Stanley Security Grade 1 Surface Closer, Size 1-4, Tri-Pack Standard

Stanley Security Grade 1 Surface Closer, Size 1-4, Tri-Pack Standard

(No reviews yet) Write a Review
New Parts & Accessories Available!

Model: D-1611 695
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$667.00
$163.20
Adding to cart… The item has been added
New Parts & Accessories
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Stanley Security Grade 1 Surface Closer, Size 1-4, Tri-Pack Standard

The D-1610 Series is a slim line closer uniquely designed to accommodate the standard aluminum storefront application foot print. The pinion and piston are constructed of cold forgedsteel maintaining critical tolerances for reliable performance. The nonhanded cylinder body incorporates a robust cast aluminum construction

D-1611 Series Door Closers are adjustable from size 1 – 4 (2lbf – 8lbf closing force measured 30” from the pivot). The D-1611 Series. Door Closers are designed to meet entrance accessibility requirements of 5lbf opening force or less.

Cut Sheet

Manufacturer Resources

Product Specs

Series:
D-1611
ADA Compliant:
Yes
Mounting Detail:
Surface - Hinge Mount(Pull Side), Top Jamb Mount(Push Side), Parallel Arm Mount(Push Side)
Mounting Location:
Pull Side
Subcategory:
Surface Mounted Closers
Product Group:
Door Controls
Product Subgroup:
Door Closers - Surface Mounted
Product Type:
Surface Mounted Door Closers
Finish Type:
Powder Coat
Fluid Type:
All-Weather
Commercial/Residential:
Commercial
Mounting Method:
Surface Mount
Product Substrate:
Iron
Product Category:
Door Controls
Department:
Door Hardware

