Rittal 62 Series CP Swivel Coupling, Die-Cast Zinc
Rittal's CP Swivel Coupling mounts housings to the vertical section of Rittal's 62 Series modular support arm system, available for both the 60 and 120 support arm systems in CP 60 and CP 120 configurations. Machined from die-cast zinc for long-term durability, this rotating/tilting coupling finishes in RAL 7035 and ships complete with the self-tapping screws and seals needed for support section attachment. It serves as a purpose-built connection point for integrating enclosures, monitor housings, and control panel components onto Rittal support arm infrastructure in industrial and commercial installations.
Key Features
- Swivel Mounting: Couples the housing to the vertical section of the 60 or 120 support arm system for adjustable, flexible positioning as equipment orientation needs change.
- Durable Construction: Die-cast zinc body provides strength, dimensional stability, and long-term mechanical reliability under continuous use in industrial environments.
- Rotating/Tilting Function: Built-in rotate/tilt capability allows the mounted housing to be angled and oriented as needed for optimal viewing or access.
- Factory Finish: RAL 7035 finish delivers a clean, consistent appearance that matches Rittal support arm and enclosure systems for a uniform installation look.
- Complete Mounting Hardware Included: Ships with self-tapping screws for support section attachment and seals to protect the mounted connection from the elements.
- System Compatibility: Purpose-built for Rittal's 62 Series support arm system, available in CP 60 and CP 120 configurations for a precise mechanical fit.
- Single-Unit Packaging: Supplied as a single packaged unit (1 pc.), simplifying stocking and replacement for maintenance and installation crews.
Technical Specifications
- Material: Die-Cast Zinc
- Rotating/Tilting: Yes
- Packaging Unit: 1 pc(s).
- Finish: RAL 7035
- Supply Includes: Self-tapping screws for support section attachment and seals
- Arm System Options: CP 60, CP 120
Typical Applications
- Support Arm System Housing Mounting
- Industrial Enclosure and Monitor Arm Installations
- Control Panel and HMI Positioning
- Commercial and Industrial Support Arm Infrastructure
- Renovation and Retrofit of Existing Support Arm Systems
Why Rittal?
Rittal is a recognized name in industrial enclosure and support arm systems, and the CP Swivel Coupling reflects that standard with die-cast zinc construction and a durable RAL 7035 finish across both the 60 and 120 support arm configurations. Complete with the mounting screws and seals needed for installation, this coupling delivers a reliable, precisely engineered connection point for professional support arm system builds, helping ensure equipment stays securely and accurately positioned over the life of the installation.
Manufacturer Resources
Rittal Product Catalog
Product Specs
- Product Type:
- Enclosure Rail & Mounting Hardware
- Configuration:
- Rotating/Tilting
- Series:
- 62 Series
- Product Material:
- Die-Cast Zinc
- Product Color:
- RAL 7035
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Finish:
- RAL 7035
- Product Subgroup:
- Enclosure Accessories
Rittal 6206340 – Frequently Asked Questions
1) Which Rittal support arm system does the CP swivel coupling fit, 60 or 120?
Both, but you order the matching one. The Rittal 62 Series CP swivel coupling comes in two configurations: CP 60 under part number 6206340 and CP 120 under 6212300. The coupling bolts the housing to the vertical section of the support arm, so the arm system size on your existing run decides which part number you need. They are not interchangeable.
2) Where in a support arm assembly does the CP swivel coupling go?
It is the connection between the housing and the vertical section of the arm. On a Rittal 62 Series run, the coupling attaches at the vertical support section and carries the enclosure, monitor housing, or control panel on the other side, giving that housing rotate and tilt adjustment for viewing angle and access.
3) Do I need to buy screws or seals separately for the Rittal CP swivel coupling?
No. The coupling ships with the self-tapping screws for attaching to the support section and with the seals for that connection. What is not included is anything on the housing side, so check the prep on your enclosure or monitor housing before install.
4) Is the Rittal 6206340 swivel coupling metal or plastic?
Die-cast zinc, not plastic. That matters on a swivel joint carrying an enclosure, because the clamping faces hold their dimension over repeated adjustment rather than creeping. It is finished in RAL 7035 over the zinc.
5) Can I add this coupling to an existing Rittal support arm system to make a fixed panel adjustable?
Yes, that is a stated use. Rittal lists the CP swivel coupling for renovation and retrofit of existing support arm systems. Because it is the rotate/tilt connection at the vertical section, swapping in the coupling gives an already-mounted HMI or control panel angle adjustment. Match the CP 60 or CP 120 configuration to the arm system already installed.
6) Will the Rittal CP swivel coupling match the color of my existing Rittal arm and enclosures?
It is finished in RAL 7035, the light grey Rittal uses across its support arm and enclosure systems, so it blends with an existing Rittal install. If your enclosures were specified in a different RAL, the coupling will read as a different shade.
7) How many swivel couplings come in a pack of Rittal 6206340?
One. The CP swivel coupling is supplied as a single packaged unit, so a maintenance crew stocking spares or building out multiple arm stations orders one per joint.
