Rittal 8611290 Comfort Handle, Die-Cast Zinc, Powder-Coated RAL 7035

Rittal 8611290 Comfort Handle, Die-Cast Zinc, Powder-Coated RAL 7035

The Rittal 8611290 Comfort Handle is a snap-on enclosure handle built in die-cast zinc with a powder-coated RAL 7035 finish, engineered for TS, TS IT, VX SE, PC enclosure door, IW, TS 8 stainless steel, SE stainless steel, and EL 3-part 18 - 21 U enclosure systems. Its folding technology eliminates the need for swiveling clearance, so the door surface stays completely free for mounted equipment. The handle is prepared for F version lock inserts as well as safety and push-button lock inserts up to 26.5 mm in length, and it ships one piece per packaging unit at 0.8 kg.

Key Features

• Durable Construction: Die-cast zinc body resists deformation and wear across repeated cycling.
• Folding Design: Requires no swiveling space, keeping the door surface completely free for installed equipment.
• Snap-On Installation: Easy fitment thanks to the snap-on handle system, speeding up enclosure assembly.
• Lock Compatibility: Prepared for padlock and lock inserts, including F version lock inserts as well as safety and push-button lock inserts up to 26.5 mm long.
• Broad Enclosure Fit: Suitable for TS, TS IT, VX SE, PC enclosure door, IW, TS 8 stainless steel, SE stainless steel, and EL 3-part 18 - 21 U enclosures.
• Finish: Powder-coated surface finish in RAL 7035 for a consistent, durable appearance.
• Mounting Note: A handle adapter is required when fitting to TS, VX SE glazed door, PC lower door, or IW designer door.
• Packaging: Supplied 1 pc(s) per packaging unit, weighing 0.8 kg.

Technical Specifications

• Version: For padlock and lock inserts.
• Suitable for Enclosure Type: TS, TS IT, VX SE, PC enclosure door, IW, TS 8 stainless steel, SE stainless steel, EL 3-part 18 - 21 U.
• Material: Die-cast zinc.
• Lock: Prepared for F version lock inserts as well as safety and push-button lock inserts with a length of up to 26.5 mm.
• Mounting Tip: Handle adapter required when fitting to TS, VX SE glazed door, PC lower door, IW designer door.
• Surface Finish: Powder-coated.
• Packaging Unit: 1 pc(s).
• Color: RAL 7035.
• Weight/Packaging Unit: 0.8 kg.

Typical Applications

• Electrical Enclosure and Cabinet Doors
• Industrial Control Panel Access Points
• TS, VX SE, and PC Series Enclosure Systems
• Stainless Steel Enclosure Retrofits
• Renovation and New Enclosure Builds

Why Rittal?

Rittal builds the Comfort Handle from die-cast zinc with a powder-coated RAL 7035 finish for consistent, long-lasting performance on demanding enclosure doors. Its folding, snap-on design simplifies installation while keeping door surfaces clear, and its lock-insert compatibility supports secure, code-conscious panel access across TS, VX SE, PC, and IW enclosure families.
