Sioux Chief 672X0 Series 6-Port CPVC Manifold, Copper Trunk Connection

Sioux Chief 672X0 Series 6-Port CPVC Manifold, Copper Trunk Connection

(No reviews yet) Write a Review

Model: 672X04C0

In Stock (leaves warehouse same day if ordered before 3pm ET)

$37.93
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Sioux Chief 672X0 Series 6-Port CPVC Manifold, Copper Trunk Connection

The Sioux Chief 672X0 Series manifold is a 6-port CPVC distribution manifold built on a 1" Type L copper tube trunk, engineered for hybrid potable water piping systems that pair a durable copper trunk line with CPVC branch distribution. Each of the six branches is spaced 2" on-center, giving plumbing contractors a consistent, predictable layout for home-run plumbing behind the wall or in a mechanical room. Depending on the job, this manifold body is available in overall sizes spanning 4" to 6" to fit a range of rough-in configurations while the 1" Type L copper trunk and 6-port CPVC branch layout remain constant across the line. This manifold is intended strictly as a distribution point for fresh supply branches — it is not rated for recirculation loops through any branch, and the manufacturer specifies that the unit must not be modified in the field.

Key Features

  • 6-Port Configuration: Six individual branch outlets allow a single trunk to feed six separate fixture runs from one manifold body.
  • Branch Spacing: Branches are spaced 2" on-center for consistent, code-friendly layout and easier tubing management.
  • Trunk Connection: Built on a 1" Type L copper tube trunk for a durable transition point into the branch network.
  • CPVC Branch Material: Branch construction is CPVC, suited for hybrid copper-to-CPVC potable water distribution systems.
  • Hybrid System Design: Purpose-built for hybrid potable water piping systems that pair a copper trunk with CPVC branch takeoffs.
  • Size Range: Manifold body available from 4" to 6" to suit different rough-in layouts.
  • No Recirculation: Not designed for recirculating flow back through any manifold branch — supply only.
  • No Field Modification: The manifold must not be modified after manufacture; altering the unit voids the manufacturer warranty.

Technical Specifications

  • Country of Origin: USA
  • Trunk Size: 1" Type L copper tube
  • Ports: 6 branch outlets, 2" on-center spacing
  • Available Sizes: 4" and 6"

Typical Applications

  • Hybrid Copper-to-CPVC Potable Water Distribution
  • Home-Run Plumbing Manifold Systems
  • Residential and Commercial Rough-In Plumbing
  • Mechanical Room Supply Distribution Points
  • New Construction and Repipe Projects

Why Sioux Chief?

Sioux Chief builds its 672X0 Series manifolds around a solid 1" Type L copper trunk paired with consistent 2" on-center CPVC branch spacing, giving plumbing contractors a dependable, repeatable layout for hybrid supply systems across 4" and 6" manifold sizes. Manufactured in the USA, this manifold is a straightforward, purpose-built component for professional rough-in work, delivering consistent fresh-supply distribution without recirculation or field modification.

Manufacturer Resources

Spec Sheet

Product Specs

Country of Origin:
United States
Configuration:
6-Port
Department:
Plumbing
Product Group:
Plumbing Fittings
Product Subgroup:
Manifolds
Product Material:
CPVC
Product Size:
6"
Product Type:
Manifold

Sioux Chief 672X04C0 – Frequently Asked Questions

1) What size trunk line does the Sioux Chief 672X0 manifold connect to?
The 672X0 Series manifold is built on a 1 inch Type L copper tube trunk, so it sweats directly into a 1 inch copper main. The branch side is CPVC, which is the point of the part: it gives you a copper-to-CPVC transition at the distribution point without a pile of adapter fittings.
2) How far apart are the branch outlets on the 672X0 6-port manifold?
Branches sit 2 inches on center across all six ports. That spacing is constant on both the 4 inch and 6 inch bodies, so your tubing layout and any clamp or bracket spacing behind the wall stays the same whichever size you order.
3) What is the difference between the 4 inch and 6 inch Sioux Chief 672X0 manifold?
Only the overall manifold body length changes. Both are 6-port, both use 2 inch on-center branch spacing, and both carry the 1 inch Type L copper trunk. Order 672X04C0 for the 4 inch body and 672X06C0 for the 6 inch. Pick based on the space you have in the stud bay or at the mechanical room drop, not on flow.
4) Can I run a hot water recirculation line through this manifold?
No. The 672X0 is a fresh-supply distribution manifold only. Sioux Chief does not rate it for recirculating flow back through any branch, so if your job has a dedicated return loop, the return has to be handled with separate piping and a crossover or return manifold rated for it. Using a branch here as a return is outside the manufacturer's intended use.
5) Is a CPVC manifold the right choice if my house is piped in copper?
That is exactly the case this manifold is built for. The trunk side is 1 inch Type L copper, so it ties into existing copper main, while the six branches are CPVC for the home-run fixture lines. If both your main and your branch runs are copper, you want an all-copper manifold instead. If both sides are CPVC, you do not need the copper trunk transition this part provides.
6) Can I cut or cap unused ports on a 6-port CPVC manifold if I only need four fixture runs?
Not on this one. Sioux Chief specifies that the 672X0 must not be modified after manufacture, so cutting the body down or drilling it is out. Unused branches should be capped with an appropriate CPVC cap or valve rather than altered. If you consistently need fewer takeoffs, order a manifold with the port count you actually want instead of trimming this one.
7) How many fixtures can one 672X0 manifold feed in a home-run layout?
Six. Each of the six branch outlets feeds one separate fixture run off the single 1 inch copper trunk, which is the standard home-run arrangement behind a wall or at a mechanical room drop. For more than six fixtures you gang additional manifolds on the same trunk.
