Schlage PM485Grade 1 Faculty Restroom/Hotel with Deadbolt Mortise Lock, Keyed

Schlage PM485Grade 1 Faculty Restroom/Hotel with Deadbolt Mortise Lock, Keyed

(No reviews yet) Write a Review

Model: PM485 ATHA 626
$1,240.00
$754.47
Selected Finish is
Selected Lever Style is
Selected Rose/Escutcheon Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,240.00
$754.47
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schlage PM485Grade 1 Faculty Restroom/Hotel with Deadbolt Mortise Lock, Keyed

Grade 1, Mortise Locks Purpose-built to serve the commercial real estate, retail, multifamily and hospitality industries, Schlage Performance Series™ locks feature exceptional quality and style at a highly competitive price point. The PM Series offers 26 functions, including three electrified, and four mortise deadbolt functions, all made to meet Schlage’s rigorous quality standards. With popular levers and finish options, Schlage's full key system security line up, and its durable design, you can meet needs for both security and style. They are made to suite with other Allegion products to present a quality, complete door hardware solution and provide a consistent user experience throughout your building or complex. Better yet, you can suite the PM Series mortise locks with the PT Series tubular locks, as they share lever and rose styles.



PM485 - Faculty Restroom/Hotel Lock with Deadbolt

  • Key cylinder outside; thumbturn inside; deadbolt, latchbolt and deadlocking auxiliary latch
  • Outside lever always fixed; latchbolt retracted by inside lever
  • Deadbolt thrown or retracted by rotating inside thumbturn
  • Key outside retracts latchbolt but does not retract deadbolt unless using an emergency key (sold separately)
  • Rotating inside lever retracts both deadbolt and latchbolt
  • Inside lever always free for immediate egress



Chassis

  • Case: Cold Rolled Steel (CRS) with corrosion resistant zinc dichromate plating
  • Case size: 4-7/16" x 6-1/16" x 1" (113 mm x 154 mm x 25 mm) Note: PM and L Series case and cover holes differ.
  • Spacing: lever to cylinder 3-7/8" (98 mm);  lever to thumbturn hub 2-11/16" (68 mm)
  • Door thickness: 1-3/4" (44 mm) standard; 1-3/8" (35 mm) minimum; fits doors up to 2-1/2" thick - specify door thickness if  over 1-3/4" and position in door (Available EE only)
  • Field reversible handing



Trim Options

  • 10 lever designs made of zinc
  • N escutcheons: 7-7⁄8” x 2-1⁄2” x 7⁄16” (200 mm x 64 mm x 11 mm); wrought brass
  • Roses: A 2-1/8" (54 mm), B 2-9/16" (65 mm), C 2-5/8" (67 mm) - brass
  • Thumbturn style is ADA qualified



Latches, Armors, Strikes

  • Backset: 2-3/4" (70 mm) only
  • Armor: Standard - 1-1⁄4" x 8" x 7⁄32" (32 mm x 203 mm x 6 mm); Optional - 1-1⁄16" x 8" x 7⁄32"  (27 mm x 203 mm x 6 mm)
  • Deadbolt: 1" (25 mm) throw stainless steel
  • Latch: 3⁄4" (19 mm) throw stainless steel with anti-friction tongue
  • Strike: ANSI curved lip strike 1-1⁄4" x 4-7⁄8" (32 mm x 124 mm) standard; dust box included
  • Strike lip length: 1-3⁄16" (30 mm); optional strike lip lengths - 7⁄8", 1", 1-1⁄2", 1-3⁄4", and 2"



DOWNLOADS & RESOURCES

Product Information



Related Product Information



Technical resources



Manufacturer Resources

Product Specs

Subcategory:
Mortise Locks
Product Group:
Mechanical Locks
Series:
PM Series
Grade:
Grade 1
Keyed Function:
Keyed
Handle Type:
Lever
Standard Strike:
10-072 1-1/4" x 4-7/8" Square Corner Strike, Box (1-3/16" Lip Length)
Warranty:
5 Year Limited
Keyed:
Yes
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Locks
Commercial/Residential:
Commercial
Lock Type:
Mortise
Lock Function:
Faculty Restroom/Hotel
IMAP Policy:
Yes
Product Attribute:
Mortise Locks
Electronic:
No
Product Model:
PM485
Product Function:
Faculty Restroom/Hotel
Door Hand Direction:
Field Reversible
Door Thickness Range:
1-3/4"
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Schlage PM485 ATHA 626 – Frequently Asked Questions

