-12V transformer sized for the total connected load on that circuit.
3) What replacement lamp does the Philips IL336-AL well light take?
It takes a PAR 36 lamp at 12 volts, supplied at 20 watts. PAR 36 is a sealed-beam style low voltage landscape lamp, so when you re-lamp you match the PAR 36 form factor and 12V rating. The catalog source code for the supplied lamp is incandescent (INC).
4) Is this Philips well light meant to be buried in the ground or surface mounted?
Inground. The IL336-AL is a well light, meaning the housing sets into the grade and the lens sits at or near ground level, aiming light upward. It is the fixture type used for uplighting building facades, columns, flagpoles, and trees where you don't want a visible fixture body above the landscape.
5) What part number should I put on the purchase order for this Philips well light?
Order it as Philips catalog number IL336-AL. That is also the manufacturer part number carried on the fixture, and the catalog description behind it reads inground well light with lamp, black, 20W PAR 36 12V.
6) How many 20W well lights can I put on one low voltage landscape transformer?
Each IL336-AL draws 20 watts at 12 volts, so divide your transformer's secondary rating by 20 to get the fixture count, then leave headroom for voltage drop on long runs. A 300VA transformer, for example, covers fifteen of these at full load, and you'd normally load it lighter than that.
7) What finish does the IL336-AL well light come in, and will it match the rest of my landscape fixtures?
The IL336-AL is finished in black, which is the standard landscape fixture color and the one most inground and path lights on a commercial property are specified in. If your existing site fixtures are bronze or verde, this one will not match visually, though on an inground well light most of the body sits below grade and only the trim ring shows.
8) How is the Philips IL336-AL packaged if I'm ordering a quantity for a whole site?
It's packed one per pack and one pack per outer carton, so each order unit is a single fixture with its lamp. Ordering twelve for a facade run means twelve individual cartons, not a case quantity.
How fast can I get the Philips Lighting IL336-AL delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Philips Lighting IL336-AL come with a warranty?
Absolutely. The Philips Lighting IL336-AL is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Philips Lighting IL336-AL?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
