SEAL4-25N/D10
SEAL4-25N/D10 - spec sheet
Features
- Diffuse polycarbonate lens for protection and minimal glare
- 5 Yr Limited Warranty
- Economical linear washdown solution
- Quick mount solutions - surface & suspended
- 0-10V dimming
- Buy American Act Compliance
- Impact resistant polycarbonate housing
SEAL4-25N/D10 - spec sheet
Manufacturer Resources
Product Specs
- 208v:
- 0.13A
- 277v:
- 0.096A
- Efficacy:
- 114 lm/W
- Finish:
- Formulated for high durability and long-lasting color
- Gaskets:
- High-temperature silicone gaskets
- Green Technology:
- Mercury and UV free. RoHS-compliant components.
- Housing:
- Impact-resistant polycarbonate with stainless steel door clips. 1/2" opening/ drill out (drill out by customer) for conduit and bushing/cord entry.
- Input Watts:
- 25W
- Installation:
- Tether Cables are provided for easy installation. Quick connector may be used for quick and easy wiring.
- Lumens:
- 2,865 lm
- Thd:
- 5.16% at 120V, 9.25% at 277V
- Watts:
- 25W
- Weight:
- 6.8 lbs
- Product Group:
- Lighting
- Product Subgroup:
- Other
- Department:
- Electrical