1) How does the Schlage PM485 faculty restroom function actually work on the door?
The PM485 gives you a key cylinder outside and a thumbturn inside, with a deadbolt, latchbolt and deadlocking auxiliary latch. The outside lever is always fixed, so nobody walks in on an occupied room; the inside lever retracts the latchbolt and, when rotated, pulls both the deadbolt and the latchbolt at once for immediate egress. The occupant throws or retracts the deadbolt with the inside thumbturn. A key outside retracts only the latchbolt, not the deadbolt, unless an emergency key (sold separately) is used. That is the standard faculty restroom and hotel guestroom arrangement.
2) Do I need to order the Schlage PM485 handed, or can it be reversed in the field?
No handing to specify. The PM485 is field reversible, so the same lock covers left and right hand openings and a property manager can stock one part number for a whole building.
3) What cylinder do I have to specify with the Schlage PM485, and can I use my own core?
Cylinder choice is a required selection. You can take P for a conventional 6-pin cylinder keyed to Schlage's standard 5-pin keying, or order it less cylinder in one of four ways: L (less conventional 6-pin), J (less full size interchangeable core), B (less small format interchangeable core), or T for an FSIC construction core. If your building is already on an SFIC or FSIC system, order it less cylinder and drop in your own core.
4) Can I match the PM485 to the other locks and levers already in my building?
The PM Series is made to suite with other Allegion products, and it shares lever and rose styles with the Schlage PT Series tubular locks, so mortise openings and tubular openings can look identical down the corridor. Ten lever designs are offered: Athens, Broadway, Latitude, Longitude, Neptune, Playa, Rhodes, Selena, Tubular and Two. Finishes are 613 oil rubbed bronze, 619 satin nickel, 622 matte black, 625 bright chrome, 626 satin chrome and 643E aged bronze.
5) Will a Schlage PM485 drop into an existing Schlage L Series mortise prep?
Not a straight swap. Schlage states the PM and L Series case and cover holes differ, so the mounting holes will not line up with an L Series pocket. The PM485 case is 4-7/16 x 6-1/16 x 1 inch (113 x 154 x 25 mm), with lever to cylinder spacing of 3-7/8 inches and lever to thumbturn hub 2-11/16 inches. Compare those against what is in the door before you commit.
6) I need a mortise lock with a deadbolt for a bathroom but no key cylinder - what should I use instead of the PM485?
The PM485 is a keyed lock: it takes a cylinder outside and is ordered with a cylinder option, so it is built for hotel and faculty restroom openings that need key access. If the restroom does not need a key, the Cal-Royal NM8440 is a Grade 1 privacy/bed/bath mortise lockset with a deadbolt for 1-3/4 inch doors, and the Hager 3840S is a Grade 1 privacy/bed/bath mortise lock with a 2-3/4 inch backset. Both give you the deadbolt and privacy behavior without the outside key cylinder the PM485 uses.
7) What is the closest equivalent to the Schlage PM485 mortise lock from another manufacturer for a hotel or faculty restroom door with a deadbolt?
The Schlage PM485 is a Grade 1 keyed mortise lock with Faculty Restroom/Hotel function, which pairs a latchbolt with a thumbturn-operated deadbolt and an inside lever that retracts both for immediate egress. The nearest peer on the same kind of opening is the Sargent 7925, a Grade 1 heavy duty mortise lock with Corridor/Dormitory function that includes a single cylinder deadbolt with rose trim. Both are Grade 1 mortise bodies with a deadbolt in the case; the difference is the function itself - the PM485 deadbolt is thrown by an inside thumbturn, while the Sargent 7925 is a dormitory exit function with a single cylinder deadbolt.
8) What is the difference between the Schlage PM485 and a storeroom mortise lock like the Accentra 8805FL?
Both are Grade 1 mortise locks, but the function is not the same. The PM485 is a Faculty Restroom/Hotel lock: outside lever always fixed with a key cylinder outside, an inside thumbturn that throws a 1 inch deadbolt, and an inside lever that retracts both bolts. The Accentra 8805FL is a Grade 1 storeroom function in the 8800 Series, and the Cal-Royal NM8080 is a Grade 1 storeroom mortise lockset with an interchangeable core option. Storeroom function keeps the outside lever locked and keyed to the latchbolt only, with no deadbolt or occupant thumbturn, so it is not a substitute where you need the room to be secured from the inside.
9) The PM485 is only available with a 2-3/4 inch backset - what mortise lock works on a door prepped for a 2-1/2 inch backset?
The PM485 uses a 2-3/4 inch backset only. If the door is prepped for 2-1/2 inch, the Baldwin 6301 entry/apartment mortise lock body is offered with a 2-1/2 inch backset in both knob by knob and lever by lever for doors 1-3/4 inch and over, and the Baldwin 6310 entry/storeroom mortise lock body is a 2-1/2 inch backset for doors 1-3/8 inch and over. Confirm the existing pocket and cross-bore before ordering, since backset drives the face position of the case.
10) Is the Schlage PM485 heavy enough for a hotel or multifamily corridor?
It is a Grade 1 commercial mortise lock. The case is cold rolled steel with corrosion resistant zinc dichromate plating, and the Performance Series was built for commercial real estate, retail, multifamily and hospitality traffic. Bolt and latch are stainless steel.
11) Is the thumbturn on the Schlage PM485 ADA compliant?
