Schneider Electric SDSA Series Surge Protection Device
Professional Type 1 SPD with NEMA 4X Protection
The Schneider Electric SDSA Series Surge Protection Device delivers reliable electrical protection with 10kA nominal discharge current and 36kA surge current capacity. This Type 1 SPD features NEMA 4X enclosure protection and 3-wire configuration for versatile commercial applications, backed by Schneider Electric’s proven Surgelogic technology and 10-year average life duration.
Professional Features & Benefits
- 10kA Nominal Discharge Current: Provides robust surge protection capacity for demanding commercial electrical systems and critical equipment protection.
- 36kA Surge Current Rating: Handles high-energy transient events effectively, ensuring comprehensive protection against electrical surges and spikes.
- NEMA 4X Enclosure: Delivers superior environmental protection against dust, water, and corrosive conditions for reliable outdoor and harsh environment operation.
- Type 1 SPD Classification: Meets the highest surge protection standards for service entrance applications and whole-facility protection requirements.
- Status LED Indication: Provides clear visual confirmation of device operational status for easy monitoring and maintenance scheduling.
- 3-Wire Configuration: Offers flexible installation options compatible with standard electrical distribution systems and wiring practices.
- 10-Year Average Life Duration: Ensures long-term reliability and cost-effective protection with extended service life and minimal replacement requirements.
Technical Specifications
- Ambient Air Temperature For Operation: 65-65 °C
- Average Life Duration: 10 year(s)
- Cable Length: 24 in
- China Rohs In Scope: No
- Connections Terminals: wire
- Country Of Origin: Mexico
- Device Type: Surge Protection and Power Conditioning - Surge Protection Devices
- Energy Efficiency Optimized: FALSE
- Eu Rohs Directive: Compliant with Exemptions
- Field Service Division: PPIBS
- Function Option: Standard
- Function Option Id: STANDARD
- H And D Domain: Safety
- H And D Enrichment Assignment: yes
- H And D Enrichment Class 3: Surge protection devices
- H And D Enrichment Class 4: SPD Type 1
- H And D Enrichment Function: SPD
- H And D Subrange: SPD NEMA
- Legacy Weee Scope: In
- Local Signalling: status LED
- Manufacturer: Schneider Electric
- Market Segmentation: Commercial
- Market Segmentation Id: COMMERCIAL
- Mercury Free: Yes
- Nema Degree Of Protection: NEMA 4X
- Nominal Discharge Current: 10 kA
- Packaging Made With Recycled Cardboard: No
- Packaging Without Single Use Plastic: Yes
- Product Availability: Stock - Normally stocked in distribution facility
- Product Contributes To Saved And Avoided Emissions: No
- Product Or Component Type: surge protection device
- Range Of Product: Surgelogic
- Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
- Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
- Reach Full Compliance Status Id: CONTAINS_SVHC
- Reach Regulation: Reference contains Substances of Very High Concern above the threshold
- Recycled Metal Content At Cr Level: 0%
- Return Indicator: Y
- Returnability: Yes
- Rohs Eur Full Compliance Status: Compliant with Exemptions
- Rohs Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
- Rohs Eur In Scope: Yes
- Rohs Eur Status: Compliant with Exemptions
- Rohs Exemption Information: Yes
- Scope Perimeter: Outside of Europe
- Serviceability: No
- Surge Current: 36 kA
- Sustainable Packaging: No
- Take Back: No
- Tier: 1
- Tier Id: 1
- Traceability: Yes
- Wiring Configuration: 3-wire
- With Recycled Cardboard: No
- Without Single Use Plastic: Yes
- Department: Electrical
Professional Applications
- Commercial Building Service Entrance Protection
- Industrial Facility Surge Suppression
- Critical Equipment Protection Systems
- Electrical Distribution Panel Protection
- Outdoor Electrical Installation Protection
- Multi-Tenant Commercial Properties
- Healthcare and Emergency Services Facilities
Why Choose Schneider Electric Quality?
Schneider Electric SDSA Series surge protection devices deliver proven reliability with 10-year average life duration and NEMA 4X environmental protection. Part of the trusted Surgelogic product range, these Type 1 SPDs provide commercial-grade protection with mercury-free construction and comprehensive compliance certifications for professional electrical installations.
