Schneider LA36 Series Molded Case Circuit Breakers — 3-Pole, 125A–400A

Schneider Electric LA36 Series 3-Pole Molded Case Circuit Breaker 125A-400A HACR Rated with Thermal-Magnetic Trip Unit

(No reviews yet) Write a Review

Model: LA36400

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6,276.96
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric LA36 Series 3-Pole Molded Case Circuit Breaker 125A-400A HACR Rated with Thermal-Magnetic Trip Unit

Professional HACR-rated circuit protection for commercial and industrial applications

The Schneider Electric LA36 Series delivers reliable 3-pole circuit protection with amperage ratings from 125A to 400A. This molded case circuit breaker features thermal-magnetic trip unit technology and HACR rating for heating, air conditioning, and refrigeration applications. Built with I-Line mounting configuration and 3-wire connectivity, this circuit breaker provides dependable overcurrent protection for commercial and industrial electrical systems.

Professional Features & Benefits

  • HACR Rating: Specifically designed and tested for heating, air conditioning, and refrigeration equipment protection, ensuring reliable performance in HVAC applications.
  • Thermal-Magnetic Trip Technology: Combines thermal and magnetic protection elements for precise overcurrent detection and fast fault clearing to protect downstream equipment.
  • 3-Pole Configuration: Provides simultaneous protection across all three phases with ABC phase connection for balanced load management in three-phase systems.
  • 125A-400A Range: Versatile amperage ratings accommodate various load requirements from medium to high-capacity electrical installations.
  • I-Line Mounting: Standardized mounting system ensures secure installation and easy integration with compatible electrical panels and switchboards.
  • Compact Design: 11" height x 6" width x 5.84" depth dimensions optimize panel space utilization while maintaining full protection capabilities.
  • 15-Year Service Life: Extended average life duration provides long-term reliability and reduces maintenance costs over the product lifecycle.

Technical Specifications

  • Average Life Duration: 15 year(s)
  • China Rohs In Scope: No
  • Circuit Breaker Application: HACR rated
  • Country Of Origin: Mexico
  • Device Type: LV equipment - Low voltage circuit breaker
  • Environmental Disclosure: ENVPEP1410004EN
  • Eoli Availability Display: No need of specific recycling operations
  • Eu Rohs Directive: Compliant with Exemptions
  • Field Service Division: PPIBS
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Green Premium Status For Reporting: Green Premium product
  • Halogen Content Performance: Halogen free plastic parts product
  • Halogen Free Status: Halogen free plastic parts product
  • Halogene Performance: Halogen free plastic parts product
  • Html Descr: 3P 300A 600V, LA FA/LA MOLDED CASE CIRCUIT BREAKER
  • Legacy Weee Scope: In
  • Manufacturer: Schneider Electric
  • Mercury Free: Yes
  • Mounting Mode: I-Line
  • Packaging Made With Recycled Cardboard: Yes
  • Packaging Without Single Use Plastic: Yes
  • Phase Connection: ABC
  • Poles Description: 3P
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Depth: 5.84 in
  • Product Height: 11 in
  • Product Or Component Type: circuit breaker
  • Product Width: 6 in
  • Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: CONTAINS_SVHC
  • Reach Regulation: Reference contains Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 1906
  • Rohs Eur Full Compliance Status: Compliant with Exemptions
  • Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant with Exemptions
  • Rohs Exemption Information: Yes
  • Scope Perimeter: At least in Europe
  • Serviceability: No
  • Sustainable Packaging: Yes
  • Take Back: No
  • Terminal Identifier: AL400LA
  • Traceability: Yes
  • Trip Unit Technology: thermal-magnetic
  • Wd Status: 1 - GSC certified
  • Wiring Configuration: 3-wire
  • With Recycled Cardboard: Yes
  • Without Single Use Plastic: Yes
  • Department: Electrical

Professional Applications

  • Commercial HVAC Systems
  • Industrial Motor Control Centers
  • Refrigeration Equipment Protection
  • Three-Phase Distribution Panels
  • Manufacturing Facility Power Distribution
  • Commercial Building Electrical Systems
  • Process Equipment Protection

Why Choose Schneider Electric Quality?

Schneider Electric LA36 Series circuit breakers deliver proven reliability with 15-year average service life and comprehensive regulatory compliance. The Green Premium product status, halogen-free construction, and sustainable packaging demonstrate environmental responsibility while maintaining professional-grade protection performance. Mercury-free design and RoHS compliance ensure safe installation and operation in modern electrical systems.

Manufacturer Resources

Product Specs

Average Life Duration:
15 year(s)
China Rohs In Scope:
No
Circuit Breaker Application:
HACR rated
Country Of Origin:
Mexico
Device Type:
LV equipment - Low voltage circuit breaker
Environmental Disclosure:
ENVPEP1410004EN
Eoli Availability Display:
No need of specific recycling operations
Eu Rohs Directive:
Compliant with Exemptions
Field Service Division:
PPIBS
Function Option:
Standard
Green Premium Status For Reporting:
Green Premium product
Halogen Content Performance:
Halogen free plastic parts product
Html Descr:
3P 300A 600V, LA FA/LA MOLDED CASE CIRCUIT BREAKER
Legacy Weee Scope:
In
Mercury Free:
Yes
Mounting Mode:
I-Line
Packaging Made With Recycled Cardboard:
Yes
Packaging Without Single Use Plastic:
Yes
Phase Connection:
ABC
Poles Description:
3P
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Depth:
5.84 in
Product Height:
11 in
Product Or Component Type:
circuit breaker
Product Width:
6 in
Reach Full Compliance Status:
Reference contains Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
1906
Rohs Exemption Information:
Yes
Serviceability:
No
Sustainable Packaging:
Yes
Take Back:
No
Terminal Identifier:
AL400LA
Traceability:
Yes
Trip Unit Technology:
thermal-magnetic
Wd Status:
1 - GSC certified
Wiring Configuration:
3-wire
With Recycled Cardboard:
Yes
Without Single Use Plastic:
Yes
Department:
Electrical
Product Type:
Circuit Breaker
Product Group:
Circuit Breakers

