Schneider Contactor, Definite Purpose, 30A, 2 Pole

Schneider Electric Definite Purpose Contactor 30A 2-Pole Single Phase

(No reviews yet) Write a Review

Model: 8910DP32V02

In Stock (leaves warehouse same day if ordered before 3pm ET)

$76.83
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric Definite Purpose Contactor 30A 2-Pole Single Phase

Professional Electrical Control for Reliable Motor and Load Management

The Schneider Electric Definite Purpose Contactor delivers dependable electrical control with 30A rated current capacity and 2-pole configuration for single phase applications. This DP series contactor features 2 NO pole contact composition and provides professional-grade performance for motor control and load switching applications requiring reliable operation and long service life.

Professional Features & Benefits

  • 30A Line Rated Current: Handles substantial electrical loads with reliable current switching capacity for demanding applications
  • 2-Pole Configuration: Provides proper control for single phase motor and electrical load applications with 2 NO contact arrangement
  • Single Phase Design: Optimized for residential and light commercial single phase electrical systems
  • 20 Year Average Life Duration: Extended service life reduces maintenance costs and ensures long-term reliability
  • Definite Purpose Construction: Purpose-built design delivers consistent performance in motor control and load switching applications
  • Standard Function Option: Reliable operation with proven electrical control functionality

Technical Specifications

  • Accessories: 9991DPG1
  • Average Life Duration: 20 year(s)
  • China Rohs In Scope: No
  • Country Of Origin: China
  • Device Type: LV equipment - LV contactor
  • Eoli Availability Display: No need of specific recycling operations
  • Eu Rohs Directive: Compliant with Exemptions
  • Field Service Division: PPIBS
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Html Descr: Definite Purpose Contactor:Range of Product: DPLine Rated Current: 30AMotor Power Horsepower: 2HP 1
  • Legacy Weee Scope: In
  • Line Rated Current: 30 A
  • Manufacturer: Schneider Electric
  • Mercury Free: Yes
  • Package Weight Lbs: 272.155 g
  • Packaging Made With Recycled Cardboard: Yes
  • Packaging Without Single Use Plastic: Yes
  • Phase: 1 phase
  • Pole Contact Composition: 2 NO
  • Poles Description: 2P
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Or Component Type: Definite Purpose Contactor
  • Range Of Product: DP
  • Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: CONTAINS_SVHC
  • Reach Regulation: Reference contains Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 2541
  • Rohs Eur Full Compliance Status: Compliant with Exemptions
  • Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant with Exemptions
  • Rohs Exemption Information: Yes
  • Scope Perimeter: At least in Europe
  • Serviceability: No
  • Sustainable Packaging: Yes
  • Take Back: No
  • Tier: 2
  • Tier Id: 2
  • Traceability: No
  • Wd Status: L - LOB initialized
  • With Recycled Cardboard: Yes
  • Without Single Use Plastic: Yes
  • Department: Electrical

Professional Applications

  • Motor Control Systems
  • HVAC Equipment Control
  • Lighting Control Applications
  • Commercial Equipment Switching
  • Industrial Load Management
  • Electrical Panel Integration
  • Single Phase Motor Applications

Why Choose Schneider Electric Quality?

Schneider Electric definite purpose contactors provide reliable electrical control with 20 year average life duration and mercury-free construction. The sustainable packaging approach and RoHS compliance demonstrate commitment to environmental responsibility while delivering professional-grade performance for demanding electrical applications.

