Sargent & Greenleaf Lock Body for 6730

We designed our 6700 series group 2 mechanical safe locks to perform in high-security, high-traffic applications like ATMs, gun safes, bank locks and other demanding commercial settings. These UL-group 2 mechanical safe locks offer advanced security features to deter attacks and keep assets secure. Choose the level of sophistication and sizing you need for your application, without sacrificing quality design and advanced attack resistance.

Features:

  • Three all-metal combination wheels.
  • Brass, dual lever locking arms mated to a machined brass wheel center for the ultimate non-slip wheel construction.
  • Key changeable wheel design for simple combination changing.
  • Exclusive, patented torque adjuster to easily keep the wheel pack assembly set to the perfect resistance for long life and maximum resistance to wheel skating and vibration opening.
  • Familiar left-right-left dialing sequence, and one-handed operation.
  • Built in relock trigger to protect against dial and spindle punching attacks.
  • Solid brass lock bolt is strong enough to resist 225 lbs. of force.
  • The lock case uses S&G’s “magic module” footprint for ease of retrofit on existing containers.
  • Available with a wide variety of dials and rings in painted and plated finishes (including 24k gold).

Model Series Lock Bodies (only):

Part Number No. of Wheels Notes
6730-010
3
Standard lock bolt
6731-004
4
Standard bolt



Model Series Locks, Dials & Rings:

Part Number No. of Wheels Notes
6730-100
3
standard bolt, D300/R211 front reading B&W dial and ring
6730-101
3
standard bolt, D003/R004 front reading B&W dial and ring
6730-102
3
standard bolt, D220 Spy-Proof® B&W dial and ring
6730-103
3
standard bolt, D690 front reading, key locking B&W dial and ring
6730-112
3
standard bolt, D225 Spy-Proof®, key locking B&W dial and ring
6731-111
4
standard bolt, D225 Spy-Proof®, key locking B&W dial and ring


Manufacturer Resources

Product Specs

Catergory:
Mechanical Locks
Product Group:
Security Locks
Product Subgroup:
Parts and Accessories
Series:
6730
Subcategory:
Safe Lock
Product Type:
Mechanical Safe Locks
Department:
Safety

Sargent & Greenleaf 6730-010 – Frequently Asked Questions

1) Will the S&G 6730 lock body retrofit an existing safe or ATM without redrilling?
The 6730 lock case uses S&G's "magic module" footprint, which the manufacturer states is there for ease of retrofit on existing containers. If your container was prepped for a magic module footprint lock, the 6730-010 body drops into that same prep. Verify the mounting pattern in the door before you pull the old lock.
2) Three wheels or four wheels: should I order the 6730-010 or the 6731-004?
Both are body-only locks with a standard bolt. The 6730-010 has three combination wheels; the 6731-004 has four. Four wheels means a four-number combination and a larger number of possible settings, which is what some specifications call for on higher-value containers. If you are matching an existing three-number combination practice across a fleet of safes, stay with the 6730-010. In a complete lock with dial and ring, the four-wheel version is the 6731-111 (D225 Spy-Proof, key locking).
3) Is the 6730 safe lock rated for ATM and gun safe use?
The 6700 series is a Group 2 mechanical safe lock, UL Group 2, built for high-security, high-traffic work such as ATMs, gun safes, bank locks and similar commercial containers. The solid brass lock bolt resists 225 lbs of force, and a built-in relock trigger protects against dial and spindle punching attacks.
4) Does the 6730-010 come with a dial and ring, or do I need to order those separately?
The 6730-010 is the lock body only, supplied with the standard lock bolt and no dial or ring. If you want the complete assembly, order one of the lock, dial and ring part numbers instead: 6730-100 with the D300/R211 front reading black and white dial and ring, 6730-101 with the D003/R004 front reading dial and ring, 6730-102 with the D220 Spy-Proof dial and ring, 6730-103 with the D690 front reading key locking dial and ring, 6730-112 with the D225 Spy-Proof key locking dial and ring, or the four wheel 6731-111 with the D225 Spy-Proof key locking dial and ring. Choose the body only when you are reusing a dial and ring already on the container.
5) Can I change the combination on the 6730 myself, and do I need a change key?
Yes. The 6730 uses a key changeable wheel design, so the combination is changed with a change key rather than by replacing parts. Dialing is the familiar left-right-left sequence with one-handed operation. The change key is a separate item from the body, so confirm you have one on the truck before you schedule the combination change.
6) What keeps a mechanical safe lock like this from drifting open under vibration?
Two things on the 6730. It has a patented torque adjuster that sets the wheel pack to a chosen resistance, which S&G specifies for long life and resistance to wheel skating and vibration opening. The wheel pack itself uses brass dual lever locking arms mated to a machined brass wheel center for non-slip wheel construction, with three all-metal combination wheels. That matters on containers mounted near machinery or on ATMs that take constant handling.
7) I want a spy-proof dial on my safe. Which 6730 part number do I order?
The lock body alone will not give you that, since dials are ordered with the complete lock. For a Spy-Proof dial and ring in black and white, order 6730-102 (three wheels, standard bolt, D220 Spy-Proof) or 6730-112 (three wheels, D225 Spy-Proof with key locking). Dials and rings across the series are offered in painted and plated finishes, including 24k gold.
8) What is the difference between the Sargent & Greenleaf 6730-010 lock body and the Arrow BM-LB lock body?
Both are safe lock bodies sold without a dial and ring. The Sargent & Greenleaf 6730-010 is the three-wheel, standard lock bolt body from the 6700 series Group 2 mechanical safe locks, built with three all-metal combination wheels, brass dual lever locking arms on a machined brass wheel center, a key changeable wheel design, a patented torque adjuster, a built in relock trigger against dial and spindle punching, and a solid brass bolt rated to resist 225 lbs of force. The Arrow BM-LB is a lock body carried in the same 6730 series grouping. If you are matching an existing S&G container that already uses the magic module footprint, the 6730-010 is the body that drops into it.
9) I need a four wheel safe lock body instead of a three wheel one, what should I order?
Order the 6731-004 rather than the 6730-010. Both are standard bolt lock bodies from the same 6700 series, but the 6730-010 carries three combination wheels and the 6731-004 carries four. More wheels means a longer combination sequence; both share the same key changeable wheel design and the S&G magic module case footprint for retrofit on existing containers.
