Eaton Replacement Coil for 511 Shoe Brake, Type S

Eaton Replacement Coil for 511 Shoe Brake, Type S

(No reviews yet) Write a Review

Model: 9-591-3

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,359.31
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Replacement Coil for 511 Shoe Brake, Type S

The Eaton Replacement Coil for 511 Shoe Brake, Type S is a renewal part engineered for Eaton's current line of 511 shoe brakes. Sized for 4 inch brake assemblies and compatible with 3, 10, and 15 lb torque ratings, this coil is built as a direct-fit replacement component to restore braking performance without replacing the entire brake unit. Measuring 4 in wide, 3.75 in in length/depth, and 5.75 in in height, it is classified by Eaton as a Renewal Parts/Accessories item for maintenance and repair of existing 511 brake installations.

Key Features

  • Compact Dimensions: Measures 4 in wide x 3.75 in deep x 5.75 in high, sized to fit directly into 511 shoe brake housings.
  • Brake Size Compatibility: Designed for the 4 inch brake size used across 3 lb, 10 lb, and 15 lb torque configurations.
  • Type S Configuration: Manufactured to Eaton's Type S specification for consistent fit and function within the 511 brake series.
  • Renewal Parts Classification: Categorized by Eaton as a Renewal Parts/Accessories item, purpose-built as a direct replacement rather than a new assembly.
  • Current Product Line Fit: Per Eaton catalog notes, this coil is a part for the current line of 511 brakes, supporting long-term serviceability of installed units.

Technical Specifications

  • Warranty: Not Applicable
  • Product Type: Coil
  • Department: Electrical
  • Product Width: 4 in
  • Product Length/Depth: 3.75 in
  • Product Height: 5.75 in
  • Catalog Notes: Part for Current line of 511 brakes

Typical Applications

  • Shoe Brake Assembly Repair and Maintenance
  • Motor-Mounted Brake Systems
  • Industrial Equipment Renewal Parts Programs
  • 511 Series Brake Servicing
  • Preventive Maintenance on Existing Brake Installations

Why Eaton?

Eaton engineers renewal parts like this Type S coil to match the exact fit and function of the original 511 shoe brake components, helping maintenance teams restore reliable braking performance without full unit replacement. Backed by Eaton's catalog documentation for the current 511 brake line, this coil supports dependable, code-compliant servicing of installed industrial brake systems.

Manufacturer Resources

Product Specs

Product Width:
4 in
Warranty:
Not Applicable
Catalog Notes:
Part for Current line of 511 brakes
Product Length/Depth:
3.75 in
Product Height:
5.75 in
Product Type:
Coil
Certifications:
Not Applicable
Department:
Electrical
Series:
511
Product Group:
Motor Control & Automation
Product Subgroup:
Contactors & Relays
Product Weight:
1.06 lb
Product Length:
3.75 in

Eaton 9-591-3 – Frequently Asked Questions

1) Does one Eaton 511 coil cover 3, 10 and 15 lb torque brakes, or do I need a different coil per torque?
One part covers all three. The Type S coil is specified for the 4 inch 511 brake across the 3 lb, 10 lb, and 15 lb torque ratings, so a maintenance crew stocking spares for a mixed set of 511 brakes at that frame size can standardize on this single coil instead of carrying three.
2) What part number do I order for the Eaton 511 shoe brake replacement coil?
Order Eaton part 9-591-3, the Type S coil in the 511 series. There is a single configuration, so there is no voltage or size option to specify on the order. Confirm your brake is from the current 511 line, since that is what Eaton lists this coil against.