The thumbturn style used on the PM Series is ADA qualified, and the lock is lever operated rather than knob, which is what accessible openings call for. Inside lever is always free for immediate egress.
12) Can I use the Schlage PM485 on a classroom door, or is there a better mortise lock for that?
The PM485 is built around an inside thumbturn deadbolt, which suits guest rooms and faculty restrooms rather than classrooms. For a classroom opening, the Corbin Russwin ML2003 is a Grade 1 mortise classroom lockset for 1-3/4 inch doors, and the Cal-Royal NM8070 is a Grade 1 classroom mortise lockset with an auxiliary deadlatch for 1-3/4 inch doors. If you need a classroom security or intruder function, the Marks USA LA318GJ is a Grade 1 classroom security indicator mortise lockset with an ANSI strike for 1-3/4 inch doors.
13) I want keypad access on a hotel room door instead of a key - what electronic mortise lock replaces the PM485?
The PM485 is a mechanical, non-electronic keyed mortise lock. For keypad or credential access on the same type of opening, the Schlage CO-100 is a Grade 1 standalone electronic mortise lock with a keypad reader in privacy function for 1-3/4 inch doors, and the Schlage Electronics LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125kHz proximity reader and a mobile enabled deadbolt with LED, carrying a 3 hour fire rating. The Dormakaba E-Plex E5086 is a Grade 1 electronic pushbutton and card mortise lock in entry/egress function.
14) Is the Sargent 4874 mortise deadbolt a substitute for the Schlage PM485?
No. The Sargent 4874 is a double cylinder mortise deadbolt with a 2-3/4 inch backset - a deadbolt only, keyed both sides, with no latchbolt and no lever. The PM485 is a complete lever lockset combining a latchbolt, a deadlocking auxiliary latch and a 1 inch deadbolt in one case, with the inside lever retracting both bolts for immediate egress. The Kaba Ilco 185 Series is likewise a deadbolt function mortise lock, not a lockset. Use a deadbolt-only body only where the door already has a separate latch and handle.
15) What mortise lock should I use on the corridor doors that only need to latch, not lock, alongside PM485 guest room locks?
For openings that only need latching, the Falcon MA101 is a Grade 1 heavy duty mortise passage lock with field reversible operation and a fire rating, which matches the PM485 field reversible handing on adjacent doors. The Hager 3810S is a Grade 1 passage mortise lock with rose trim and a 2-3/4 inch backset, the same backset the PM485 uses, and the Hager 3810E is the same passage lock with escutcheon trim. Choose rose or escutcheon to match the trim you are running on the keyed doors.
16) For an office or apartment entry door rather than a hotel room, what mortise lock do I order instead of the PM485?
The PM485 Faculty Restroom/Hotel function keeps the outside lever always fixed, so entry requires a key every time. For an office or tenant entry opening, the Cal-Royal NM8050 is a Grade 1 office/entrance mortise lockset with an auxiliary deadlatch for 1-3/4 inch doors, the Hager 3850E is a Grade 1 office mortise lock with lever and escutcheon on a 2-3/4 inch backset, and the Baldwin 6301 is an entry/apartment mortise lock body. These give an office or entrance function rather than the thumbturn deadbolt arrangement of the PM485.
17) Can I put the PM485 on a behavioral health or patient room door?
The PM485 uses a standard lever trim in ten lever designs with rose or escutcheon, which is not an anti-ligature arrangement. For behavioral health openings, the TownSteel MRX-L-01 is a Grade 1 heavy duty stainless steel anti-ligature lever mortise lockset in passage function for 1-3/4 inch doors, the MRX-A-01 is the ligature resistant arch trim version, and the Marks USA 5PDN is a Grade 1 hospital passage mortise push/pull paddleset that is ligature resistant and ADA compliant in satin stainless steel.
18) My door is 1-5/8 inch thick - can I still use the PM485?
The PM485 is built for 1-3/4 inch doors as standard with a 1-3/8 inch minimum, so a 1-5/8 inch door falls inside its range. If you are comparing electronic options on the same door, the Alarm Lock DL3500CR and DL2700CR Grade 1 classroom electronic mortise locks cover 1-5/8 inch to 1-7/8 inch, and the DL4500 Grade 1 electronic mortise deadbolt covers the same thickness band.
19) What is the difference between ordering the PM485 complete lockset and a bare mortise lock body like the BEST 45H?
The PM485 ships as a complete keyed lockset - case, latch, 1 inch deadbolt, ANSI curved lip strike with dust box, and your chosen lever, rose or escutcheon and finish. The BEST 45H is a heavy duty mortise lock body in public entrance function and the 45HCA is a heavy duty lock body with intruder function; those are lock bodies, so trim is specified separately. If you want one part number that covers the whole opening, the PM485 route keeps lever style, rose or escutcheon and finish on the same order.
20) Will a mortise thumbturn like the Sargent 130KB work with the Schlage PM485?
The Sargent 130KB is a standard mortise thumbturn in the 8200 Series and the Sargent 130W is a mortise thumbturn with a round backplate in the 7800 Series - both are trim pieces for their own lock bodies, not for the PM485. The PM485 already includes its inside thumbturn that throws and retracts the deadbolt, and its thumbturn style is ADA qualified. Order PM485 trim from the lever, rose and escutcheon options that belong to the PM Series rather than substituting another maker's thumbturn.
