Schneider PowerPact Q Circuit Breaker 200A 3-Pole 240VAC 25kA Thermal Magnetic with Lugs

Schneider PowerPact Q Circuit Breaker 200A 3-Pole 240VAC 25kA Thermal Magnetic with Lugs

Professional Power Distribution & Circuit Protection

The Schneider PowerPact Q Circuit Breaker delivers reliable 200A circuit protection with thermal-magnetic trip technology for professional electrical distribution applications. This 3-pole unit operates at 240VAC with 25kA interrupting capacity and features lug mounting for secure installation. Designed for HACR applications with 80% continuous current rating and 50/60 Hz network frequency compatibility.

Professional Features & Benefits

• 200A Current Rating: Provides robust circuit protection for medium-load electrical distribution systems with reliable overcurrent protection.
• Thermal-Magnetic Trip Technology: Combines thermal overload protection with magnetic short-circuit protection for comprehensive fault detection and interruption.
• 25kA Interrupting Capacity: Safely interrupts high fault currents to protect downstream equipment and maintain system integrity.
• 3-Pole Configuration: Simultaneously protects all three phases in balanced electrical systems for complete circuit monitoring.
• HACR Rated Application: Specifically designed for heating, air conditioning, and refrigeration equipment with appropriate motor protection characteristics.
• Lug Mounting System: Provides secure mechanical and electrical connections for professional installation requirements.
• 80% Continuous Current Rating: Allows sustained operation at rated capacity while maintaining thermal protection integrity.

Technical Specifications

• Ambient Air Temperature For Operation: 40-70 °C
• Average Life Duration: 15 year(s)
• Carbon Footprint: 537.0224939
• Carbon Footprint Kg Co2 Eq Total Life Cycle: 537.0224939
• China Rohs In Scope: No
• Circuit Breaker Application: HACR rated
• Continuous Current Rating: 80%
• Control Type: operating handle
• Country Of Origin: Mexico
• Device Application: distribution
• Device Type: LV equipment - Low voltage circuit breaker
• Distribution Carbon Footprint: 0.447523962
• End Of Life Carbon Footprint: 3.006844443
• Environmental Disclosure: ENVPEP2311048EN
• Eoli Availability Display: No need of specific recycling operations
• Eu Rohs Directive: Compliant with Exemptions
• Field Service Division: PPIBS
• Function Option: Standard
• Function Option Id: STANDARD
• Green Premium Status For Reporting: Green Premium product
• H And D Domain: Safety
• H And D Enrichment Assignment: no
• H And D Enrichment Class 3: Circuit Breakers
• H And D Enrichment Class 4: MCCB
• H And D Enrichment Function: ENCLOSURES
• H And D Subrange: RESI
• Halogen Content Performance: Halogen free product
• Halogen Free Status: Halogen free product
• Halogene Performance: Halogen free product
• Installation Carbon Footprint: 0
• Legacy Weee Scope: In
• Magnetic Hold Current: 1200 A
• Magnetic Tripping Current: 2400-2400 A
• Manufacturing Carbon Footprint: 16.34920666
• Mercury Free: Yes
• Mounting Support: lug
• Network Frequency: 50/60 Hz
• Package Weight Lbs: 2.07 kg
• Packaging Made With Recycled Cardboard: No
• Packaging Without Single Use Plastic: No
• Poles Description: 3P
• Product Availability: Stock - Normally stocked in distribution facility
• Product Contributes To Saved And Avoided Emissions: No
• Product Depth: 3.93 in
• Product Height: 6.47 in
• Product Or Component Type: circuit breaker
• Product Width: 4.5 in
• Range: PowerPact
• Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id: CONTAINS_SVHC
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• Recycled Metal Content At Cr Level: 0%
• Relationshiptype: Compatible relationship
• Return Indicator: Y
• Returnability: Yes
• Rohs Eur Conformity Date: 1909
• Rohs Eur Full Compliance Status: Compliant with Exemptions
• Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
• Rohs Eur In Scope: Yes
• Rohs Eur Status: Compliant with Exemptions
• Rohs Exemption Information: Yes
• Scope Perimeter: Outside of Europe
• Serviceability: No
• Sustainable Packaging: No
• Take Back: No
• Tier: 1
• Tier Id: 1
• Total Lifecycle Carbon Footprint: 537 kg CO2 eq.
• Traceability: Yes
• Trip Unit Technology: thermal-magnetic
• Use Carbon Footprint: 517.2189188
• Utilisation Category: category A
• Wd Status: 5 - INITIALIZED WITH DataSCAN OK (Migration)
• Wire Stripping Length: 22 mm
• With Recycled Cardboard: No
• Without Single Use Plastic: No
• Department: Electrical

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Commercial HVAC Systems
• Industrial Distribution Panels
• Refrigeration Equipment Protection
• Motor Control Centers
• Electrical Distribution Boards
• Power Distribution Systems
• Equipment Protection Applications

Why Choose Schneider Quality?

Schneider PowerPact Q circuit breakers deliver proven reliability with 15-year average life duration and halogen-free construction. The thermal-magnetic trip technology provides dependable protection while meeting environmental compliance standards including RoHS and Green Premium status for professional electrical installations.