Manufacturer Resources

Product Specs

Accessories:
9991DPG1
Average Life Duration:
20 year(s)
China Rohs In Scope:
No
Country Of Origin:
China
Device Type:
LV equipment - LV contactor
Eoli Availability Display:
No need of specific recycling operations
Eu Rohs Directive:
Compliant with Exemptions
Field Service Division:
PPIBS
Function Option:
Standard
Html Descr:
Definite Purpose Contactor:Range of Product: DPLine Rated Current: 30AMotor Power Horsepower: 2HP 1
Legacy Weee Scope:
In
Line Rated Current:
30 A
Mercury Free:
Yes
Package Weight Lbs:
272.155 g
Packaging Made With Recycled Cardboard:
Yes
Packaging Without Single Use Plastic:
Yes
Phase:
1 phase
Pole Contact Composition:
2 NO
Poles Description:
2P
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Or Component Type:
Definite Purpose Contactor
Range Of Product:
DP
Reach Full Compliance Status:
Reference contains Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
2541
Rohs Exemption Information:
Yes
Serviceability:
No
Sustainable Packaging:
Yes
Take Back:
No
Tier:
2
Traceability:
No
Wd Status:
L - LOB initialized
With Recycled Cardboard:
Yes
Without Single Use Plastic:
Yes
Department:
Electrical
Product Type:
Definite Purpose Contactor
Product Group:
Motor Starters & Contactors

Schneider 8910DP32V02 – Frequently Asked Questions

1) What coil voltage does the Schneider 8910DP32V02 contactor use?
The coil on the 8910DP32V02 runs on 120V AC at 60 Hz (110V AC at 50 Hz). That is the control circuit voltage, not the load voltage, so it pairs with a standard 120V thermostat or control circuit. If your control transformer puts out 24V, this is the wrong contactor for the job.
2) Will a 2-pole 30A definite purpose contactor work for a three phase motor?
No. The Schneider DP 8910DP32V02 is a 1 phase, 2-pole device with a 2 NO contact arrangement, so it switches two legs only. A three phase load needs all three legs switched, which means a 3-pole contactor. Use this one for single phase motors, compressors, heaters, and lighting circuits.
3) How big a motor will a 30A Schneider DP contactor handle on single phase?
The DP series 8910DP32V02 carries a 30A line rated current and is rated 2 HP on single phase. Size by the motor's full load amps and the manufacturer's HP rating, not by the 30A figure alone, since inrush on a compressor or fan motor is well above running current.
4) I'm replacing a burned-out contactor in a rooftop unit. What do I match to be sure this one drops in?
Match three things off the old one: 2-pole, 30A, and a 120V AC coil. The Schneider 8910DP32V02 is 2-pole with 2 NO contacts, 30A line rated, single phase, with a 120V AC 60 Hz coil. If the old unit's coil label reads 24V or 208/240V, this is not the same part even though the poles and amperage match.
5) Are the contacts normally open or normally closed on this Schneider DP contactor?
Both poles are normally open (2 NO). The load is dead until the coil is energized at 120V AC, then both poles close. There is no normally closed pole, so you cannot use it to break a circuit on coil energization.
6) Can I add an auxiliary contact to the Schneider 8910DP contactor?
Yes. Schneider lists the 9991DPG1 as the accessory for this DP contactor. Order it separately, it does not come in the box with the contactor.
7) Is this Schneider contactor a repairable unit or a replace-on-failure part?
Replace on failure. Schneider lists serviceability as No for the 8910DP32V02, so there are no field-replaceable contact kits or coil kits for it. For an HVAC or MRO shop, that means stocking a spare whole contactor rather than parts. The published average life duration is 20 years.
8) Does this Schneider contactor meet RoHS and REACH for our facility's procurement rules?
The 8910DP32V02 is RoHS compliant with exemptions and mercury free. On REACH, Schneider declares that the reference contains Substances of Very High Concern above the threshold, which some institutional and government buyers flag in their submittals. Country of origin is China. Packaging uses recycled cardboard with no single use plastic.
9) What is a definite purpose contactor and when should I use one instead of a general purpose IEC contactor?
A definite purpose contactor like the Schneider DP range is built for a specific, predictable duty, typically HVAC compressors, condenser fans, heating elements, and lighting loads, where the load is known and steady. It is simpler and more compact than a general purpose IEC or NEMA contactor. Step up to a general purpose contactor when you need heavy jogging or plugging duty, replaceable contacts, or overload relay mounting. The 8910DP32V02 is not serviceable, so it is a swap-out part.
