Schneider LAL 3-Pole Molded Case Circuit Breakers — 125A to 400A

Schneider Electric LAL 3-Pole Molded Case Circuit Breaker 125A-400A HACR Rated Thermal-Magnetic

(No reviews yet) Write a Review

Model: LAL36300

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,434.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric LAL 3-Pole Molded Case Circuit Breaker 125A-400A HACR Rated Thermal-Magnetic

Professional HACR Rated Circuit Protection for Commercial and Industrial Applications

The Schneider Electric LAL 3-pole molded case circuit breaker delivers reliable electrical protection for commercial and industrial installations requiring 125A to 400A capacity. Featuring thermal-magnetic trip unit technology and HACR rating, this unit mount circuit breaker provides dependable overcurrent protection with halogen-free construction and sustainable design practices.

Professional Features & Benefits

  • 125A-400A Current Range: Versatile amperage capacity accommodates diverse commercial and industrial electrical loads with reliable overcurrent protection.
  • 3-Pole Configuration: Three-pole design provides comprehensive protection for three-phase electrical systems in commercial facilities.
  • HACR Rated: Heating, Air Conditioning, and Refrigeration rating ensures compatibility with HVAC equipment and motor loads.
  • Thermal-Magnetic Trip Technology: Advanced trip unit combines thermal and magnetic protection for precise overcurrent detection and reliable operation.
  • Halogen-Free Construction: Environmentally conscious plastic parts reduce environmental impact while maintaining performance standards.
  • Unit Mount Design: Flexible mounting configuration allows for versatile installation in various panel and enclosure applications.
  • 15-Year Average Life Duration: Extended service life reduces maintenance costs and provides long-term reliability for critical electrical systems.

Technical Specifications

  • Average Life Duration: 15 year(s)
  • Carbon Footprint: 1160.069476
  • Carbon Footprint Kg Co2 Eq Total Life Cycle: 1160.069476
  • China Rohs In Scope: No
  • Circuit Breaker Application: HACR rated
  • Country Of Origin: Mexico
  • Device Type: LV equipment - Low voltage circuit breaker
  • Distribution Carbon Footprint: 1.966271581
  • End Of Life Carbon Footprint: 10.30297115
  • Environmental Disclosure: ENVPEP1410004EN
  • Eoli Availability Display: No need of specific recycling operations
  • Eu Rohs Directive: Compliant with Exemptions
  • Field Service Division: PPIBS
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Green Premium Status For Reporting: Green Premium product
  • Halogen Content Performance: Halogen free plastic parts product
  • Halogen Free Status: Halogen free plastic parts product
  • Halogene Performance: Halogen free plastic parts product
  • Installation Carbon Footprint: 1.896790469
  • Legacy Weee Scope: In
  • Manufacturer: Schneider Electric
  • Manufacturing Carbon Footprint: 43.82880551
  • Mercury Free: Yes
  • Mounting Mode: unit mount
  • Packaging Made With Recycled Cardboard: Yes
  • Packaging Without Single Use Plastic: Yes
  • Poles Description: 3P
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Depth: 5.84 in
  • Product Height: 11 in
  • Product Or Component Type: circuit breaker
  • Product Width: 6 in
  • Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: CONTAINS_SVHC
  • Reach Regulation: Reference contains Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 1906
  • Rohs Eur Full Compliance Status: Compliant with Exemptions
  • Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant with Exemptions
  • Rohs Exemption Information: Yes
  • Scope Perimeter: At least in Europe
  • Serviceability: No
  • Sustainable Packaging: Yes
  • Take Back: No
  • Terminal Identifier: AL400LA
  • Tier: 3
  • Tier Id: 3
  • Total Lifecycle Carbon Footprint: 1 160 kg CO2 eq.
  • Traceability: Yes
  • Trip Unit Technology: thermal-magnetic
  • Use Carbon Footprint: 1102.074638
  • Wd Status: 1 - GSC certified
  • With Recycled Cardboard: Yes
  • Without Single Use Plastic: Yes
  • Department: Electrical

Professional Applications

  • Commercial Building Electrical Distribution
  • Industrial Facility Power Protection
  • HVAC Equipment Protection
  • Motor Control Centers
  • Manufacturing Facility Distribution
  • Retail and Office Building Systems
  • Multi-Unit Residential Properties

Why Choose Schneider Electric Quality?

Schneider Electric LAL circuit breakers combine proven thermal-magnetic technology with sustainable design practices and 15-year average life duration. Green Premium product status, halogen-free construction, and sustainable packaging demonstrate environmental responsibility while delivering reliable electrical protection for critical applications.