Manufacturer Resources
Product Specs
- Ambient Air Temperature For Operation:
- 65-65 °C
- Average Life Duration:
- 10 year(s)
- Cable Length:
- 24 in
- China Rohs In Scope:
- No
- Connections Terminals:
- wire
- Country Of Origin:
- Mexico
- Device Type:
- Surge Protection and Power Conditioning - Surge Protection Devices
- Energy Efficiency Optimized:
- FALSE
- Eu Rohs Directive:
- Compliant with Exemptions
- Field Service Division:
- PPIBS
- Function Option:
- Standard
- H And D Domain:
- Safety
- H And D Enrichment Assignment:
- yes
- H And D Enrichment Class 3:
- Surge protection devices
- H And D Enrichment Class 4:
- SPD Type 1
- H And D Enrichment Function:
- SPD
- Legacy Weee Scope:
- In
- Local Signalling:
- status LED
- Market Segmentation:
- Commercial
- Mercury Free:
- Yes
- Nema Degree Of Protection:
- NEMA 4X
- Nominal Discharge Current:
- 10 kA
- Packaging Made With Recycled Cardboard:
- No
- Packaging Without Single Use Plastic:
- Yes
- Product Availability:
- Stock - Normally stocked in distribution facility
- Product Contributes To Saved And Avoided Emissions:
- No
- Product Or Component Type:
- surge protection device
- Range Of Product:
- Surgelogic
- Reach Full Compliance Status:
- Reference contains Substances of Very High Concern above the threshold
- Recycled Metal Content At Cr Level:
- 0%
- Rohs Exemption Information:
- Yes
- Serviceability:
- No
- Surge Current:
- 36 kA
- Sustainable Packaging:
- No
- Take Back:
- No
- Tier:
- 1
- Traceability:
- Yes
- Wiring Configuration:
- 3-wire
- With Recycled Cardboard:
- No
- Without Single Use Plastic:
- Yes
- Department:
- Electrical
- Product Type:
- surge protection device
- Product Group:
- Surge Protective Devices
Schneider SDSA1175T – Frequently Asked Questions
1) Which SDSA model do I order for a 120V single phase circuit versus a 600V three phase delta system?
Two voltage configurations are offered on the Schneider Surgelogic SDSA. The SDSA1175T is the 120V, single phase, 2W+G single pole unit. The SDSA3650D is the 600V, three phase, 3W+G delta unit. Pick by the system you are landing on, not by the surge rating, since both share the same 10 kA nominal discharge and 36 kA surge current numbers.
2) Can a Schneider SDSA surge protector be mounted outdoors on a wet or washdown wall?
Yes. The SDSA carries a NEMA 4X rating, which covers dust, hose-directed water and corrosive environments, so outdoor walls, washdown areas and coastal or chemical-exposed sites are within its enclosure rating.
3) Is the SDSA a Type 1 or Type 2 SPD, and can it go on the line side of the main?
It is classified as a Type 1 SPD. Type 1 devices are the ones permitted on the line side of the service disconnect, which is why the SDSA is used for service entrance and whole-facility protection. A Type 2 device would be restricted to the load side of the main overcurrent device.
4) How does the SDSA connect to the panel, and how much lead do I get?
Connection is by flying leads, not terminal lugs, with 24 inches of cable supplied. That matters on install: SPD lead length should be kept as short and straight as practical, so mount the unit close to the panel and trim rather than coil the excess.
5) Will the SDSA3650D work on a 480V wye service?
No. The SDSA3650D is built for a 600V three phase 3-wire plus ground delta system. SPDs are voltage and configuration specific, so a 480V wye service needs the SDSA model matched to that system, not the 3650D. Using a delta-configured unit on a wye system leaves the neutral path unprotected.
6) How do I tell if a Surgelogic SDSA has taken a hit and needs replacing?
There is a status LED on the unit for local indication. It is a visual check only, so it needs someone to walk the panel; there is no remote contact or alarm output in the standard function option. Schneider lists the device as non-serviceable, so a failed unit gets replaced rather than repaired, and average life duration is given as 10 years.
7) Is the Schneider SDSA RoHS and REACH compliant for a spec submittal?
On RoHS, the SDSA is in scope and reports as Compliant with Exemptions, with exemption information available. On REACH, the reference contains Substances of Very High Concern above the threshold, so a facility with SVHC reporting obligations needs to log that. The device is mercury free. Country of origin is Mexico.
8) Is a 10 kA / 36 kA SPD enough for a commercial building service entrance?
The SDSA is rated at 10 kA nominal discharge current with 36 kA surge current capacity and is segmented by Schneider for commercial applications, which puts it in the range typically used for service entrance and distribution panel protection in commercial buildings. For a very high exposure site or a critical-load facility, a higher surge current Surgelogic unit is the usual step up, but the specification driver is your engineer's stated kA per phase, not the device family.
9) Is the SDSA part of the Surgelogic line, and does that matter for standardizing a facility?
Yes, the SDSA sits in Schneider's Surgelogic range under the SPD NEMA subrange. If your property already standardizes on Surgelogic at the panelboards, staying in the same range keeps the status indication, mounting habits and replacement practice consistent across openings and keeps your maintenance techs looking at the same LED for the same meaning.
