Panduit H000X025H1M 0.27" White Polyolefin Heat Shrink Label for MP Printers
The Panduit H000X025H1M is a 0.27" white polyolefin heat shrink label engineered for seamless compatibility with MP printer cable and wire marking systems. Designed for 22-18 AWG wire applications with a cable diameter range from 0.055" to 0.15", this label delivers military grade resistance properties and reliable performance across a wide operating temperature range of -40°F to 257°F. RoHS compliant construction makes it a durable, professional-grade solution for cable and wire identification in demanding electrical environments.
Key Features
- Label Width: 0.27" (6.8mm) sized for clear, readable cable and wire identification in standard wire management applications.
- Durable Construction: White polyolefin material provides superior chemical resistance and long-term identification reliability.
- MP Printer Compatibility: Engineered specifically for seamless integration with MP printer systems for consistent, professional results.
- Wire & Cable Range: Compatible with 22-18 AWG wire gauges and cable diameters from 0.055" to 0.15", covering common gauges in professional electrical installations.
- Military Grade Resistance: Enhanced durability properties ensure reliable performance in challenging industrial environments.
- Wide Temperature Range: Operates reliably from -40°F to 257°F (-40°C to 125°C) for diverse application environments.
- Roll Length: 8.2 ft (2.5 m) per roll for extended, continuous labeling runs.
Certifications & Compliance
- RoHS Compliant
- California Prop 65 Cancer Designation: No
- Hazardous Material Flag: No
- Mercury Content Indicator: No
- Reach Status: No
Technical Specifications
- Label Width: 0.27" (6.8mm)
- Maximum Cable Diameter: 0.15" (3.8mm)
- Minimum Cable Diameter: 0.055" (6.8mm)
- Maximum Operating Temperature: 257°F (125°C)
- Minimum Operating Temperature: -40°F (-40°C)
- Compatible Wire Gauge: 22-18 AWG
- Roll Length: 8.2 ft (2.5 m)
- Product Material: Polyolefin
- Product Color: White
- Country of Origin: Japan
Typical Applications
- Industrial Cable Management Systems
- Commercial Electrical Installations
- Data Center Wire Identification
- Manufacturing Facility Wiring
- Telecommunications Infrastructure
- Control Panel Wire Marking
Why Panduit?
Panduit delivers proven reliability with RoHS compliant construction and military grade resistance properties built into every label. The white polyolefin material ensures long-term durability and clear identification across a wide operating temperature range from -40°F to 257°F, giving electrical professionals a dependable cable and wire marking solution for MP printer systems.
Manufacturer Resources
Product Specs
- California Pro65 Cancer:
- N
- Compatible Wire Gauge Awg:
- 22-18
- Ean:
- 3.06131E+13
- GTIN Carton:
- 5.06131E+13
- GTIN Package:
- 3.06131E+13
- Hazardous Material Flag:
- N
- Label Application:
- Cable & Wire Marking
- Label Width In:
- 0.27
- Label Width Mm:
- 6.8
- Maximum Cable Diameter (In.):
- 0.15
- Maximum Cable Diameter (mm):
- 3.8
- Maximum Operating Temperature (°C):
- 125
- Maximum Operating Temperature (°F):
- 257
- Mercury Content Indicator:
- N
- Min Order Qty:
- 1
- Minimum Cable Diameter (In.):
- 0.055
- Minimum Cable Diameter (mm):
- 6.8
- Minimum Operating Temperature (°C):
- -40
- Minimum Operating Temperature (°F):
- -40
- Note:
- For use with MP printers
- Pallet Quantity:
- 9,240
- Pallet Volume:
- 2.666927
- Pallet Weight:
- 2,910.60
- Product Color:
- White
- Product Material:
- Polyolefin
- Product Segment:
- IEI
- Product Type:
- Printer Label
- REACH Status:
- N
- Resistance Properties:
- Military Grade
- Rohs Compliant:
- Compliant
- Roll Length Ft:
- 8.2
- Roll Length M:
- 2.5
- Standard Carton Volume Ft3:
- 0.0346
- Standard Carton Weight Pounds:
- 37.8
- Standard Package Volume Ft3:
- 0.0014
- Standard Package Weight Pounds:
- 1.575
- Std Carton Height In:
- 7.9
- Std Carton Height MM:
- 200.66
- Std Carton Length In:
- 18.1
- Std Carton Length MM:
- 459.74
- Std Carton Width In:
- 12.2
- Std Carton Width MM:
- 309.88
- Std Ctn Qty:
- 120
- Std Package Height In:
- 3
- Std Package Height MM:
- 76.2
- Std Package Length In:
- 5.7
- Std Package Length MM:
- 144.78
- Std Package Width In:
- 3.5
- Std Package Width MM:
- 88.9
- Std. Pkg. Qty.:
- 5
- Std. Pkg. UOM:
- Piece
- Department:
- Electrical
- Product Group:
- Cable Management & Identification
- Product Subgroup:
- Wire Markers & Labels
Panduit H000X025H1M – Frequently Asked Questions
1) What wire size does the Panduit H000X025H1M heat shrink label fit?
The H000X025H1M is sized for 22-18 AWG conductors, with a cable diameter window of 0.055 in to 0.15 in (up to 3.8 mm). If the bundle or jacket you are marking measures outside that range, the sleeve either will not slide on or will not recover tight enough to stay put, so measure the finished OD rather than going by gauge alone on jacketed cable.
2) Will Panduit H000X025H1M labels run in any thermal transfer printer?
No. These sleeves are made for Panduit MP series handheld printers. Loading them in a different printer platform is not supported, so if your shop runs a different marking system you need the sleeve format built for it.
3) Can these heat shrink wire markers handle a hot control panel or an outdoor enclosure?
Rated from -40 F to 257 F (-40 C to 125 C), so they hold up in unconditioned mechanical rooms, outdoor enclosures in cold climates, and control panels that run warm. The polyolefin also carries military grade resistance properties for chemical and abrasion exposure in industrial areas.
4) How much labeling do I get from one roll of H000X025H1M?
Each roll holds 8.2 ft (2.5 m) of continuous 0.27 in wide white sleeve. Standard packaging is 5 pieces, and the standard carton holds 120, which is the number to quote from when you are stocking a panel shop or an MRO crib rather than buying for one job.
5) Why use a heat shrink sleeve instead of a wrap-around adhesive wire label?
A shrink sleeve slides over the conductor and recovers onto it, so there is no adhesive to creep or peel in heat, oil, or cleaning chemicals, and the marker cannot be pulled off in a pull box. The tradeoff is that it must be installed before the conductor is terminated, or the end has to be disconnected. Wrap-around adhesive labels are the choice when you are re-identifying wire already landed on a terminal strip.
6) Are Panduit H000X025H1M labels RoHS compliant for a spec-driven job?
Yes, RoHS compliant, with no mercury content and no California Prop 65 cancer designation. They are not flagged as hazardous material, which keeps shipping and site documentation simple. Country of origin is Japan.
7) Is 0.27 inch wide enough to read a circuit number on a data center patch cable?
The 0.27 in (6.8 mm) width gives a legible print field for the short circuit, port, and panel designations used in data center and telecom work on small conductors. For long descriptive text or larger bundles you would step up to a wider sleeve in the same family rather than crowding this one.
8) What is the minimum order on the Panduit H000X025H1M shrink label?
One piece is the minimum, so a single roll can be bought for a punch list item. Volume buyers order by the 120-piece carton or the 9,240-piece pallet.