Manufacturer Resources

Product Specs

Average Life Duration:
15 year(s)
Carbon Footprint:
1160.069476
Carbon Footprint Kg Co2 Eq Total Life Cycle:
1160.069476
China Rohs In Scope:
No
Circuit Breaker Application:
HACR rated
Device Type:
LV equipment - Low voltage circuit breaker
Distribution Carbon Footprint:
1.966271581
End Of Life Carbon Footprint:
10.30297115
Environmental Disclosure:
ENVPEP1410004EN
Eoli Availability Display:
No need of specific recycling operations
Eu Rohs Directive:
Compliant with Exemptions
Field Service Division:
PPIBS
Function Option:
Standard
Green Premium Status For Reporting:
Green Premium product
Halogen Content Performance:
Halogen free plastic parts product
Installation Carbon Footprint:
1.896790469
Legacy Weee Scope:
In
Manufacturing Carbon Footprint:
43.82880551
Mercury Free:
Yes
Mounting Mode:
unit mount
Packaging Made With Recycled Cardboard:
Yes
Packaging Without Single Use Plastic:
Yes
Poles Description:
3P
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Depth:
5.84 in
Product Height:
11 in
Product Or Component Type:
circuit breaker
Product Width:
6 in
Reach Full Compliance Status:
Reference contains Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
1906
Rohs Exemption Information:
Yes
Serviceability:
No
Sustainable Packaging:
Yes
Take Back:
No
Terminal Identifier:
AL400LA
Tier:
3
Total Lifecycle Carbon Footprint:
1 160 kg CO2 eq.
Traceability:
Yes
Trip Unit Technology:
thermal-magnetic
Use Carbon Footprint:
1102.074638
Wd Status:
1 - GSC certified
With Recycled Cardboard:
Yes
Without Single Use Plastic:
Yes
Department:
Electrical
Product Type:
Circuit Breaker
Product Group:
Circuit Breakers

Schneider LAL36300 – Frequently Asked Questions

1) Which amp ratings of the Schneider LAL 3-pole breaker can I actually order?
Three amperages are offered: 300A (LAL36300), 350A (LAL36350) and 400A (LAL36400). All three are the same 3-pole molded case frame with a thermal-magnetic trip unit, so the only thing you pick is the amp rating that matches your feeder and overcurrent calculation.
2) Will the LAL breaker fit in my panel enclosure?
Plan the space around 11 inches high, 6 inches wide and 5.84 inches deep. It is a unit mount breaker, meaning it bolts into the panel or enclosure on its own mounting provisions rather than plugging onto a bus, so confirm your enclosure has the depth behind the dead front plus room for cable bending at 300A to 400A conductors.
3) Can I use this breaker to protect a rooftop HVAC unit or chiller?
Yes. The LAL is HACR rated, which is the rating required for breakers feeding heating, air conditioning and refrigeration equipment with motor-driven loads. The 3-pole configuration suits three-phase compressors and condenser units, and the thermal-magnetic trip handles the inrush of motor starting while still protecting against sustained overload.
4) Is a thermal-magnetic breaker the right choice, or do I need an electronic trip unit?
Thermal-magnetic is what the LAL uses, and it is the standard choice for straightforward feeder and branch protection in commercial distribution: a bimetal element for overload and a magnetic element for short circuit, with no electronics to configure. If your drawings call for adjustable long-time, short-time or ground-fault pickup settings for selective coordination, you need an electronic trip breaker instead; the LAL's trip unit is listed as Standard function with no adjustable electronic settings.
5) What terminal lugs does the LAL 400A breaker use?
The terminal reference on this breaker is AL400LA. That is the lug designation to quote when you are ordering replacement or additional terminals, and it is what to check against the conductor size you are landing at 300A through 400A.
6) Can the LAL breaker be repaired or re-ratable with a different trip unit?
No. Schneider lists the LAL as non-serviceable, so it is a sealed molded case unit: if it fails or you need a different amp rating, you replace the breaker rather than rebuild it or swap the trip unit. Budget a spare in the amp rating you standardize on if the circuit is critical.
7) Does the Schneider LAL meet green building and low-halogen material requirements for a spec job?
It carries Schneider's Green Premium product status, uses halogen-free plastic parts, is mercury free, and is RoHS compliant with exemptions. The packaging is recycled cardboard with no single-use plastic. One thing to flag for a submittal: the reference does contain Substances of Very High Concern above the REACH threshold, and the environmental profile document is ENVPEP1410004EN if your LEED or procurement reviewer wants the full EPD data.
8) What carbon footprint figure do I report for the LAL breaker on a facility sustainability submittal?
Total life cycle footprint is 1,160 kg CO2 eq. The breakdown Schneider publishes: 43.83 kg from manufacturing, 1.97 kg distribution, 1.90 kg installation, 1,102.07 kg in the use phase, and 10.30 kg at end of life. The use phase dominates because it accounts for resistive losses over the breaker's 15-year average life duration.
9) How long should I expect a Schneider LAL breaker to last in a commercial distribution panel?
Schneider publishes a 15-year average life duration for the LAL. That is a planning number for replacement cycles in a maintenance program, not a guarantee, and it assumes the breaker is used as an overcurrent device rather than as a daily on/off switch. At end of life Schneider notes no specific recycling operations are needed, though the unit falls in the legacy WEEE scope in Europe.
10) Where is the Schneider LAL circuit breaker made, and is it traceable for a government or institutional order?
Country of origin is Mexico, and Schneider maintains traceability on the reference, with GSC certified status on the record. If your procurement requires a country-of-origin declaration on the submittal, Mexico is the figure to put on it for the LAL36300, LAL36350 and LAL36400.