Schneider LA36400 – Frequently Asked Questions

1) Will the Schneider LA36 breaker mount in an I-Line panelboard or switchboard?
Yes. The LA36 uses I-Line mounting, which is the plug-on stab configuration Schneider uses in I-Line panelboards and switchboards. It is not a bolt-on or DIN rail breaker, so it needs an I-Line interior with an open space that accepts the LA frame. Plan around a device that measures 11 inches high, 6 inches wide and 5.84 inches deep.
2) Which amperages of the Schneider LA36 3-pole breaker can I order?
The LA36 family is catalogued from 125A through 400A, and the two ordering points are LA36300 at 300A and LA36400 at 400A. Both are 3-pole thermal-magnetic devices on the same LA frame, so the case footprint does not change between them.
3) Can I use this breaker to feed a rooftop packaged HVAC unit or a refrigeration rack?
Yes, that is the intended use. The LA36 carries an HACR rating, which is the qualification an equipment nameplate calls for when it specifies "HACR type breaker" for heating, air conditioning and refrigeration loads. It is a 3-pole device wired ABC, so it lands a three-phase compressor or condenser feed directly.
4) What voltage system is the Schneider LA36 rated for?
The LA36 is a low voltage molded case breaker rated to 600V, which covers 480Y/277V and 600V three-phase distribution as well as lower 208V systems. Schneider's own catalog description for the 300A pole reads "3P 300A 600V, LA FA/LA MOLDED CASE CIRCUIT BREAKER".
5) Will a Schneider LA36 drop into an Eaton or Square D bolt-on panel?
No. The LA36 is an I-Line plug-on breaker and will not mount in a bolt-on load center interior. An Eaton BAB Series Quicklag breaker, for example, is a bolt-on thermal-magnetic device for Eaton panels and is not interchangeable with an I-Line frame in either direction. Match the breaker to the panelboard the manufacturer built it for.
6) Does a thermal-magnetic trip unit work for motor loads, or do I need electronic trip?
Thermal-magnetic is what the LA36 uses, and it is the standard choice for HVAC and motor feeders: the bimetal element handles sustained overload while the magnetic element clears short circuits fast. What it does not give you is field-adjustable long-time, short-time or ground-fault settings. If your drawing calls for adjustable trip curves or selective coordination bands, you need an electronic trip frame instead, not the LA36.
7) What lugs or terminals does the LA36 400A use?
The terminal reference on the LA36 is AL400LA, the aluminum lug assembly for the 400A LA frame. Confirm your conductor size falls inside that lug range before you cut cable, and note the breaker is a 3-wire configuration, so a neutral is not landed on the device.
8) Can the LA36 breaker be repaired or have its trip unit replaced in the field?
No. Schneider lists the LA36 as non-serviceable, so there are no field-replaceable internals and a tripped-and-failed unit gets swapped rather than rebuilt. Average service life is stated at 15 years, which is what facilities teams generally budget replacement cycles against.
9) Do I need a separate main breaker kit or accessories with the LA36?
The LA36 is a standard-function breaker, meaning no shunt trip, undervoltage release or auxiliary contacts are built in. If your sequence of operation needs remote tripping on loss of control power, that is a separate accessory in the frame's own accessory line, the way Eaton handles it with an undervoltage release for its NZM frames. Specify those at order time, because the LA36 itself is not field-serviceable after the fact.
10) I need a shunt or undervoltage trip on a 3-pole breaker - does the Eaton 10250T undervoltage release fit an LA36?
It does not. The Eaton 10250T undervoltage release is built for Eaton NZM series molded case breakers. The Schneider LA36 is a standard function option thermal-magnetic breaker and is listed as non-serviceable, so field accessory work is not part of its design. If the job calls for an undervoltage release, specify a breaker frame built to accept one rather than adding a release to the LA36.
11) I need documentation for a LEED or green building submittal on this breaker. What does Schneider publish?
The LA36 is designated a Green Premium product with environmental disclosure document ENVPEP1410004EN. Plastic parts are halogen free, the unit is mercury free, and packaging uses recycled cardboard with no single-use plastic. One caveat for European submittals: the reference contains Substances of Very High Concern above the REACH threshold, and RoHS status is compliant with exemptions.
12) Where is the Schneider LA36 circuit breaker manufactured?
Mexico. Schneider also flags the LA36 as traceable, which matters on government and institutional jobs where country of origin and unit traceability have to be documented on the submittal.
13) For a main breaker position, would the Eaton Pow-R-Xpress kit do what the LA36 does?
Different jobs. The Eaton Pow-R-Xpress convertible main circuit breaker kit is a kit for converting a panel to a main breaker configuration in Eaton Pow-R-stock equipment. The Schneider LA36 is a 3-pole 3-wire molded case breaker itself, 125A to 400A, I-Line mounted and HACR rated for heating, air conditioning and refrigeration loads. If the requirement is overcurrent protection on a three-phase HVAC feeder, the LA36 is the device; the Eaton kit is panel conversion hardware for an Eaton lineup.
