Spec Sheet
Product Specs
- Field color:
- Black
- Legend:
- OPEN OFF CLOSE
- Letter size:
- 1/8 inch high
- Lettering Color:
- White
- Notes:
- Has a satin aluminum field. Color is on lower portion.
- Number Of Positions:
- Three-position
- Series:
- 10250T
- Used With:
- 10250T Series, Selector Switch and Roto-Push Operators
- Department:
- Electrical
- Product Size:
- Standard, square
- Product Length:
- 1.7 IN
- Product Height:
- .1 IN
- Product Weight:
- .01 LB
- Product Width:
- 1.7 IN
B-LINE 10250TS53 – Frequently Asked Questions
1) What operators does the B-Line 10250TS53 legend plate fit?
The 10250TS53 is made for Eaton/B-Line 10250T Series pushbutton stations, specifically selector switch and Roto-Push operators. It is a legend plate only, so the operator, contact blocks and enclosure are separate items.
2) Will a 3-position legend plate work on a 2-position selector switch?
No. The OPEN OFF CLOSE marking on the 10250TS53 is positioned for a three-position operator, so the printed positions won't line up with a maintained two-position switch. For a two-position switch order the matching two-position plate in the same 10250T legend plate family.
3) Do I get the selector switch with the 10250TS53, or just the plate?
Just the legend plate. The 10250TS53 is the marked escutcheon that sits between the panel face and the operator; you still need the 10250T selector switch or Roto-Push operator and its contact blocks to have a working control.
4) What size is the 10250TS53 legend plate, and will it cover an existing standard 30.5mm hole?
It is the standard square size for the 10250T line, measuring 1.7 x 1.7 in with a .1 in thickness, and weighs about .01 lb. It mounts under the operator nut on a standard 30.5mm pushbutton hole, which is what 10250T operators use.
5) What finish is the 10250TS53 plate, and will it match my other 10250T plates?
The plate has a satin aluminum field with a black lower portion and white lettering. If your existing station plates are the satin aluminum 10250T style, it will match; if your panel uses the all-black legend plates, it will stand out.
