Schneider Electric Homeline Quad Tandem Circuit Breaker 20/20A 10kA Short Circuit Rating

Schneider Electric Homeline Quad Tandem Circuit Breaker 20/20A 10kA Short Circuit Rating

Professional HACR Rated Protection for Residential Applications

The Schneider Electric Homeline quad tandem circuit breaker delivers reliable electrical protection with dual 20A circuits in a compact 2-space design. This UL Listed miniature circuit breaker features plug-in mounting for easy installation and HACR rating for heating, air conditioning, and refrigeration applications. Built for residential market segmentation with 10 kA short circuit current capacity and box lug electrical connections.

Professional Features & Benefits

• Dual 20A Rating: Provides protection for two separate 20-ampere circuits in one compact unit, maximizing panel space efficiency.
• 10 kA Short Circuit Current: Delivers robust fault protection capability for residential electrical systems and equipment.
• HACR Rated Application: Specifically designed and certified for heating, air conditioning, and refrigeration equipment protection.
• Plug-in Mounting: Enables quick and secure installation without additional hardware or complex wiring procedures.
• 2-Space Requirement: Optimizes electrical panel utilization by fitting two circuits into minimal panel real estate.
• UL Listed Certification: Meets rigorous safety and performance standards for reliable electrical protection and code compliance.
• 15 Year Average Life Duration: Engineered for long-term reliability and consistent performance in residential applications.

Technical Specifications

• Ambient Air Temperature For Operation: 40 °C
• Average Life Duration: 15 year(s)
• Carbon Footprint: 23.65867023
• Carbon Footprint Kg Co2 Eq Total Life Cycle: 23.65867023
• China Rohs In Scope: No
• China Rohs Label: 1
• Circuit Breaker Application: HACR rated
• Circuit Breaker Type: quad tandem
• Country Of Origin: Mexico
• Device Type: LV equipment - Low voltage circuit breaker
• Distribution Carbon Footprint: 0.098181326
• Electrical Connection: box lugs
• End Of Life Carbon Footprint: 0.08020074
• Energy Efficiency Optimized: FALSE
• Environmental Disclosure: ENVPEP1308001
• Eoli Availability Display: No need of specific recycling operations
• Eu Rohs Directive: Compliant
• Field Service Division: PPIBS
• Function Option: Standard
• Function Option Id: STANDARD
• Green Premium Status For Reporting: Green Premium product
• H And D Domain: Safety
• H And D Enrichment Assignment: no
• H And D Enrichment Class 3: Circuit Breakers
• H And D Enrichment Class 4: MCB UL 2P
• H And D Enrichment Function: MCB
• H And D Subrange: RESI
• Html Descr: MINIATURE CIRCUIT BREAKERLine Rated Current : 30 A, 20 ASystem Voltage
• Installation Carbon Footprint: 0.000390291
• Legacy Weee Scope: In
• Manufacturer: Schneider Electric
• Manufacturing Carbon Footprint: 1.607897878
• Market Segmentation: Residential
• Market Segmentation Id: RESIDENTIAL
• Mercury Free: Yes
• Mounting Mode: plug-in
• Number Of Spaces Required: 2
• Package Weight Lbs: 385.554 g
• Packaging Made With Recycled Cardboard: Yes
• Packaging Without Single Use Plastic: Yes
• Product Availability: Stock - Normally stocked in distribution facility
• Product Certifications: UL Listed
• Product Contributes To Saved And Avoided Emissions: No
• Product Depth: 2.98 in
• Product Height: 3.13 in
• Product Or Component Type: miniature circuit-breaker
• Product Width: 2 in
• Range Of Product: Homeline
• Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id: CONTAINS_SVHC
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• Recycled Metal Content At Cr Level: 0%
• Relationshiptype: Compatible relationship
• Return Indicator: Y
• Returnability: Yes
• Rohs Eur Conformity Date: 2534
• Rohs Eur Full Compliance Status: Compliant
• Rohs Eur Full Compliance Status Id: COMPLIANT
• Rohs Eur In Scope: Yes
• Rohs Eur Status: Compliant
• Rohs Exemption Information: Yes
• Scope Perimeter: Outside of Europe
• Serviceability: No
• Short Circuit Current: 10 kA
• Sustainable Packaging: Yes
• Take Back: No
• Tier: 1
• Tier Id: 1
• Total Lifecycle Carbon Footprint: 24 kg CO2 eq.
• Toxic Heavy Metal Free: Yes
• Traceability: No
• Use Carbon Footprint: 21.872
• Wd Status: L - LOB initialized
• With Recycled Cardboard: Yes
• Without Single Use Plastic: Yes
• Department: Electrical

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential Electrical Panels
• HVAC Equipment Protection
• Air Conditioning Systems
• Refrigeration Equipment
• Multi-Unit Properties
• Residential Service Upgrades
• Space-Constrained Panel Installations

Why Choose Schneider Electric Quality?

Schneider Electric Homeline circuit breakers deliver proven reliability with UL Listed certification and 15-year average life duration. The Green Premium product status and mercury-free construction demonstrate environmental responsibility, while RoHS compliance ensures regulatory adherence. Sustainable packaging with recycled cardboard and plastic-free materials reflects commitment to environmental stewardship.
