Schlage Scan ll™ passive infrared motion sensors for request-to-exit applications are wall or ceiling mounted and designed to maximize coverage area regardless of installation height.

Models

• Scan II-B: black with externally visible activation LED
• Scan II-W: white with externally visible activation LED

Power requirements

• 12/24 VDC: 35 mA @ 12 VDC; 38 mA @ 24 VDC when activated
• 12/24 VAC: 42 mA @ 12 VAC; 48 mA @ 24 VAC when activated
• 38 mAh required for standby operation (no internal standby battery)

Relay

• Two form "C" relay contacts rated 2.0 Amp @ 30 VDC or VAC maximum for DC resistive loads

Installation options

• Adjustable relay latch time from 0.5 to 64 seconds
• Relay mode can be programmed to reset when timer expires or remain activated until motion stops
• Field-selectable fail safe/fail secure
• Mounting height of 7 to 15 feet (indoors only)
• Lock-in-place pattern adjustment is +/- 14° with separate settings for wall vs. ceiling application

Operating temperatures

• Intended for indoor use only
• High-impact ABS plastic enclosure and internal electronics can endure temperatures of -20° to 120°F

Additional information

• Refer to the Scan II data sheet