Parts & Accessories

    Stanley Security D-1611 695 – Frequently Asked Questions

    1) Will the Stanley D-1611 closer fit a narrow aluminum storefront door?
    That is what the D-1610 Series body was shaped for. It is a slim line closer sized to the standard aluminum storefront application footprint, so it sits on the narrow top rail of a typical glass front entrance without an auxiliary plate being the default. The cylinder is cast aluminum and non-handed, so one unit works on either hand of door.
    2) Is the Stanley D-1611 door closer ADA compliant for an accessible entrance?
    Yes. The D-1611 is built to meet entrance accessibility requirements of 5 lbf opening force or less, and it is flagged ADA compliant in its specs. Spring power adjusts from size 1 to 4, which is 2 lbf to 8 lbf closing force measured 30 inches from the pivot, so you can dial it down to the accessible range on an interior opening and up for a heavier exterior door.
    3) Can the Stanley D-1611 be mounted parallel arm on the push side?
    All three standard mountings are covered: hinge (regular) mount on the pull side, top jamb mount on the push side, and parallel arm mount on the push side. That is what tri-pack means here, the arm and brackets for all three ship together, so you decide at the opening rather than at the order form.
    4) I need a closer with more spring power than size 4 on a heavier door. What should I use instead?
    The Stanley D-1611 tops out at size 4 (8 lbf measured 30 inches from the pivot). For a heavier leaf, the Arrow DCN325 is a Grade 1 surface closer with regular/parallel arm tri-pack mounting and adjustable spring size 1 - 6, and the Norton Rixson 8501A is a Grade 1 tri-mount surface closer with an adjustable size 1-6 spring. The Accentra 2701 is another tri-pack closer with adjustable spring sizes 1-6.
    5) What is the closest equivalent to the Stanley D-1611 surface closer in another brand?
    The Stanley D-1611 is a tri-pack, adjustable size 1-4 surface closer that mounts hinge (pull) side, top jamb, or parallel arm. The Arrow DCN314 is the nearest match in that it is a Grade 1 surface closer with regular/parallel arm tri-pack mounting and adjustable spring size 1 - 4, though it ships less cover. The Accentra 1101BF is also an adjustable size 1-4 closer supplied with a tri-packed non-hold open arm.
    6) Do I need to specify handing when ordering a Stanley D-1611 closer?
    No handing to call out. The cylinder body is non-handed, so the same closer serves left and right hand doors. What you do pick is finish: 689 aluminum painted or 695 dark bronze painted, both powder coat.
    7) Will a Stanley D-1611 closer hold its speed on an exterior door through winter?
    It uses all-weather hydraulic fluid, so closing speed stays consistent across temperature swings instead of dragging in cold and racing in heat. Combined with the powder coat finish, it is rated for commercial use on exterior storefront entrances.
    8) Does the Stanley D-1611 hold the door open, or do I need a hold open arm?
    The D-1611 standard tri-pack is a closing arm, not a hold open. If the opening needs the door to stay parked, look at a hold open version instead, such as the Accentra 51 Series, which is specified as a tri-packed hold open arm, or the Orca BHDC1958 HO/PA hold open closer with parallel bracket.
    9) What is another slim storefront closer comparable to the Stanley D-1611?
    For aluminum storefront work the closest peers are the Norton Rixson 1600 Series aluminum storefront closer with tri-style mounting and the BEST SL6000 Series Grade 1 slim line closer with adjustable spring. Both are surface tri-mount closers in the same application space as the D-1611. Arrow's DCN314 is another tri-pack in the size 1-4 range if you want to stay at the same spring band.
    10) I'm standardizing closers across a building with dark bronze storefront. Does the Stanley D-1611 match?
    Yes, it comes in 695 dark bronze painted as well as 689 aluminum painted, both powder coat, which are the two finishes that cover most anodized aluminum storefront. Since the closer is non-handed and tri-mount, one part number covers every door in the fleet regardless of hand or mounting condition.
    11) For a high-traffic entrance, should I step up from the Stanley D-1611 to a heavy duty closer?
    The D-1611 is a commercial closer adjustable size 1 - 4 with all-weather fluid. Where a heavy duty cylinder is specified, the BEST EHD9000 is an extra heavy-duty Grade 1 surface closer with adjustable spring sizes 1-6, the Sargent 1431 Powerglide is a heavy-duty Grade 1 surface closer with adjustable spring power, and the Falcon SC71A is a heavy-duty Grade 1 surface-mount closer.
    12) Is the Cal-Royal 400 a direct substitute for the Stanley D-1611?
    Not on grade. The Cal-Royal 400 Series is a Grade 2 commercial hydraulic closer, while the Stanley D-1611 is Grade 1. If you are holding a Grade 1 spec, the Cal-Royal 500S barrier free closer with adjustable back-check or the Cal-Royal N900PBF barrier free hydraulic closer are the Grade 1 options in that brand.
    13) Which closers meet the same ADA opening force requirement as the Stanley D-1611?
    The D-1611 is ADA compliant and designed to meet entrance accessibility requirements of 5 lbf opening force or less. Other barrier free or ADA-rated choices include the Calibre CA4001 adjustable spring tension ADA hydraulic closer, the Calibre CA9901 tri-pack arm size 2-5 ADA closer, and the LCN 1250, a light duty closer with sizes 1-5 and all-weather fluid that is ADA compliant.
    14) What is the difference between the Stanley D-1611 and a slide track closer like the Corbin Russwin DC5230?
    The D-1611 is an arm-type closer that mounts hinge side, top jamb, or parallel arm. The Corbin Russwin DC5230 is a Grade 1 surface closer supplied with a slide track arm as standard for pull side mounting on 1-3/4 inch doors, so the track hardware and jamb prep differ. If you want a conventional arm in that brand, the DC6200 uses a double lever regular arm, pull side.
    15) Do I need delayed action instead of the standard Stanley D-1611?
    The D-1611 is a standard tri-pack closer without delayed action. Where a slower initial sweep is wanted for accessibility, the Orca BHDC1958DA/PA and BHDC2011DA/PA are delayed action closers with a regular arm and parallel bracket for 1-3/4 inch doors.
    16) What is the Stanley D-1611 closer body made of, and will it stand up to traffic?
    The pinion and piston are cold forged steel, which holds the tolerances that keep the hydraulics consistent over cycles, and the cylinder body is cast aluminum. It is a Grade 1 commercial closer, not a residential unit.
    17) Is the Arrow DCN500DP parallel drop plate a substitute for the Stanley D-1611?
    No. The Arrow DCN500DP is a parallel drop plate for the DCN500 closer, a mounting accessory rather than a closer. The Stanley D-1611 is the complete surface mounted closer body with tri-pack arm, adjustable size 1 - 4.
    18) I want a closer with a cover to match the painted Stanley D-1611. What are the options?
    The Stanley D-1611 comes in 689 aluminum painted and 695 dark bronze painted powder coat finishes. If a full metal or plastic cover is part of the spec, the Dexter DCH1000 is a Grade 1 tri-mount surface closer supplied with a full cover, and the Design Hardware 316 Series is a medium to heavy duty tri-packed closer supplied with a cover.
