Schneider PowerPact 2-Pole Molded Case Circuit Breaker 100A Thermal-Magnetic HACR Rated

Schneider PowerPact 2-Pole Molded Case Circuit Breaker 100A Thermal-Magnetic HACR Rated

Professional thermal-magnetic protection for distribution applications

The Schneider PowerPact 2-pole molded case circuit breaker delivers reliable thermal-magnetic protection with 100A continuous current rating and HACR rating for HVAC applications. This distribution-grade circuit breaker features toggle control operation, lug mounting support, and operates across 50/60 Hz network frequencies with -25°C to 70°C ambient temperature range for versatile installation environments.

Professional Features & Benefits

• 100A Continuous Current Rating: Provides reliable power distribution capacity with 80% continuous current rating for sustained operation under load.
• Thermal-Magnetic Trip Technology: Combines thermal overload and magnetic short-circuit protection for comprehensive electrical fault protection.
• HACR Rated Application: Specifically designed and certified for heating, air conditioning, and refrigeration equipment protection.
• PowerPact Series Design: Professional-grade molded case construction with black finish for durable performance in distribution applications.
• Wide Operating Temperature Range: Functions reliably from -25°C to 70°C ambient air temperature for diverse installation conditions.
• Magnetic Protection Parameters: 900A magnetic hold current and 1700A magnetic tripping current provide precise short-circuit fault detection.
• 15-Year Average Life Duration: Long service life reduces maintenance requirements and provides dependable long-term protection.

Technical Specifications

• Ambient Air Temperature For Operation: -25-70 °C
• Ambient Air Temperature For Storage: -50-85 °C
• Average Life Duration: 15 year(s)
• Carbon Footprint: 161.7325211
• Carbon Footprint Kg Co2 Eq Total Life Cycle: 161.7325211
• China Rohs In Scope: Yes
• China Rohs Label: 7
• Circuit Breaker Application: HACR rated
• Circularity Profile: ENVEOLI2206027_V2
• Continuous Current Rating: 80%
• Control Type: toggle
• Country Of Origin: Mexico
• Device Application: distribution
• Device Type: LV equipment - Low voltage circuit breaker
• Distribution Carbon Footprint: 0.290067498
• End Of Life Carbon Footprint: 2.580440191
• End Of Life Doc Ref: ENVEOLI2206027_V2
• Environmental Disclosure: ENVPEP2206027_V2
• Eoli Availability Display: Yes
• Eu Rohs Directive: Compliant with Exemptions
• Field Service Division: PPIBS
• Function Option: Standard
• Function Option Id: STANDARD
• Green Premium Status For Reporting: Green Premium product
• Installation Carbon Footprint: 1.39E-02
• Legacy Weee Scope: In
• Line Rated Current: 100-100 A
• Magnetic Hold Current: 900 A
• Magnetic Tripping Current: 1700-1700 A
• Manufacturing Carbon Footprint: 7.02266436
• Mercury Free: Yes
• Mounting Support: lug
• Network Frequency: 50/60 Hz
• Package Weight Lbs: 1.361 kg
• Packaging Made With Recycled Cardboard: Yes
• Packaging Without Single Use Plastic: No
• Poles Description: 2P
• Product Availability: Stock - Normally stocked in distribution facility
• Product Color: Black
• Product Contributes To Saved And Avoided Emissions: No
• Product Depth: 3.39 in
• Product Height: 6.42 in
• Product Or Component Type: circuit breaker
• Product Width: 4.09 in
• Protected Poles Description: 2t
• Quality Labels: CE
• Quantity Per Set: 1
• Range: PowerPact
• Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id: CONTAINS_SVHC
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• Recycled Metal Content At Cr Level: 0%
• Relationshiptype: Compatible relationship
• Return Indicator: Y
• Returnability: Yes
• Rohs Eur Conformity Date: 2539
• Rohs Eur Full Compliance Status: Compliant with Exemptions
• Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
• Rohs Eur In Scope: Yes
• Rohs Eur Status: Compliant with Exemptions
• Rohs Exemption Information: Yes
• Scope Perimeter: Outside of Europe
• Serviceability: No
• Sustainable Packaging: No
• Take Back: No
• Terminal Identifier: AL150HD
• Tier: 1
• Tier Id: 1
• Total Lifecycle Carbon Footprint: 162 kg CO2 eq.
• Traceability: Yes
• Trip Unit Technology: thermal-magnetic
• Use Carbon Footprint: 151.8254497
• Utilisation Category: category A
• Wd Status: 1 - GSC certified
• Wire Stripping Length: 16 mm
• With Recycled Cardboard: Yes
• Without Single Use Plastic: No
• Department: Electrical

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Commercial HVAC System Protection
• Industrial Distribution Panels
• Heating and Air Conditioning Equipment
• Refrigeration System Protection
• Electrical Distribution Centers
• Motor Control Centers
• Professional Building Services

Why Choose Schneider Quality?

Schneider PowerPact circuit breakers deliver professional-grade reliability with 15-year average life duration, CE quality certification, and mercury-free construction. The thermal-magnetic trip technology and HACR rating ensure dependable protection for critical electrical distribution applications with comprehensive environmental compliance and traceability.
