RAB 150W LED Wall Pack with Field-Adjustable CCT - 21,514-25,458 Lumens, Bronze Finish

RAB 150W LED Wall Pack with Field-Adjustable CCT - 21,514-25,458 Lumens, Bronze Finish

(No reviews yet) Write a Review

Model: WP3FA150

In Stock (leaves warehouse same day if ordered before 3pm ET)

$352.04
$270.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

RAB 150W LED Wall Pack with Field-Adjustable CCT

Professional LED lighting with field-adjustable color temperature for versatile commercial applications

The RAB 150W LED Wall Pack delivers exceptional performance with field-adjustable color temperature technology, providing 21,514-25,458 lumens of reliable illumination. This professional-grade fixture features a durable bronze finish and constant current driver for consistent operation across multiple voltage inputs from 120V to 277V. With DLC Premium certification and 100,000-hour lamp life, this wall pack ensures long-term reliability for demanding commercial and industrial applications.

Professional Features & Benefits

  • 150W LED Technology: Delivers high-efficiency lighting with 137.3-149.5 efficacy rating for optimal energy performance and cost savings.
  • Field-Adjustable CCT: Allows on-site color temperature selection to match specific application requirements and preferences.
  • 21,514-25,458 Lumen Output: Provides powerful illumination coverage suitable for large commercial and industrial areas.
  • Multi-Voltage Compatibility: Operates on 120V, 208V, 240V, and 277V systems with corresponding amperage ratings for flexible installation.
  • DLC Premium Certification: Meets stringent energy efficiency standards for utility rebate eligibility and professional compliance.
  • Bronze Finish: Offers durable, weather-resistant coating that complements architectural aesthetics while providing long-lasting protection.
  • 100,000-Hour Lamp Life: Ensures extended service intervals and reduced maintenance costs for professional applications.

Technical Specifications

  • Amps 120: 1.30A
  • Amps 208: 1.00A
  • Amps 240: 0.80A
  • Amps 277: 0.60A
  • Dlc Id: PLZ8ROXMXGF6
  • Dlc Type: DLC Premium
  • Dlc Version: 5.1
  • Driver Info: Constant Current
  • Efficacy: 137.3/149.5/138.8
  • Input Watts: 156.7/155.4/154.5
  • Lamp Hours: 100000
  • Lamp Info: LED
  • Lamp Lumens: 21514/23223/21438
  • Product Finish: Bronze
  • Product Height: 12.2
  • Product Length: 19.17
  • Product Watts: 150
  • Product Weight: 11.46
  • Product Width: 11.5

Professional Applications

  • Commercial Building Perimeter Lighting
  • Industrial Facility Security Illumination
  • Retail Center Exterior Lighting
  • Office Complex Wall Mounting
  • Warehouse and Distribution Centers
  • Municipal and Government Buildings
  • Educational Institution Exterior Areas

Why Choose RAB Quality?

RAB delivers professional-grade LED lighting solutions with DLC Premium certification and 100,000-hour lamp life, ensuring reliable performance and energy efficiency. The constant current driver technology and multi-voltage compatibility provide consistent operation across diverse electrical systems, while the durable bronze finish offers long-term weather resistance for demanding commercial applications.

Manufacturer Resources

Product Specs

Amps 120:
1.30A
Amps 208:
1.00A
Amps 240:
0.80A
Amps 277:
0.60A
Dlc Id:
PLZ8ROXMXGF6
Dlc Type:
DLC Premium
Dlc Version:
5.1
Driver Info:
Constant Current
Efficacy:
137.3/149.5/138.8
Input Watts:
156.7/155.4/154.5
Lamp Hours:
100000
Product Finish:
Bronze
Product Height:
12.2
Product Length:
19.17
Product Weight:
11.46
Product Width:
11.5
Department:
Electrical
Product Group:
Flood/Security Lights
Light Technology:
LED
Lumens:
21514/23223/21438
Product Wattage:
150

RAB WP3FA150 – Frequently Asked Questions

1) Will the RAB WP3FA150 wall pack run on 277V, or do I need a different model for each voltage?
One fixture covers all of it. The WP3FA150 accepts 120V through 277V, drawing 1.30A at 120V, 1.00A at 208V, 0.80A at 240V and 0.60A at 277V. That means an electrician can stock a single part number for a site with mixed panel voltages and size the branch circuit off the amp figure for whatever voltage the building actually runs.
2) What does field-adjustable CCT actually change on the RAB 150W wall pack - does output drop at the warmer setting?
Yes, output shifts with the setting. The three CCT positions deliver 21,514, 23,223 and 21,438 lumens, at efficacies of 137.3, 149.5 and 138.8 lumens per watt, with input watts of 156.7, 155.4 and 154.5. The middle setting is the brightest and most efficient; the two ends give up roughly 1,700 lumens. The switch is on the fixture, so you set it on the pole or wall at install rather than ordering a specific color temperature.
3) Does this RAB wall pack qualify for a utility LED rebate?
It is listed DLC Premium under DLC technical requirements version 5.1, with DLC ID PLZ8ROXMXGF6. Premium is the tier most utilities require for their higher rebate amounts, and the DLC ID is the number the rebate application asks for, so you can submit it without chasing the manufacturer for paperwork.
4) Do I need to add a separate photocell for dusk-to-dawn operation on the RAB WP3FA150?
No. The WP3FA150 is supplied with a selectable photocell built in, so dusk-to-dawn switching is part of the fixture and no external photo control or stem-mount cell is required on the circuit. Wire it to an unswitched hot and it will handle the on/off itself.
5) How big and heavy is the RAB WP3FA150 wall pack - will it mount on a standard junction box?
It is a large fixture: 19.17 long by 11.5 wide by 12.2 high, weighing 11.46 pounds. At that weight and size, treat the mounting surface accordingly - a lightweight plastic box or a thin panel will not carry it, and it needs backing or a properly secured steel box. Check your clearance above doors and signage too, since a 12.2 inch tall housing projects more than a small compact wall pack.
6) Is a 150W LED wall pack enough to replace a 400W metal halide on a loading dock?
Output-wise, yes. The WP3FA150 puts out 21,514 to 23,223 lumens at roughly 155 input watts, which is in the range a 400W metal halide delivers after lamp depreciation, at about a third of the draw. The LED also holds its output far longer, rated 100,000 hours against the frequent relamping an HID head needs. For dock faces and warehouse perimeters that is the usual one-for-one swap.
7) What finish does the RAB 150W field-adjustable wall pack come in, and will it match the rest of my building's exterior fixtures?
Bronze only. If your perimeter already runs bronze wall packs and pole heads, it drops in without a visual mismatch. Spec'ing a white or architectural-color facade, you would need a different fixture family, because bronze is the single finish on the WP3FA150.
8) Can the RAB WP3FA150 be put on a dimmer or occupancy control?
The WP3FA150 uses a constant current driver. That is what keeps light output steady as line voltage moves across the 120V to 277V range, and it is the standard driver type for commercial LED wall packs. The fixture's own control is the selectable photocell it ships with, for dusk-to-dawn switching.
