Eaton Replacement Solenoid Coil, Renewal Part
The Eaton Replacement Solenoid Coil is a genuine renewal part/accessory engineered to restore proper operation to Eaton solenoid assemblies, such as Size A configurations rated 110V/60Hz. Designed as a direct-fit replacement coil, it allows maintenance teams to service existing solenoid hardware rather than replacing the entire assembly, helping minimize downtime and repair cost. As a manufacturer renewal part, it is built to match original Eaton solenoid coil specifications for dependable, code-compliant performance in industrial and commercial electrical systems.
Key Features
- Renewal Part: Classified as a Renewal Parts/Accessories item, designed specifically to service and restore existing Eaton solenoid assemblies.
- Solenoid Coil Design: Sized for Size A solenoid configurations, ensuring proper fit and function within compatible assemblies.
- Voltage Compatibility: Manufactured for 110V/60Hz solenoid applications, matching original equipment electrical requirements.
- Precision OEM Fit: Built to Eaton specifications so the replacement coil integrates seamlessly with existing solenoid hardware.
- Simplified Maintenance: Enables straightforward swap-in replacement of a worn or failed coil without requiring full solenoid assembly replacement.
- Reliable Operation: Supports consistent solenoid actuation and electrical performance once installed.
Technical Specifications
- Product Type: Coil
- Type: Renewal Parts/Accessories
- Certifications: Not Applicable
Typical Applications
- Motor Control Centers and Contactor Assemblies
- Industrial Solenoid and Relay Systems
- Panelboard and Switchgear Maintenance
- Repair and Servicing of Eaton Solenoid Components
- Commercial and Industrial Electrical Maintenance Programs
Why Eaton?
Eaton renewal parts are manufactured to match original equipment specifications, giving electrical professionals a dependable way to service solenoid assemblies without full replacement. Choosing genuine Eaton components like this replacement coil helps maintain consistent, reliable performance across motor control and switching equipment used in professional electrical installations.
Manufacturer Resources
Product Specs
- Product Width:
- .01 in
- Product Height:
- .01 in
- Product Type:
- Contactor Coil
- Product Length/Depth:
- .01 in
- Certifications:
- Not Applicable
- Department:
- Electrical
- Product Group:
- Motor Control & Automation
- Product Subgroup:
- Contactors & Relays
- Product Length:
- 0.01 in
- Product Weight:
- 0.01 lb
Eaton 9-584-1 – Frequently Asked Questions
1) What voltage is the Eaton 9-584-1 replacement solenoid coil wound for?
The Eaton 9-584-1 renewal coil is built for 110V/60Hz solenoid applications, matching the original equipment electrical rating. If the coil you are pulling out is a different voltage or a 50Hz coil, this is not the right replacement part.
2) My control circuit runs on 24 volts - is the Eaton 9-584-1 coil the right choice?
No. The Eaton 9-584-1 coil is manufactured for 110V/60Hz solenoid applications and must match the original equipment coil voltage. For a 24VAC 60Hz control circuit, the Square D Type S 31041400 series coil is the 24VAC option, covering NEMA Size 00, 0 and 1. Always match the coil voltage stamped on the existing coil to the control circuit.
3) Is the Eaton 9-584-1 an OEM part or an aftermarket coil?
Genuine Eaton renewal part, built to Eaton's original coil specifications rather than an aftermarket copy. For plants that standardize on Eaton motor control gear and need the service record to stay OEM, that matters more than the coil itself.
4) How do I make sure I order the right Eaton solenoid coil?
Order by the Eaton part number 9-584-1, sold as model 95841. Confirm three things off the coil you are removing: Eaton branding, Size A frame, and a 110V 60Hz nameplate. Coil part numbers within a solenoid family differ only by voltage, so the nameplate is the check that keeps you from a return.
5) Does coil sizing work the same way between the Eaton 9-584-1 and Square D coils?
They use different sizing language. The Eaton 9-584-1 is specified for Size A Eaton solenoid configurations. The Square D Type S 31041400 series coil is specified by NEMA starter size, covering Size 00, 0 and 1. Because the size designations refer to each manufacturer's own frames, you identify the coil from the assembly it came out of rather than cross-reading the size letters and numbers.
6) Where is this Eaton replacement coil typically used?
Motor control centers and contactor assemblies, industrial solenoid and relay systems, and panelboard or switchgear maintenance work. It is a maintenance and repair item, not a component you would design into a new panel build.
